Adaptec RAID

Installation Guide

COMBINED RAID IG.BOOK Page i Monday, September 17, 2001 4:30 PM

reproduced, stored in a retrieval system, or transmitted in any form or by any means,

electronic, mechanical, photocopying, recording or otherwise, without the prior

written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.

Trademarks

Adaptec and the Adaptec logo are trademarks of Adaptec, Inc., which may be

registered in some jurisdictions. Windows 95, Windows 98, Windows NT,

Windows Me, and Windows 2000 are trademarks of Microsoft Corporation in the US

and other countries, used under license. RAIDIOS is a trademark of Intel Corp.

All other trademarks are the property of their respective owners.

Changes

The material in this document is for information only and is subject to change

without notice. While reasonable efforts have been made in the preparation of this

document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from

errors or omissions in this document, or from the use of the information contained

herein.

Adaptec reserves the right to make changes in the product design without reservation

and without notification to its users.

Disclaimer

IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE

PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID

VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER

REMEDIES.

COMBINED RAID IG.BOOK Page ii Tuesday, September 25, 2001 5:46 PM

iii

Regulatory Compliance Statements

Federal Communications Commission Radio Frequency Interference Statement

WARNING: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy, and if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. However, if this equipment

does cause interference to radio or television equipment reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

• Use a shielded and properly grounded I/O cable and power cable to ensure compliance of this unit to the

specified limits of the rules.

This device complies with part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference and (2) this device must accept any

interference received, including interference that may cause undesired operation.

European Union Compliance Statement

This Information Technology Equipment has been tested and found to comply with the

following European directives:

EMC Directive 89/336/EEC, as amended by 92/31/EEC and 93/68/EEC

EN 50081-1 (1992)

EN55022 (1994) Class B

EN 50082-1 (1992)

EN61000-4-2 (1998)

EN61000-4-3 (1998)

EN61000-4-4 (1995)

EN61000-4-5 (1995) Surges

EN61000-4-6 (1996) Conducted immunity

EN61000-4-11 (1994) Supply dips of variation

Australian/New Zealand Compliance Statement

This device has been tested and found to comply with the limits for a Class B digital

device, pursuant to the Australian/New Zealand standard AS/NZS 3548 set out by the

Spectrum Management Agency.

Adaptec, Inc.

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

SCSI RAID2000S/2005S/ 2100S/2110S/

ATA RAID 2400A

3200S/3210S/3400S/3410S

COMBINED RAID IG.BOOK Page iii Tuesday, September 25, 2001 5:46 PM

Canadian Compliance Statement

This Class B digital apparatus meets all requirements of the Canadian Interference-

Causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le

matérial brouilleur du Canada.

Japanese Compliance (Voluntary Control Council Initiative)

COMBINED RAID IG.BOOK Page iv Tuesday, September 25, 2001 5:46 PM

Contents

1 Introduction

Read this First 1-1

System Requirements 1-2

Storage Requirements for Drivers and Software 1-2

Motherboard Compatibility 1-2

Kit Contents 1-3

Adaptec RAID Controller Features 1-3

Adaptec RAID Features – SCSI Only 1-4

About the Documentation 1-6

Using the Adaptec RAID Installation CD 1-6

Files and Folders 1-8

Product Documentation on CD 1-8

Errata and Release Notes 1-9

Installing the Adobe Acrobat Reader 1-9

Overview of the Installation Process 1-10

Cache Memory Module 1-11

Storage Management Software Overview 1-12

Safety Information 1-14

Notes, Cautions, and Warnings 1-14

Electrostatic Discharge 1-14

2 Installing Your Controller

Configuring ATA Drives 2-1

ATA Drives 2-1

ATA Cables 2-2

Configuring SCSI Devices 2-2

Narrow and Wide SCSI Devices 2-2

LVD and SE Devices 2-3

SCSI Cables 2-3

SCSI Device IDs 2-3

SCSI Termination 2-4

Installing Additional Cache Memory 2-6

COMBINED RAID IG.BOOK Page v Tuesday, September 25, 2001 5:46 PM

Adaptec RAID Installation Guide

Seating the Module – Adaptec 3200S/3400S Only 2-7

Seating the Module – Adaptec 2400A/2100S/3210S/3410S

Only 2-8

Installing the Battery Backup Module 2-8

Finishing up – All Models 2-9

Installing the Controller 2-9

Zero Channel RAID Controllers (2000S, 2005S) 2-10

Determining the Booting Controller 2-10

Controller IRQ and Address 2-11

Using SMOR 2-11

3 Installing the Driver

Windows 2000 3-2

Installing the Driver in a New System 3-2

Adding the Controller to an Existing System 3-4

Upgrading Windows NT to Windows 2000 3-5

Windows NT 4.0 3-6

Installing the Driver in a New System with Only One

Controller 3-7

Installing the Driver in a New System with Other

Hardware 3-8

Upgrading the Controller in an Existing System 3-9

Changing the Driver in an Existing System 3-10

Windows95,Windows98,andWindowsMe 3-11

Creating the Driver Disk 3-12

Installing the Driver in a New Windows 98/Me

System 3-13

Installing the Driver in a New System with Windows 95

(OEM SR2 – Version 95B) 3-15

Adding the Controller to an Existing Windows 95/98/

Me System 3-17

Upgrading Windows 95 to Windows 98/Me (Upgrade

Version) 3-19

Novell NetWare 3-19

Installing the Driver for a Boot Controller in a New

NetWare 4.11 Server 3-20

Installing the Driver in a Existing NetWare 4.11

Server 3-21

COMBINED RAID IG.BOOK Page vi Tuesday, September 25, 2001 5:46 PM

vii

Contents

Installing the Driver for a Boot Controller in a New

NetWare 4.2 Server 3-22

Installing the Driver in an Existing NetWare 4.2

Server 3-24

Installing the Driver for a Boot Controller in a New

NetWare 5 Server 3-25

Installing the Driver in an Existing NetWare 5

Server 3-26

SCO UNIX 3-27

Installing the Driver in a New OpenServer 5.0x

System 3-27

Adding the Controller to an Existing OpenServer 5.x

System 3-28

Adding the Controller to an Existing UnixWare 7

System 3-29

FreeBSD 3-30

Linux 3-31

Installing the Driver in a New Linux System 3-31

Installing the Driver in an Existing Linux System 3-33

4 Installing Storage Management Software

System Requirements 4-2

Installing Storage Manager Pro 4-2

Operating System Compatibility 4-2

Installation Prerequisites 4-3

Windows 4-3

NetWare 4.11 and 4.2 4-4

NetWare 5.x 4-6

Red Hat Linux and FreeBSD 4-7

Installing Storage Manager 4-8

Operating System Compatibility 4-8

Windows 4-8

NetWare 4-9

SCO UNIX 4-10

SCO UnixWare 7 4-10

FreeBSD 4-10

Linux 4-11

COMBINED RAID IG.BOOK Page vii Tuesday, September 25, 2001 5:46 PM

viii

Adaptec RAID Installation Guide

A Card and Module Diagrams

Adaptec ATA RAID 2400A A-2

Adaptec SCSI RAID 2000S A-3

Adaptec SCSI RAID 2005S A-4

Adaptec SCSI RAID 2100S A-5

Adaptec SCSI RAID 2110S A-6

Adaptec SCSI RAID 3200S A-7

Adaptec SCSI RAID 3400S A-8

Adaptec SCSI RAID 3210S/3410S A-9

Adaptec Battery Backup Module - ABM-100 A-11

Adaptec Battery Backup Module - ABM-200 A-12

B Controller LEDs

LED During Power-up B-2

LEDs During Controller Idle B-2

LEDs During Controller Active B-2

Cache Status LEDs B-3

Cache Status LEDs – Adaptec 2400A/3200S/3400S

Only B-3

Cache Status LED – Adaptec 3210S/3410S Only B-4

SCSI Bus Status LEDs B-4

SCSI Bus Status LEDs – Adaptec 3200S/3400S Only B-4

SCSI Bus Status LEDs – Adaptec 3210S Only B-4

SCSI Bus Status LEDs – Adaptec 3410S Only B-5

C Troubleshooting

D Controller Reset Procedures

NVRAM Reset D-2

Flash Mode 0 D-2

E Specifications

COMBINED RAID IG.BOOK Page viii Tuesday, September 25, 2001 5:46 PM

1-1

Introduction

In this Chapter

Read this First

Before you begin installing your new Adaptec RAID controller, read

this chapter. This chapter is an important guide to the rest of the

documentation and provides a summary of the installation process.

➤ Read this First 1-1

➤ System Requirements 1-2

➤ Kit Contents 1-3

➤ Adaptec RAID Controller Features 1-3

➤ About the Documentation 1-6

➤ Using the Adaptec RAID Installation CD 1-6

➤ Installing the Adobe Acrobat Reader 1-9

➤ Overview of the Installation Process 1-10

➤ Cache Memory Module 1-11

➤ Storage Management Software Overview 1-12

➤ Safety Information 1-14

COMBINED RAID IG.BOOK Page 1 Tuesday, September 25, 2001 5:46 PM

1-2

Adaptec RAID Installation Guide

System Requirements

The following system requirements are discussed:

■Storage requirements for drivers and software

■Motherboard compatibility

■ATA requirements – Adaptec 2400A only

■

SCSI requirements –

Adaptec 2000S/2005S/2100S/2110S/3200S/

3210S/3400S/3410S only

Storage Requirements for Drivers and Software

Adaptec Storage Management software and device drivers require

approximately 4 MB of disk space. The host system should have

64 MB of memory, and a Pentium processor that is at least as fast as

200 MHz. A mouse and SVGA color monitor are also required.

Adaptec Storage Manager Pro requires 40 MB of available disk space

for installation. The host system should have 64 MB of memory, a

Pentium processor (200 MHz or faster), and a video adapter capable

of 800 ×600 resolution with 256 colors.

Motherboard Compatibility

The Adaptec controller requires a motherboard BIOS that:

■

Complies with the

PCI Local Bus Specification

(revisions 2.1 and 2.2).

■Supports multifunction devices where one of the devices is a

PCI bridge.

■Provides large memory-mapped address ranges.

Most motherboards manufactured since 1997 have these

capabilities. For information about any known compatibility issues,

refer to the README file on the Adaptec RAID Installation CD.

The zero channel Adaptec 2000S and 2005S controllers provide

advanced RAID functionality to server motherboards incorporating

onboard Adaptec SCSI and Embedded RAID Logic (EMRL) or

RAIDIOS™ logic. The 2000S is designed to work in one of the

supported EMRL- or RAIDIOS-enabled PCI slots. The 2005S plugs

into a specially-designed SO-DIMM PCI connector, present only on

specific motherboards.

COMBINED RAID IG.BOOK Page 2 Tuesday, September 25, 2001 5:46 PM

Andere Handbücher für 2025ZCR - SCSI RAID Storage Controller

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Adaptec Computerhardware Handbücher

Adaptec

Adaptec PM2865U3 Bedienungsanleitung

Adaptec

Adaptec 2940U2W - Storage Controller U2W SCSI 80... Bedienungsanleitung

Adaptec

Adaptec SAS RAID Controllers Bedienungsanleitung

Adaptec

Adaptec ASR-3085 Betriebsanleitung

Adaptec

Adaptec PowerDomain 29160 Bedienungsanleitung

Adaptec

Adaptec ARO-1130CA Montageanleitung

Adaptec

Adaptec RAID 2405 Bedienungsanleitung

Adaptec

Adaptec SATA RAID FOR ADAPTEC Bedienungsanleitung

Adaptec

Adaptec FireWire 1394 Bedienungsanleitung

Adaptec

Adaptec CDP-00277-01-A Bedienungsanleitung

Adaptec

Adaptec RAID 5405 Bedienungsanleitung

Adaptec

Adaptec SCSI 58300 Bedienungsanleitung

Adaptec

Adaptec ASR-2130SLP Anleitung zur Verwendung

Adaptec

Adaptec ASA-7211C Bedienungsanleitung

Adaptec

Adaptec AAA-130U2 SERIES Montageanleitung

Adaptec

Adaptec 2010S - SCSI RAID Storage Controller Bedienungsanleitung

Adaptec

Adaptec ACB-5500 Bedienungsanleitung

Adaptec

Adaptec RAID Solutions Handbuch

Adaptec

Adaptec 2100S - SCSI RAID Controller Bedienungsanleitung

Adaptec

Adaptec PM3332UW Bedienungsanleitung

Adaptec

Adaptec AAR-1420SA Bedienungsanleitung

Adaptec

Adaptec PM1564U3 Bedienungsanleitung

Adaptec

Adaptec RAID 51245 Anleitung zur Verwendung

Adaptec

Adaptec AAA-130SA SERIES Montageanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
