Contents

Aspire 5745 Series

Quick Guide

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire 5745 Series Quick Guide

Original Issue: 02/2010

Aspire 5745 Series Notebook PC

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the Just for Starters... poster helps you get started with setting up your

computer.

The Aspire Series Generic User Guide contains useful information applying to all

models in the Aspire product series. It covers basic topics such as using the

keyboard and audio, etc. Please understand that due to its nature, the Generic

User Guide as well as the AcerSystem User Guide mentioned below will

occasionally refer to functions or features which are only contained in certain

models of the series, but not necessarily in the model you purchased. Such

instances are marked in the text with language such as "only for certain

models".

The Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the poster, let us show you

around your new Acer notebook.

Top view

#Icon Item Description

1 Acer Crystal Eye

webcam

Web camera for video communication.

(only for certain models)

2 Microphone Internal microphone for recording sound.

English

1. The front panel indicators are visible even when the computer cover is closed up.

3 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output

(configuration may vary by model).

4 HDD indicator Indicates when the hard disk drive is active.

Num Lock

indicator

Lights up when Num Lock is activated.

Caps Lock

indicator

Lights up when Caps Lock is activated.

5 Power button Turns the computer on and off.

6 Keyboard For entering data into your computer.

7 Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

8Power indicator1Indicates the computer's power status.

Battery indicator1Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

Communication

indicator1

Indicates the computer's wireless

connectivity device status.

9 Click buttons

(left and right)

The left and right buttons function like the

left and right mouse buttons.

10 Palmrest Comfortable support area for your hands

when you use the computer.

11 Speakers Left and right speakers deliver stereo audio

output.

12 Optical drive eject

button

Ejects the optical disk from the drive.

13 P Programmable

key

User-programmable.

(only for certain models)

PowerSmart key Puts your computer into power-saving mode.

(only for certain models)

#Icon Item Description

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key

in the hotkey combination.

Hotkey Icon Function Description

<Fn> + <F3> Communication

key

Enables / disables the computer's

communication devices.

(Communication devices may vary by

configuration.)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle Switches display output between the

display screen, external monitor

(if connected) and both.

<Fn> + <F6> Display off Turns the display screen backlight

off to save power. Press any key to

return.

<Fn> + <F7> Touchpad

toggle

Turns the internal touchpad on and

off.

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness

down

Decreases the screen brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

<Fn> +

<Home>

Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up>

Stop Stop playing the selected media file.

<Fn> +

<Pg Dn>

Previous Return to the previous media file.

<Fn> + <End> Next Jump to the next media file.

English

Closed front view

Right view

#Icon Item Description

1 Multi-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory

Stick (MS), Memory Stick PRO (MS

PRO), xD-Picture Card (xD).

Note: Push to remove/install the card.

Only one card can operate at any

given time.

#Icon Item Description

1 USB 2.0 port Connect to USB 2.0 devices

(e.g., USB mouse, USB camera).

2 Optical drive Internal optical drive; accepts CDs or DVDs.

3 Optical disk

access indicator

Lights up when the optical drive is active.

4 Emergency eject

hole

Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the emergency

eject hole to eject the optical drive tray

when the computer is off.

5 DC-in jack Connects to an AC adapter.

21345

English

Left view

#Icon Item Description

1 Kensington lock slot Connects to a Kensington-compatible

computer security lock.

2 Ventilation slots Enable the computer to stay cool, even

after prolonged use.

3 External display

(VGA) port

Connects to a display device

(e.g., external monitor, LCD projector).

4 HDMI port Supports high definition digital video

connections.

5 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-

based network.

6 USB 2.0 port Connect to USB 2.0 devices

(e.g., USB mouse, USB camera).

7Microphone jack Accepts inputs from external

microphones.

Headphones/speaker/

line-out jack with

S/PDIF support

Connects to audio line-out devices

(e.g., speakers, headphones).

2134567
