ADA INSTRUMENTS COSMO MINI Bedienungsanleitung

Operating manual

Laser distance meter

Model: COSMO MINI

Manufacturer: ADAINSTRUMENTS Address: WWW.ADAINSTRUMENTS.COM

INSTRUMENTS

COSMO MINI

INSTRUMENTS

Table of contents

1. Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. Menu functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4. Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5. Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

6. Message codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

7. Techical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

8. Measuring conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

9. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

10. Exceptions from responsibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Appendix 1 - “Warranty card”

COSMO MINI 3

INSTRUMENTS

Congratulations on the purchase of laser distance meter ADA COSMO MINI!

Permitted use

· Measuring distances

· Computing functions, e.g. areas, volumes, Pythagorean calculation

The safety regulations and instructions along with the operating manual should be read carefully before

initial operation.The person responsible for the instrument must ensure that equipment is used in accor-

dance with the instructions. This person is also accountable for the deployment of personnel and for their

training and for the safety of the equipment when in use.

COSMO MINI

INSTRUMENTS

SAFETY INSTRUCTION

Prohibited use

Please follow up instructions given in operating manual.

Do not use instrument in explosive environment (lling station, gas equipment, chemical production and so on).

Do not remove warning labels or safety instructions.

Do not open instrument housing, do not change it’s construction or modication.

Do not stare at beam. Laser beam can lead to eye injury (even from greater distances).

Do not aim laser beam at persons or animals.

Opening of the equipment by using tools (screwdrivers, etc.), as far as not specically permitted for certain cases.

Inadequate safety precautions at the surveying site (e.g. when measuring on the roads, construction sites and so on).

Use the instrument in the places where it could be dangerous: on the air transport, near manufacturers,

production facilities, in the places where the work of laser distance meter can lead to the harmful effects on

people or animals.

COSMO MINI 5

INSTRUMENTS

Laser classication

The instrument is a laser class 2 laser product with

power < 1 mW and wavelength 635 nm. Laser is safety

in ordinary conditions of usage.

START UP

Keypad

1) ON / Measure / Continious measurements

2) Area / Volume / Pythagorean measure / Reference

setting

3) Clear / OFF

COSMO MINI

INSTRUMENTS

Display

1) Laser ON

2) Reference (front/rear)

3) Area / volume/ Pythagorean

4) Main line 1

5) Line 2

6) Units

7) Battery level

COSMO MINI 7

INSTRUMENTS

Inserting / Replacing Batteries

Remove the battery cover, insert the battery correctly. Pay attention to correct polarity.

Close the battery compartment.

Replace the battery when symbol constantly blinks in the display.

Batteries should be removed in case of danger of corrosion, if the device will not be used for a long time.

MENU FUNCTIONS

Swtich on and off

Press the button (1) to switch on the instrument and laser.

The device also switches off automatically after 3 minutes of inactivity i.e. no key is pressed within that interval.

To switch off the instrument press and hold button (3) for about 2 sec.

COSMO MINI

INSTRUMENTS

Clear-Key

Cancel the last action. Press button (3).

Reference setting

Default reference setting is from the rear of the device. Press and hold button (2) for more than 2 sec to set the reference:

the front or the rear. You will see the reference symbol (2) on the display.

Selecting Units

Instrument is switched ON. Press and hold button (1) for 8 sec. Selected unit will be shown on the display

(ft/m). When you switch ON the instrument again DO NOT press and hold button (1) for 8 sec if you don’t

want to change the units of measurement.

MEASUREMENTS

Single distance measurement

Press and hold button (1) for 2 sec to activate the laser. When in continuous laser mode, press this button to

trigger the distance measurement directly. The instrument will give acoustical signal. The result is displayed

immediately.

COSMO MINI 9

INSTRUMENTS

Continuous Measurement

Press and hold the button (1) for about 2 seconds to start continuous measuring.

FUNCTIONS

Area

Press the button (2) once.The symbol “area” is displayed. Press button (1) to take the rst measurement (for

example, length). Measured value is displayed in the second line.

Press button (1) to take the second measurement (for example, width). Measured value is displayed in the

second line. The result of measured area is displayed in the rst line.

Volume

For volume measurements, press button (2) twice until the indicator for volume measurement appears on

the display.

Press button (1) to take the rst measurement (for example, length). Measured value is displayed in the

second line.

Press button (1) to take the second measurement (for example, width). Measured value is displayed in the

COSMO MINI

INSTRUMENTS

second line.

Press button (1) to take the third measurement (for example, height). Measured value is displayed in the

second line. The volume value will be displayed in the rst line.

Indirect measurement

Pythagorean measurement is used in the condition that the objective needing to be measured is covered or

has no effective reecting surface and can’t be measured directly.

Make sure you adhere to the prescribed sequence of measurement:

All target points must be in a horizontal or vertical plane.

The best results are achieved when the instrument is rotated about a xed point (e.g. with the positioning

bracket fully folded out and the instrument placed on a wall).

Be sure that the rst measurement and distance are measured at right angles.

Indirect measurement – determing a distance using 2 auxilary measurements

This function is used when height and distance can’t be measured directly.

Press button (2) 3 times. The symbol “triangle” is displayed. The distance to be measured is blinking in
