ActionTec GT704WR Bedienungsanleitung

Solutions for the Digital Life™

User Manual

54 Mbps

Wireless

Cable/DSL

Router

Model #: GT704WR

Firmware version: 3.0.1.0.5b-GT704WR

IB: 1.1.1.42

Table of Contents

1 Introduction 1

Package Contents 1

Minimum System Requirements 2

Features 2

Getting to Know the Router 3

2 Setting Up the Router 7

Connecting a Computer to the Router 7

3 Performing a Basic Setup 21

Basic Setup 21

Changing the Admin User Name and Password 24

4 Using Advanced Setup 27

Accessing Advanced Setup 27

WAN IP Address 29

Wireless Settings 32

Wireless MAC Authentication 35

Wireless Advanced Settings 36

LAN IP Address 37

DHCP Server 37

Services Blocking 39

Website Blocking 40

Remote Management 41

Port Forwarding 42

DMZ Hosting 43

Firewall 44

Dynamic Routing 44

Static Routing 45

UPnP (Universal Plug and Play) 45

MAC Address Cloning 46

5 Viewing the Router’s Settings 47

Status 47

Routing Table 49

WAN Status 49

LAN Status 50

Active User List 50

6 Using Utilities 51

Web Activity Log 51

Restore Default Settings 52

Upgrade Firmware 53

Actiontec 54 Mbps Wireless Cable/DSL Router User Manual

7 Setting Up a Network 55

Ethernet 55

Wireless 60

8 Troubleshooting 63

Troubleshooting 63

Frequently Asked Questions 64

A Reference 71

Locating Computer Information 71

Locating Windows Operating System Files 72

B Setting Up Static IP on the Computer 75

Windows 98 SE 75

Windows Me 78

Windows 2000 81

Windows XP 85

C Computer Security 89

Comparing Broadband Service

with a Dial-Up Modem 89

Router Security 90

Computer Security 90

Electronic Security 91

D Specifications 93

General 93

Wireless Operating Range 94

LED Indicators 94

Environmental 94

E Glossary 95

F Firewall Security Level Services Table 99

High Security Level 99

Medium Security Level 100

Low Security Level 100

Basic Security Level 101

Service Acronym Definitions 101

G Non-Windows System Setup 103

Classic 103

OS X 105

Notices 107

Regulatory Compliance Notices 107

Modifications 107

Miscellaneous Legal Notices 108

Limited Warranty 109

Introduction

Thank you for purchasing the Actiontec 54 Mbps Wireless Cable/DSL Router. The

Router is the simplest way to connect computers to a high-speed broadband con-

nection using a Ethernet cable/DSL modem. This easy-to-use product is perfect for

the home office or small business. If you want to take your computing to the next

level, the Actiontec 54 Mbps Wireless Cable/DSL Router is sure to be one of the keys

to your success.

Package Contents

s Actiontec 54 Mbps Wireless Cable/DSL Router

s Power cord

s Yellow (Ethernet) cable

s Installation CD

s Quick start guide

Actiontec 54 Mbps Wireless Cable/DSL Router User Manual

Chapter 1 Introduction

Minimum System Requirements

s Active DSL service with Ethernet cable/DSL modem

s Computer with a 10/100 Mbps Ethernet connection

s Microsoft Windows 98 Second Edition (SE), Millennium Edition (Me), NT 4.0,

2000, or XP; Mac OS 7.1 and above

s Internet Explorer 4.0 or higher (5.x recommended) or Netscape Navigator

4.0 or higher (4.7 recommended)

s TCP/IP network protocol installed on each computer

Features

s Plug-and-Play installation support for systems with Windows operating

systems (98SE, Me, 2000, and XP)

s Ethernet WAN port (RJ-45)

s IP packet routing and transparent bridge

s Routing protocol (RIP-1, RIP-2) and static routing support

s Built-in NAT, DHCP server

s DNS relay support

s PAP/CHAP authentication, administrative passwords through Telnet

s 64-, 128-, and 256-bit WEP/WPA wireless LAN security

s 802.1x, WPA, and WPA-PSK for additional security wireless LAN security

s Compliant with IEEE 802.3 Ethernet standard

s 10/100 Base-T Ethernet ports (4)

s Flow control support for Fast Ethernet

s Web-based configuration setup

s Default configuration backup restore

Actiontec 54 Mbps Wireless Cable/DSL Router User Manual

Chapter 1 Introduction

s FTP firmware upgradeable

s Web download support

s 802.11b/g support

Getting to Know the Router

This section contains a quick description of the Router’s lights, ports, etc.

The Router contains several indicator lights (LEDs) on its front panel and a series

of ports on its rear panel.

Front Panel

The front panel of the Router features seven lights: Power, Internet, Wireless, and

Ethernet (4).

Power

Internet

Ethernet

Wireless

Power

Internet

Ethernet

Wireless234

1234

Power Light

The Power light displays the Router’s current status. If the Power light glows

steadily green, the Router is receiving power and fully operational. When the

Power light flashes rapidly, the Router is initializing. If the Power light is not

illuminated when the power cord is plugged in, the Router has suffered a critical

error and technical support should be contacted.

Actiontec 54 Mbps Wireless Cable/DSL Router User Manual

Chapter 1 Introduction

Internet Light

When the Internet light glows steadily, the Router is connected to the DSL pro-

vider via an Ethernet cable/DSL modem.

Wireless Light

The Wireless light illuminates when the Router is connected wirelessly.

Ethernet Lights

The Ethernet lights illuminate when the Router is connected via one or more of

its Ethernet ports.

Rear Panel

The rear panel of the Router contains six ports (Ethernet [4], Cable/DSL, and

Power), as well as a Reset switch.

Power

Ethernet 4

Reset

Cable/DSL

Ethernet 3Ethernet 2Ethernet 1

Ethernet Ports

The Ethernet ports are used to connect computers to the Router via Ethernet

cable. The Ethernet ports are 10/100 Mbps auto-sensing ports, and either a

straight-through or crossover Ethernet cable can be used when connecting to

the ports.

Actiontec 54 Mbps Wireless Cable/DSL Router User Manual

Chapter 1 Introduction

Cable/DSL Port

The Cable/DSL port is used to connect the Router to an Ethernet cable/

DSL modem.

Reset Switch

Depressing the Reset switch for one or two seconds will power cycle the Router

(similar to unplugging and then plugging in the Router’s Power cord). To

restore the Router’s factory default settings, depress and hold the Reset switch

for approximately 15 seconds. The reset process will start about 10 seconds after

releasing the switch.

Power Port

The Power port is used to connect the Power cord to the Router.

N Warning: Do not unplug the Power cord from the Router dur-

ing the reset process. Doing so may result in permanent damage

to the Router.

Actiontec 54 Mbps Wireless Cable/DSL Router User Manual

This page left intentionally blank.

Setting Up

the Router

The instructions that follow parallel the steps contained in the Actiontec Installation

Buddy®, which provides a visual guide to setting up the Router. It is recommended the

user run the Installation Buddy first, before attempting any other procedures.

To set up the Router, it must be connected to a computer, and then configured.

After connecting this first computer, other computers can be added to the network

via Ethernet, or wirelessly (see “Setting Up a Network” on page 55).

Connecting a Computer to the Router

1. Insert the Installation CD in the CD-ROM drive of the computer. The

Installation Buddy starts automatically. Wait until the following screen

appears, read the on-screen instructions, select the country in which you live

by clicking in the appropriate check box, then click Next.
