le-idc3 VESA adapter

Assembly instructions

The VESA adapter is compatible with the following products from Lenovo

(lenovo.com):

IdeaCentre AIO 3 27 (R3-Windows 11 Home-8GB-512GB), IdeaCentre AIO

3 27 (R5-Windows 11 Home-16GB-512GB), IdeaCentre AIO 3 27

(R7-Windows 11 Home-16GB-1TB), IdeaCentre AIO 3 Gen 6, IdeaCentre

AIO 3i 24 (i5-Windows 11 Home-16GB-512GB)

The VESA adapter allows you to conveniently mount your LENOVO brand All-in-

One PC to a monitor arm with a VESA hole pattern (75 x 75mm). Use the included

screws and nuts for this.

If you want to mount your VESA adapter directly to the wall, use suitable screws

and dowels (not included).

Make sure that the device is switched off and disconnected from the

mains to avoid possible injury or damage

Assembly instructions

Assembly instruction

Step 1

Place your Lenovo All-in-One PC securely on a soft surface.

Now remove the base of your Lenovo monitor if it is attached.

Step 2

Figure 1

Position your 3idee VESA adapter with the arrow and text

"UP" so that it is visible to you and with the arrow pointing

towards the top edge of the screen.

(Figure 1)

Step 3

Figure 2

Attach the VESA adapter to the monitor mount as shown.

(Figure 2)

Step 4

Figure 3

Take the 4 supplied M3x14 pan-head screws (separate screw

bag) and attach the adapter to the monitor.

(Figure 3)

3Assembly instructions

Step 5

Figure 4

For this step we recommend a 2nd person.

Now lift the monitor and hold it to your monitor mount.

Fasten the VESA adapter with the 4 included M4x14 screws

(screw bag: SP2).

It is best to fasten 2 screws diagonally first, so that the

monitor cannot fall down and you can fasten the remaining

screws without any effort.

ATTENTION: Pay attention to the right screws!

(Figure 4)

Step 6

Figure 5

Tighten the screws firmly. Done! (Figure 5)

Assembly instructions

Safety instructions

General notes

Make sure that all screws are tight and that the monitor audibly clicks into place during installation (if

present).

The material of the adapter is not heat resistant. Avoid direct heat around the adapter such as PC

exhaust or direct sunlight in summer.

PLA is UV resistant but not suitable for high temperatures.

Avoid jerky movements (pulling, tearing) on the PC monitor. This can affect the performance of the

VESA adapter.

Do not subject the PC monitor to excessive loads such as leaning or pushing. This can impair the

performance of the VESA adapter.

Material Notes

The adapter is made of high-quality polylactide (PLA) plastic. PLA is both a colorfast and UV-resistant

material and has low flammability. Polylactide has a low temperature resistance of approx. 35°C- 40°C

and is therefore not suitable for use in the vicinity of direct heat and heat sources.

Important note: Due to the low temperature resistance, the adapter is not suitable for use in vehicles

such as mobile homes or caravans. The temperatures prevailing there could affect the material and

impair the functionality of the adapter.

We wish you a lot of fun with your product.

Your 3idee Team

Responsible for this content:

3idee Technologies S.à r.l

5, ZA Um Lenster Bierg

L-6125 Junglinster

Luxembourg
