Zte MU5001 Bedienungsanleitung

ZTE MU5001

5G Router

User Manual

Benutzerhanbuch

Version 1



CONTENTS

Contents 2

What’sin the box 3

teChniCal speCifiCation 4

GettinG familiar With your router 5

hoW to install the battery 6

hoW to insert the nano-sim 7

turn your 5G router on 8

Computer ConneCtion via usb type-C9

touCh sCreen iCons 10

start-up Guide: details required 11

pC start-up Guide: the proCess 12

mobile deviCe start-up Guide: the proCess 13

trouble shootinG / fehlerbehebunG 14

soinstallieren sie die batterie 15

soleGen sie die nano-sim ein 15

sChalten sie ihren 5G-router ein 16

ComputerverbindunG über usb type-C16

touChsCreen-symbole 17

startanleitunG: anGaben erforderliCh 18

pC-starthilfe: der prozess 19

leitfaden zur inbetriebnahme mobiler Geräte: der prozess 19

Please read the manual carefully.

If further support is required please contact us

United Kingdom enquiries

UK Website: https://falcontechnology.co.uk/

European Website : https://falcontechnology.eu

Email: support@falcontechnology.co.uk

Telephone: +44 1928 759 239

Germany Enquiries:

Email: info@easynd24.de

Hotline: +49 2688 988181

Congratulations on the purchase of your new

FALCON 5G Router

WHAT’S IN THE BOX

5G Router

USB Type-c

Cable

User

Manual

*The item colours and shapes may vary depending on the models.

TECHNICAL SPECIFICATION

Product Dimensions 13.3 x 7.3 x 1.85 cm; 200g

Batteries 1x Li-ION Polymer battery required.

(included)

Item model number MU5001

Colour Black

Wireless Type 802.11n, 802.11b, 802.11a, 802.11g,

802.11ac

Battery (in hours) 8 Hours charge with 8 hours use

Are Batteries

Included

Yes

Lithium Battery

Energy Content

4500 Milliamp Hours (mAh)

Lithium Battery

Packaging

Batteries contained in equipment

Number Of Lithium

Ion Cells

GETTING FAMILIAR WITH YOUR ROUTER

1External Antenna Ports

2Power Button

3Nano SIM Slot

4Touch Screen

5Charge/USB type-C jack

6LAN Port

FALCON

HOW TO INSTALL THE BATTERY

1. Pull back the cover to open. Note the nail gap on one

edge.

2. Insert the battery (found in box)

HOW TO INSERT THE NANOSIM

1. Insert the tip of a tray eject tool into the hole.

2. Pull out the tray and place the nano-SIM on the tray.

Slide the tray back in place with the provider logo facing up

(device facing screen down).

*Tray eject tool not included

TURN YOUR 5G ROUTER ON

*Note: If the battery is extremely low, you may be unable to power on the

device. Please charge your device rst.

Press and hold the power button until the screen lights

up. Once you have setup the device then in future it will

connect automatically.

COMPUTER CONNECTION VIA USB TYPEC

USB Type-C cable: Connect the cable to your computer to

browse the internet.

FALCON

TOUCH SCREEN ICONS

Network type: 4/5G

Signal

Strength

Wi:

- Users

connected

- Touch to

congure

settings

Battery Percentage

Settings:

- Connection by USB

- Connection by ethernet

cable

- Touch to congure device

settings

Date Usage*

*Usage shown for

demonstration

purposes

*Messages:

Not shown in

the image but

its accessible by

clicking on “settings”

then“messages”

Apply light pressure to the touch screen. Hold for a few second

to unlock.
