ADA INSTRUMENTS Cosmo 40 Bedienungsanleitung

Инструкция

по эксплуатации

Лазерный дальномер ADA Cosmo 40 А00376

Цены на товар на сайте:

http://www.vseinstrumenti.ru/instrument/izmeritelnyj/lazernye_dalnomery/ada/lazernyj_dalnomer_ada_co

smo_40_a00376/

Отзывы и обсуждения товара на сайте:

http://www.vseinstrumenti.ru/instrument/izmeritelnyj/lazernye_dalnomery/ada/lazernyj_dalnomer_ada_co

smo_40_a00376/#tab-Responses

Operating manual

Laser distance meter

Model: COSMO 40

Manufacturer: ADAINSTRUMENTS Address: WWW.ADAINSTRUMENTS.COM

COSMO 40

Table of contents

1. Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. Menu functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

4. Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

5. Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

6. Message codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

7. Techical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

8. Measuring conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

9. Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

10.Warranty/ Exceptions fromresponsibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Appendix 1 - “Certificate of acceptance and sale”

Appendix 2 - “Warranty card”

COSMO 40 3

Congratulations on the purchase of laser distance meter ADA COSMO 40!

Permitted use

· Measuring distances

· Computing functions, e.g. areas, volumes, subtractions, Pythagorean calculation

· Storing measurements

The safety regulations and instructions along with the operating manual should be read carefully before

initial operation.The person responsible for the instrument must ensure that equipment is used in accor-

dance with the instructions. This person is also accountable for the deployment of personnel and for their

training and for the safety of the equipment when in use.

COSMO 40

SAFETY INSTRUCTION

Prohibited use

Please follow up instructions given in operating manual.

Do not use instrument in explosive environment (filling station, gas equipment, chemical production and so on).

Do not remove warning labels or safety instructions.

Do not open instrument housing, do not change it’s construction or modification.

Do not stare at beam. Laser beam can lead to eye injury (even from greater distances).

Do not aim laser beam at persons or animals.

Opening of the equipment by using tools (screwdrivers, etc.), as far as not specifically permitted for certain cases.

Inadequate safety precautions at the surveying site (e.g. when measuring on the roads, construction sites and so on).

Use the instrument in the places where it could be dangerous: on the air transport, near manufacturers,

production facilities, in the places where the work of laser distance meter can lead to the harmful effects on

people or animals.

COSMO 40 5

Laser classification

The instrument is a laser class 2 laser product with

power < 1 mW and wavelength 635 nm. Laser is safety

in ordinary conditions of usage.

START UP

Keypad

1) ON / Measure

2) Area / Volume / Pythagorean measure

3) Reference

4) Clear / OFF

5) Addition / Subtraction/ Units

COSMO 40

Display

1) Laser ON

2) Reference (front/rear)

3) Area / volume/ Pythagorean

4) Main line

5) Line 2

6) Line 1

7) Units

8) Battery level

9) Error

COSMO 40 7

Inserting / Replacing Batteries

Remove the end piece on 180º. Remove the battery cover, insert the battery correctly. Pay attention to

correct polarity.

Close the battery compartment.

Replace the battery when symbol constantly blinks in the display.

Batteries should be removed in case of danger of corrosion, if the device will not be used for a long time.

MENU FUNCTIONS

Swtich on and off

Press the button (1) to switch on the instrument and laser.

Press and hold key for about 2 seconds to start continuous measuring.

The device also switches off automatically after 3 minutes of inactivity i.e. no key is pressed within that interval. To

switch off the instrument press and hold button (4) for about 2 sec.

COSMO 40

Reference Setting

Default reference setting is from the rear of the device. Press the button (3) to set the reference: the front or the rear.

When the end-piece is folded out fully, the reference rear is set. You will see the reference symbol on the display.

Selecting Units

Press and hold the button (5) for 2 sec. until the desired unit is displayed.

Clear-Key

Cancel the last action. Press button (4).

MEASUREMENTS

Single distance measurement

Press button (1) to activate the laser. When in continuous laser mode, press this button to trigger the distance

measurement directly. The instrument will give acoustical signal. The result is displayed immediately.

COSMO 40 9

Continuous Measurement

Press and hold the button (1) for about 2 seconds to start continuous measuring.

Minimum/ Maximum measurement

This function allows the user to measure the minimum or maximum distance from a fixed measuring point. It is

commonly used to measure room diagonals (maximum values) or horizontal distances (minimum values). Press and hold

down the button (1), until you will hear acoustical signal. Then slowly sweep the laser back and forth and up and down

over the desired target point (e.g. into the corner of a room). Press (1) to stop continuous measurement. The values for

maximum and minimum distances are shown on the display as well as the last measured value in the main line.

FUNCTIONS

Distance measuring

Press button (5): next measurement is added to the previous one. Press button (5): next measurement is

substracted from the previous one.
