2.0 OPERATION

2.1 SETTING UP AND TURN ON THE SCALE

The CBK, CBK-M series of scales provides a range of accurate, fast and versatile weighing scales with

counting, percent weighing and check-weighing functions. For the first time, you should set up your scale as

follows:

Gently Place the platform in the locating holes on the top cover. Level the scale by adjusting the four feet.

The scale should be adjusted such that the bubble in the spirit level is in the centre of the level and the scale

is supported by all four feet.

Attach the power cable to the connector on the base on the left of the scale

Plug in the power cable to the mains. Switch on the power switch located on

the base on the right side of the scale.

The scale will first display the software revision then run a self-

test. At the end of the self-test it will display zero weight when a

stable condition has been achieved. A stable symbol and zero

symbol indicators are also displayed.

2.2 ZEROING THE DISPLAY

You can press the [Zero] key at any time to set the zero point. When the zero point is obtained the display

will show the indicator for zero.

The scale has an automatic re-zeroing function to account for minor drifting or accumulation of material on

the platform. However you may need to press [Zero] to re-zero the scale if small amounts of weight are still

shown when the platform is empty.

2.3 TARING

Manual tare

Steps:

Zero the scale by pressing the [Zero] key if necessary. Place a container on the platform, a value for its

weight will be displayed.

Press the [Tare] key when reading is stable. The weight that was displayed is

stored as the tare value. The stable and “NET” indicator will be on. As a product

is added only the weight of the product will be shown. The scale could be tared

a second time.

When the container is removed a negative value will be shown. The zero indicator will also be on

because the platform is back to the same condition as it was when the [Zero] key was pressed last.

Press [Tare] or [Zero] to remove the tare value and display zero. The Net indicator will disappear.

Preset tare

This method allows you to enter a value for the tare weight from the keypad. This is useful if all containers are

the same or if the container is already full but the net weight is required and the weight of the container is

known.

Steps:

1) Zero the scale by pressing [Zero]. The zero indicator will be on.

2) Enter a tare value using the numeric keys.

3) Press [Tare] to tare the scale. The value that was entered is stored as the tare value and it is

subtracted from the display, leaving a negative number on the display.

2.4 WEIGHING

To determine the weight of a sample, first tare an empty container if used, then place the sample in the

container. The display will show the weight and the unit of weight currently in use. To change the weighing

unit press the [Unit] key. Weighing units displayed are the ones that are enabled by the user in the

parameters section.

2.5 PARTS COUNTING

The scale can be used to count parts based on the average weight of a sample weighed. If a container is to

be used, place this container on the platform before entering parts counting and press [Tare]. Press [Count]

to enter the Parts Counting mode.

The display will show the last sample size used. For example,

“10 Pcs”

Either place 10 parts on the platform for determining the average piece

weight or use a different number of parts. To change the sample size, press

[CE] to clear the last values and then enter the value 20 using the numeric

keypad.

Place the right number of parts on the platform. Press [Count] to weigh the samples and determine an

average piece weight.

After the sample has been weighed the scale will count any other parts added

by applying the average piece weight to the weight of the parts to be counted.

During parts counting the display can be changed to show the net weight, unit weight and number of parts by

each time pressing the [Func] key.

To count a different sample quantity, press the [Count] key. To return to weighing, press [Unit] when

“0

pcs”

is displayed.

NOTE:

If the parts are too light to measure accurately, the count may become faulty. It is suggested that the

samples to be weighed should each weigh more than the resolution of the scale.

2.6 CHECK COUNTING

Check-weighing is a procedure to display an indicator or sound an alarm when the weight on the platform

meets or exceeds the values stored in the memory. The memory holds values for a high limit and a low limit.

Either or both the limits can be set by the user.

The alarm and the LED bar graph can each be set to OFF. The LCD display will indicate whenever the

weight is within or exceeds the limits by showing

“OK”

(mass is between the limits),

“HI”

(mass is above the

high limit) or

“LO”

( mass is below the low limit).

The limits can be locked by the manager (see the menu structure section) .A Limit Password must be used

to change the limits or operation of the beeper or bar graph.

Steps:

1) In normal weighing, Press the [Low Limit] key. It will show the current low limit. The

“LO”

symbol will

appear on the display.

2) Press the [CE] key to clear the old value and then enter the new low limit using the numeric keys.

Then press [Tare] to accept the value. If you want to reset the value to zero, press [CE] to clear the

value. The limits are displayed in the weighing unit in use. If the weighing unit is pounds:ounces, the

limits are entered in pounds and decimal parts of pounds. i.e. 6,0125 lb.

3) To set the high limit press [High Limit], the

“HI”

symbol will be on. Set the high limit in the same way

the low limit was set. Pressing the [Tare] key to enter the value will return the scale to weighing, with

the Check-weighing function enabled.

4) During parts counting and percent weighing, the limits are set in the same way as above. The limits

are displayed in pcs or %.

5) To disable the check weighing function, enter zero into both the limits as described above. When the

current limits are shown, press [CE] to clear the settings, then press [Tare] to store the zero values.

NOTE:

The weight must be greater than 20 scale divisions for the check-weighing to operate.

Limits storing and recalling

The indicator can store up to 10 sets of high and low limits in memory along with the weighing units in use

(including pcs and %) as well as settings for the beeper and bar graph. During Check weighing the current

limits can be stored or previously stored units can be recalled.

If you are already in the check weighing mode the display will ask if you wish to

store the current limits by showing

“StOrE”

or recall another set of limits by

showing

“rECALL”

. The [Lim] key can be used to toggle between

“StOrE”

and

“rECALL”

If you want to store the limits, when

“StOrE”

is displayed press the [Tare] key.

The display shows

“St ”.

Enter a number corresponding to the desired memory

location (0 to 9).

“St X”

will be displayed for 2 seconds indicating the location X

where the current limits, weighing units and settings for the beeper and bar

graph are stored. The indicator will continue to work with the current settings as

active.

If you wish to recall any of the pre-stored limits, press [Tare] when

“rECALL”

displayed. The display shows

“rEC”

. Enter the number corresponding to the desired memory location (0 to 9)

to be recalled.

“rEC X”

will be displayed for 2 seconds indicating the values stored in the location “X” is being

recalled. The indicator will change to the recalled limits, weighing units and settings for the beeper and bar

graph.

NOTE:

If the recalled limit is for parts counting or percent weighing, the display will show the last sample

value used, ready for a new sample to be counted. If the memory location was empty the scale will return to

weighing.

2.7 PERCENT WEIGHING

The scale will use a mass on the platform as the 100% reference weight or input a reference weight using the

keypad.

Steps:

Press [Func]. The first option is

“FUnC 1”

, Press the [Tare] key.

“F1 PCt”

will be

displayed. Press [Tare] again to enter percent weighing. Put the sample on the

platform. The scale will set the sample mass on the platform as 100% reference

weight.

NOTE:

If there is no reference weight on the pan and percent weighing function is

entered, pressing [Tare] again will return to normal weighing.

Remove the sample weight. Then any other weight placed on the platform will be displayed as a percentage

of the original sample.

The number of decimal points will depend on the weight used. A smaller weight will show only “100%” while a

larger weight might show “100.00%”.

If the scale is showing zero When entering this function, Users can also input the reference weight using the

keypad, press [Tare] to accept the reference weight. The display will show “0.00 %”.

If the indicator shows

“x x . x x %”

, which is the last weight used as a reference, press [CE] to clear and use

the numeric keypad to enter a new value. Press [Tare] to accept the new reference weight.

Press [Unit] to return to normal weighing.

NOTE:

1) The weight entered must be greater than 50 scale divisions.

2) The display may jump by large numbers unexpectedly if small weights are used to set as 100%

reference. For example, if only 23.5g is placed on a scale with 0.5g increments and is set to 100%,

the display will show 100.00%. However a small change of weight will cause the display to jump to

102.13% as an increase of one scale division (0.5g) to 24.0g will be equivalent to an increase of

2.13%.

2.8 ACCUMULATED TOTALS

The scale can be set to accumulate when a weight is added to the platform automatically or manually by

pressing [Print]. See menu structure section. The accumulation function is available only during weighing. If

at any time the weighing units are changed, the accumulated data will be lost.

Manual Accumulation

When the scale is set to manual accumulation, the weight displayed will be stored in the memory when the

[Print] key is pressed and the weight is stable.

Steps :

Remove the weight and press [Print] when the display is at zero. The display

will show

"ACC 1"

and then the weight in memory for 2 seconds before returning

to normal. The weight can be output to a printer or PC using the RS-232 interface.

When the scale is at zero, place a second weight. When stable, press [Print] to accumulate the weight. The

display will show "

ACC 2"

for 2 seconds and then show the new total.

Continue until all weights have been added. This can continue for up to 99 entries until the capacity of display

is exceeded.

To view the total in memory, press the [Print] key when the scale is at zero. The display will show the total

number of accumulation

"ACC xx"

and the total weight before returning to zero.

To print the total, press [Print] to recall and then immediately press [Print] the second time to print the

results. To erase the memory, press [Print] to view the total and then immediately press [CE] to clear the

memory.

Automatic Accumulation

When the scale has been set to Automatic Accumulation the value will be stored in memory automatically.

Steps:

Place a weight on the platform. The beeper will sound when the display is stable indicating the value is

accepted. Remove the weight. The display will show

"ACC 1"

and then the total in the memory before it

returns to zero. Adding a 2nd weight will repeat the process.

While the weight is on the platform, press the [Print] key to view the values- first the accumulation number

"ACC x"

and then the total will be shown.

NOTE:

The scale must return to zero or a negative number, before another sample can be added to the

memory.

3.0 RS-232 INTERFACE

The CBK and CBK-M Series of scales include a bi-directional RS-232 interface.The scale when connected to

a printer or computer through the RS-232 interface, outputs the weight with the selected weighing unit.

Specifications:

Connector:

RS-232 output of weighing data

ASCII code

9600Baud rate(user selectable)

8 data bits

No Parity

9 pin d-subminiature socket

Pin 3 Output

Pin 2 Input

Pin 5 Signal Ground

4.0 PARAMETERS

Pressing the [Func] key allows the user to access the parameters for customising the scale. The parameters

are split into 3 groups- Check weighing parameters, RS-232 parameters and Scale parameters. Please find

the RS-232 parameters in complete manual.

When [Func] is pressed, display will first show

“FUnC 1”

for Check weighing parameters. Enter [2] for RS-232

parameters or [3] for Scale parameters or press the [Func] key to advance through the groups

“FUnC 1”,

“FUnC 2”

and

“FUnC ”

. Press [Tare] to enter the desired group of parameters.

Press [Zero] to return to the group

“FUnC 1”

. If you press [Zero] again, the scale will exit the User Parameter

section and return to normal weighing.

4.1 CHECK WEIGHING PARAMETERS

Shortcut to enter this group is to press and hold the [Func] key for 4 seconds. The display will go directly to

“FUnC 1”.

Press [Tare] to enter the group. Press [Func] to view the options for setting. Press [Tare] to

confirm the change and then advance to the next parameter by pressing the [Func] key.

Parameter Description Options Default

setting

F1 PCt

This parameter allows the user to

enter the Percent weighing Function.

See Section 10.7.

None Enabled

always

F2 LLk

This parameter prevents the normal

user from changing the limits with the

help of a Limit Lock.

With LLK set to Off (oFF), the

user is allowed to change limits

at any time.

With LLK set to Preset (PSt), the

user is allowed to use one of the

preset limits only.

oFF

F LEd

This parameter sets the LED

indicator to off or on and the LED

type (whether LED’s are on in the

form of a continuous bar or a spot

LED).

bAr - Bar type

Spot - Spot type

oFF - Off

bAr

F4 bEP

This parameter sets the Beeper to off

or on. If set to on, the beeper can

further be set to sound when the

weighing result is within or outside

the check-weighing limits.

bP oFF - Off

bP inL - Within limits

bP otL - Outside limits (>20d)

bP inL

F5 CPS

(Not available

in CBK-M)

This parameter allows setting of a

new Check weighing password, must

be entered twice when asked. When

complete, it will display “donE”.

To be entered manually.

0000

F6 Nck

(Not available

in CBK-M)

This parameter enables negative

check weighing function with ability to

do negative tare.

oFF

NOTE:

The Check weighing password is separate from the scale password, If the password is other than

0000, user must enter the password to gain access to

“F2 LLk”, “F LEd”, “F4 bEP”, “F5 CPS”

and “F6 nCK”.

Andere Handbücher für CBK series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Adam Equipment Skala Handbücher

Adam Equipment

Adam Equipment HIGHLAND SERIES Bedienungsanleitung

Adam Equipment

Adam Equipment NETS Produktinformationsblatt

Adam Equipment

Adam Equipment CBK series Bedienungsanleitung

Adam Equipment

Adam Equipment WBZ Series Bedienungsanleitung

Adam Equipment

Adam Equipment MTB Bedienungsanleitung

Adam Equipment

Adam Equipment ASC Bedienungsanleitung

Adam Equipment

Adam Equipment UG119 Bedienungsanleitung

Adam Equipment

Adam Equipment CCEU-20 Bedienungsanleitung

Adam Equipment

Adam Equipment PTS plus Series Bedienungsanleitung

Adam Equipment

Adam Equipment CBW Series Bedienungsanleitung

Adam Equipment

Adam Equipment Nimbus NBL Serie Bedienungsanleitung

Adam Equipment

Adam Equipment HIGHLAND SERIES Bedienungsanleitung

Adam Equipment

Adam Equipment CQT1751GR Bedienungsanleitung

Adam Equipment

Adam Equipment CFC SERIES Bedienungsanleitung

Adam Equipment

Adam Equipment CB 501 Bedienungsanleitung

Adam Equipment

Adam Equipment MUW Bedienungsanleitung

Adam Equipment

Adam Equipment 700660189 Bedienungsanleitung

Adam Equipment

Adam Equipment AGB Series Bedienungsanleitung

Adam Equipment

Adam Equipment HIGHLAND HCB 602M Bedienungsanleitung

Adam Equipment

Adam Equipment NETS ME Price Bedienungsanleitung

Adam Equipment

Adam Equipment CCSA series Bedienungsanleitung

Adam Equipment

Adam Equipment NBL 84 e/i Bedienungsanleitung

Adam Equipment

Adam Equipment Luna LAB Series Bedienungsanleitung

Adam Equipment

Adam Equipment Warrior Series Bedienungsanleitung

Beliebte Skala Handbücher anderer Marken

AWS

AWS ZEO-50 Bedienungsanleitung

Gima

Gima Glass Body Fat Analyzer Stücklistenhandbuch

Seca

Seca 374 Bedienungsanleitung

TEC

TEC TEC SL59 SERIES Bedienungsanleitung

Axis

Axis B/E Series Bedienungsanleitung

Alecto

Alecto ACW-40 Bedienungsanleitung

Rice Lake

Rice Lake MSI-4260 IS Bedienungsanleitung

IKA

IKA RCT basic safety control Bedienungsanleitung

ADE

ADE M20011 Bedienungsanleitung

Duronic

Duronic KS3000 Bedienungsanleitung

Digi

Digi SM-720 Bedienungsanleitung

Cardinal

Cardinal CS Series Bedienungsanleitung

Korona

Korona Kastella Bedienungsanleitung

A&D

A&D FC-50Ki Bedienungsanleitung

BDA

BDA CAMARGUE Bedienungsanleitung

Tanita

Tanita HD-357 Bedienungsanleitung

Leifheit

Leifheit 03173 Bedienungsanleitung

Lumme

Lumme LU-1340 Bedienungsanleitung
