DCS800

Service manual

DCS800 Drives

(

20 to 5200 A

)

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

DCS800 Drive Manuals

Language

Public. number

E D I ES F CN RU PL

DCS800 Quick Guide 3ADW000191 x x x x x

DCS800 Tools & Documentation CD 3ADW000211 x

DCS800 Converter module

Flyer DCS800 3ADW000190 x x x x

Technical Catalogue DCS800 3ADW000192 x x x x x x x

Hardware Manual DCS800 3ADW000194 x x x x x x x x

Hardware Manual DCS800 update DCF503B/DCF504B 3ADW000194Z0301 x

Firmware Manual DCS800 3ADW000193 x x p x x x x x

Installation according to EMC 3ADW000032 x

Technical Guide 3ADW000163 x

Service Manual DCS800 3ADW000195 x x

12-Pulse Manual 3ADW000196 x

CMA-2 Board 3ADW000136 p

Flyer Hard - Parallel 3ADW000213 x

Drive Tools

DriveWindow 2.x - User's Manual 3BFE64560981 x

DriveOPC 2.x - User's Manual 3BFE00073846 x

Optical DDCS Communication Link 3AFE63988235 x

DDCS Branching Units - User’s Manual 3BFE64285513 x

DCS800 Applications

PLC Programming with CoDeSys CoDeSys_V23 x x x

61131 DCS800 target +tool description - Application Program 3ADW000199 x

DCS800 Crane Drive

DCS800 Crane Drive Manual suppl. 3AST004143 x

DCS800 Crane Drive Product note PDC5 EN REVA p

DCS800 Winder ITC

DCS800 Winder Product note PDC2 EN x

DCS800 Winder description ITC 3ADW000308 x

Winder Questionnaire 3ADW000253z x

DCS800-E Panel Solution

Flyer DCS800-E Panel solution 3ADW000210 x

Hardware Manual DCS800-E 3ADW000224 x

DCS800-A Enclosed Converters

Flyer DCS800-A 3ADW000213 x

Technical Catalogue DCS800-A 3ADW000198 x

Installation of DCS800-A 3ADW000091 x x

DCS800-R Rebuild System

Flyer DCS800-R 3ADW000007 x x

DCS800-R Manual 3ADW000197 x

DCS500/DCS600 Size A5...A7, C2b, C3 and C4 Upgrade Kits 3ADW000256 x

Extension Modules

RAIO-01 Analogue IO Extension 3AFE64484567 x

RDIO-01 Digital IO Extension 3AFE64485733 x

RRIA-01 Resolver Interface Module 3AFE68570760 x

RTAC-01 Pulse Encoder Interface 3AFE64486853 x

RTAC-03 TTL Pulse Encoder Interface 3AFE68650500 x

AIMA R-slot extension 3AFE64661442 x

Serial Communication

Drive specific serial communication

NETA Remote diagnostic interface 3AFE64605062 x

Fieldbus Adapter with DC Drives RPBA- (PROFIBUS) 3AFE64504215 x

Fieldbus Adapter with DC Drives RCAN-02 (CANopen)

Fieldbus Adapter with DC Drives RCNA-01 (ControlNet) 3AFE64506005 x

Fieldbus Adapter with DC Drives RDNA- (DeviceNet) 3AFE64504223 x

Fieldbus Adapter with DC Drives RMBA (MODBUS) 3AFE64498851 x

Fieldbus Adapter with DC Drives RETA (Ethernet) 3AFE64539736 x

x -> existing p -> planned

Status 04.2010

DCS800 Drive Manuals-List

j.doc

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

DCS800 Drives

20 to 5200 A

Service Manual

Code: 3ADW000195R0501 Rev E

DCS800 Service Manual e e.doc

EFFECTIVE: 03.2011

SUPERSEDES: Rev D 09.2009

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

3ADW000195R0101 DCS800 Service Manual e a

3ADW000195R0501 DCS800 Service Manual e e

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

Safety instructions

3ADW000195R0501 DCS800 Service Manual e e

Safety instructions

What this chapter contains

This chapter contains the safety instructions you must follow when installing,

operating and servicing the drive. If ignored, physical injury or death may follow, or

damage may occur to the drive, the motor or driven equipment. Read the safety

instructions before you work on the unit.

To which products this chapter applies

The information is valid for the whole range of the product DCS800, the converter

modules DCS800-S0x size D1 to D7, field exciter units DCF80x, etc. like the

Rebuild Kit DCS800-R00-9xxx.

Usage of warnings and notes

There are two types of safety instructions throughout this manual: warnings and

notes. Warnings caution you about conditions which can result in serious injury or

death and/or damage to the equipment, and advise on how to avoid the danger.

Notes draw attention to a particular condition or fact, or give information on a

subject. The warning symbols are used as follows:

Dangerous voltage warning warns of high voltage which can cause

physical injury or death and/or damage to the equipment.

General danger warning warns about conditions, other than those

caused by electricity, which can result in physical injury or death

and/or damage to the equipment.

Electrostatic sensitive devices warning warns of electrostatic

discharge which can damage the equipment.

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

Safety instructions

3ADW000195R0501 DCS800 Service Manual e e

Installation and maintenance work

These warnings are intended for all who work on the drive, motor cable

or motor. Ignoring the instructions can cause physical injury or death

and/or damage to the equipment.

WARNING!

• Only qualified electricians are allowed to install and maintain

the drive!

• Never work on the drive, motor cable or motor when main power is

applied.

Always ensure by measuring with a multimeter (impedance at least

1 Mohm) that:

1. Voltage between drive input phases U1, V1 and W1 and

the frame is close to 0 V.

2. Voltage between terminals C+ and D- and the frame is

close to 0 V.

• Do not work on the control cables when power is applied to the

drive or to the external control circuits. Externally supplied control

circuits may cause dangerous voltages inside the drive even when

the main power on the drive is switched off.

• Do not make any insulation resistance or voltage withstand tests

on the drive or drive modules.

• Isolate the motor cables from the drive when testing the insulation

resistance or voltage withstand of the cables or the motor.

• When reconnecting the motor cable, always check that the C+ and

D- cables are connected with the proper terminal.

Note:

•

The motor cable terminals on the drive are at a dangerously high

voltage when the main power is on, regardless of whether the

motor is running or not.

• Depending on the external wiring, dangerous voltages (115 V,

220 V or 230 V) may be present on the relay outputs of the drive

system (e.g. SDCS-IOB-2 and RDIO).

• DCS800 with enclosure extension: Before working on the drive,

isolate the whole drive system from the supply.

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

Safety instructions

3ADW000195R0101 DCS800 Service Manual e a

3ADW000195R0501 DCS800 Service Manual e e

Grounding

These instructions are intended for all who are responsible for the

grounding of the drive. Incorrect grounding can cause physical injury,

death and/or equipment malfunction and increase electromagnetic

interference.

WARNING!

• Ground the drive, motor and adjoining equipment to ensure

personnel safety in all circumstances, and to reduce

electromagnetic emission and pick-up.

• Make sure that grounding conductors are adequately sized and

marked as required by safety regulations.

• In a multiple-drive installation, connect each drive separately to

protective earth (PE ).

• Minimize EMC emission and make a 360° high frequency

grounding (e.g. conductive sleeves) of screened cable entries at

the cabinet lead-through plate.

• Do not install a drive equipped with an EMC filter to an

ungrounded power system or a high resistance-grounded (over 30

ohms) power system.

Note:

•

Power cable shields are suitable as equipment grounding

conductors only when adequately sized to meet safety regulations.

• As the normal leakage current of the drive is higher than 3.5 mA

AC or 10 mA DC (stated by EN 50178, 5.2.11.1), a fixed protective

earth connection is required.

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

Safety instructions

3ADW000195R0501 DCS800 Service Manual e e

Printed circuit boards and fiber optic cables

These instructions are intended for all who handle the circuit boards

and fiber optic cables. Ignoring the following instructions can cause

damage to the equipment.

WARNING! The printed circuit boards contain components sensitive to

electrostatic discharge. Wear a grounding wrist band when handling

the boards. Do not touch the boards unnecessarily.

Use grounding strip:

ABB order no.: 3ADV050035P0001

WARNING! Handle the fiber optic cables with care. When unplugging

optic cables, always grab the connector, not the cable itself. Do not

touch the ends of the fibers with bare hands as the fiber is extremely

sensitive to dirt. The minimum allowed bend radius is 35 mm (1.38 in.).

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

Safety instructions

3ADW000195R0101 DCS800 Service Manual e a

3ADW000195R0501 DCS800 Service Manual e e

Mechanical installation

These notes are intended for all who install the drive. Handle the unit

carefully to avoid damage and injury.

WARNING!

• DCS800 sizes D4 ... D7: The drive is heavy. Do not lift it alone. Do

not lift the unit by the front cover. Place units D4 and D5 only on its

back.

DCS800 sizes D5 ... D7: The drive is heavy. Lift the drive by the

lifting lugs only. Do not tilt the unit. The unit will overturn from a tilt

of about 6 degrees.

• Make sure that dust from drilling does not enter the drive when

installing. Electrically conductive dust inside the unit may cause

damage or lead to malfunction.

• Ensure sufficient cooling.

• Do not fasten the drive by riveting or welding.

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

Safety instructions

3ADW000195R0501 DCS800 Service Manual e e

Operation These warnings are intended for all who plan the operation of the drive

or operate the drive. Ignoring the instructions can cause physical injury

or death and/or damage to the equipment.

WARNING!

• Before adjusting the drive and putting it into service, make sure

that the motor and all driven equipment are suitable for operation

throughout the speed range provided by the drive. The drive can

be adjusted to operate the motor at speeds above and below the

base speed.

• Do not control the motor with the disconnecting device

(disconnecting mains); instead, use the control panel keys and

, or commands via the I/O board of the drive.

• Mains connection

You can use a disconnect switch (with fuses) to disconnect the

electrical components of the drive from the mains for installation

and maintenance work. The type of disconnect switch used must

be as per EN 60947-3, Class B, so as to comply with EU

regulations, or a circuit-breaker type which switches off the load

circuit by means of an auxiliary contact causing the breaker's main

contacts to open. The mains disconnect must be locked in its

"OPEN" position during any installation and maintenance work.

• EMERGENCY STOP buttons must be installed at each control

desk and at all other control panels requiring an emergency stop

function. Pressing the STOP button on the control panel of the

drive will neither cause an emergency stop of the motor, nor will

the drive be disconnected from any dangerous potential.

To avoid unintentional operating states, or to shut the unit down in

case of any imminent danger according to the standards in the

safety instructions it is not sufficient to merely shut down the drive

via signals "RUN", "drive OFF" or "Emergency Stop" respectively

"control panel" or "PC tool".

• Intended use

The operating instructions cannot take into consideration every

possible case of configuration, operation or maintenance. Thus,

they mainly give such advice only, which is required by qualified

personnel for normal operation of the machines and devices in

industrial installations.

If in special cases the electrical machines and devices are in-

tended for use in non-industrial installations - which may require

stricter safety regulations (e.g. protection against contact by

children or similar) - these additional safety measures for the

installation must be provided by the customer during assembly.

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: [email protected]

Andere Handbücher für DCS800

Inhaltsverzeichnis

Andere ABB Gleichstromantrieb Handbücher

ABB

ABB Relion 615 series Bedienungsanleitung

ABB

ABB ACS150 series Installationshandbuch

ABB

ABB ACS850-04 series Bedienungsanleitung

ABB

ABB ACS800-17LC Bedienungsanleitung

ABB

ABB ACS880-04 drive modules Bedienungsanleitung

ABB

ABB ACQ580-34 Bedienungsanleitung

ABB

ABB DCS800 Gebrauchs- und Pflegehandbuch

ABB

ABB ACS250 Betriebsanleitung

ABB

ABB ACS880 PCP Gebrauchs- und Pflegehandbuch

ABB

ABB ACS880 Series Gebrauchs- und Pflegehandbuch

ABB

ABB ACS880-07XT Series Bedienungsanleitung

ABB

ABB DriveIT ACH550-UH Bedienungsanleitung

ABB

ABB HSCXT3A-6B Bedienungsanleitung

ABB

ABB ACS880-07 Bedienungsanleitung

ABB

ABB ACS880-01 Series Bedienungsanleitung

ABB

ABB DCS880 series Bedienungsanleitung

ABB

ABB ACS480-04-09A8-1 Bedienungsanleitung

ABB

ABB ACS355 series Betriebsanleitung

ABB

ABB ACS580MV Bedienungsanleitung

ABB

ABB ACS880 Series Bedienungsanleitung

ABB

ABB ACS880-07LC Bedienungsanleitung

ABB

ABB DCS 400 Bedienungsanleitung

ABB

ABB ACS880-01 Series Bedienungsanleitung

ABB

ABB ACH580-01 Series Bedienungsanleitung

Beliebte Gleichstromantrieb Handbücher anderer Marken

Vincent Associates

Vincent Associates UNIBLITZ ED12DSS Bedienungsanleitung

EKSMA OPTICS

EKSMA OPTICS DQ-100-4 Stücklistenhandbuch

Chamberlain Garog

Chamberlain Garog D Series Bedienungsanleitung

Parker

Parker PDS Series Bedienungsanleitung

Festo

Festo DGC G Series Einrichtungshandbuch

Binks

Binks QS-5012-1-CE Bedienungsanleitung

Danfoss

Danfoss VLT 2800 Series Technisches Datenblatt

YASKAWA

YASKAWA CANopen SI-S3 Bedienungsanleitung

GE D20A6 Bedienungsanleitung

Unex

Unex MC-D-250-1000-050W-TW Bedienungsanleitung

Geckodrive

Geckodrive G213V Bedienungsanleitung

Rockwell Automation

Rockwell Automation PowerFlex 700S Betriebsanleitung

WEG

WEG DeviceNet CFW500 Bedienungsanleitung

Siemens

Siemens SINAMICS G Datenblatt

Siemens

Siemens SINAMICS SM150 6SL3815-7NP41-0AA1 Betriebsanleitung

SOMFY

SOMFY JR RU 30 Bedienungsanleitung

Beckhoff

Beckhoff AX8911 Bedienerhandbuch

Minarik

Minarik MM300 Series Bedienungsanleitung
