AddBike Carry'Box Module Handbuch
Non-contractual Photographs
User's and Installation Guide
Carry’Box Module
November 2019
Applicable to the AddBike and AddBike+
This document indicates the correct practices to be respected during use and assembly /
disassembly of the module Carry’Box. It is imperative to read this document entirely in order to
keep your bike, your AddBike, and your Carry’Box in good working conditions for as long as
possible.
Please keep this document.
Child
Groceries
Loads
Your Bike
The AddBike
A reversible cargo bike
2VERSION V4.1
The AddBike is an innovative solution that transforms your bike into a practical, easy to
handle cargo bike. It consists of a two-wheeled base that allows the transportation of
loads and the installation of modules specifically designed for the AddBike. These
modules give your bike the capacity to carry bulkier loads, groceries or a child.
Welcome to the big family of AddBikers!!
There is no need to invest in expensive and large cargo bicycles. With the AddBike you
can quickly and easily turn your own bike into a compact cargo bike.
This document concerns only the module Carry’Box and is complementary to the
“AddBike User's and Installation Guide”.
This module is compatible with the AddBike and the AddBike+
Maximum capacities
Carry’Box
35 kg
Dimensions (LxWxH in cm)
Carry’Box useful volume
40*45*62 –110 L
Size of the Addbike + Carry’Box
68*70*90
VERSION V4.1 3
Table of contents
1. General warning.......................................................................................................................................4
2. Lexicon of the Carry’Box module......................................................................................................5
3. Content of the Carry’Box parcel........................................................................................................6
4. Installing the Carry’Box.........................................................................................................................6
5. Using the Carry’Box module............................................................................................................14
6. Uninstalling the Carry’Box module...............................................................................................14
7. Cleaning....................................................................................................................................................15
8. Guarantee Charter................................................................................................................................15
9. Assistance in case of problem ........................................................................................................15
4VERSION V4.1
1. General warning
Symbols and warnings:
WARNING! This symbol indicates a hazard that could result in serious injury if
the instructions are not followed.
CAUTIONING!
This symbol indicates a hazard that may result in minor injury if the instructions
are not followed
ADVICE! This symbol indicates advice for the use or maintenance of your
AddBike.
Before installing this module on your AddBike, make sure you have read and understood the »
AddBike User's and Installation Guide ».
Read and follow the instructions in this guide: Read the entire guide carefully and follow the
instructions to use the Carry’Box module safely. If you do not understand certain indications, please
contact your AddBike dealer or contact AddBike directly at: support@addbike.fr. Please keep this
manual for future reference. It is also important to take into account the directions for use of the
AddBike and that of the bike receiving the AddBike.
The AddBike Company disclaims all liability in case of non-compliance with the instructions in this
User's and Installation Guide of the Module Carry’Box and in case of modification of the product by
the user.
Using the Carry’Box module
The Carry’Box module is designed to be used on the AddBike produced by our company. Do not
try to install or use this module on other cargo bikes or on a classic bike.
The Carry’Box module is not designed to be stored outdoors for prolonged periods. It must be
stored in a dry and temperate place away from corrosive products.
VERSION V4.1 5
2. Lexicon of the Carry’Box module
Figure 1 –Lexicon of the Carry'Box module
Transerve tube
Upper tubes
Front
tubes
Compact slat
Front tubes
Compact slat
Transverse
tube
Upper
tubes
6VERSION V4.1
3. Content of the Carry’Box parcel
The Carry’Box is delivered in a parcel containing:
•A compact slat ;
•The textile part of the module (white bin);
•The textile lid of the module (yellow);
•2 upper tubes ;
•2 front tubes ;
•1 transverse tube ;
•2 screws BHC M5x30 ;
•4 screws BHC M5x30 with the 4 corresponding nuts;
•This manual for the Carry’Box V4.1. module
Before assembling the Carry’Box module on your bike, please verify the following:
•Check that the product is in good general condition (no scratches or twisted pieces).
4. Installing the Carry’Box
The Carry’Box module must be installed and uninstalled as explained. Improper
installation can lead to accidents that could cause serious injury.
We advise you to add the Carry’Box module to your AddBike only when the
latter is properly installed on your bike so as to make it easier to assembly
For the installation you will need an Allen wrench size 3, and an open-end wrench 8 (Cf. Figure 2).
Open-end wrench (size 8) Allen wrench (size 3)
Figure 2 –Tools needed
VERSION V4.1 7
•Screw the provided compact slat to the lower front tubes with the 4 screws BHC M5x30 and
corresponding nuts. You should end up with a set as shown in figure 1;
Figure 3 –Fixing the compact slat to the lower tubes
•Remove the screws, nuts and plastic cap from both sides of the compact plate of the
AddBike’s seat. Also remove the screws, nuts and plastic cap from both sides of the highest
compact plate of the AddBike’s backrest;
Figure 4 –Screws and plastic caps to be removed
During this step, if your AddBike isn't equipped with 4 plastic caps at the 4 bar
ends of the backrest and base structure (at the level of the connection sleeve),
the only preparation to install the bars is to remove the screws at each bar end
(screw without nut). Once the bars are inserted as shown below, tighten the
screws (screw without nut).
Screws and nuts to be removed
Plastic caps to be removed
Screws and nuts to be removed
8VERSION V4.1
•Insert the front tubes into the holes of the seat and line up the screw holes of both parts;
Figure 5 - Insertion of bottom tubes into the seat
•Put back the screws and nuts previously removed from the seat (but not the plastic
caps) making them pass through the holes on the front tubes;
Figure 6 –Screws and nuts to be put back on the seat
Make sure to keep in a safe place the 4 plastic caps removed during the previous
step.
VERSION V4.1 9
•Install the textile :
oThe front tubes slip on the black textile sheaths
oThe rear of the textile is positioned simply in front of the backrest
Figure 7 - Insertion of the textile
10 VERSION V4.1
•At the back of the module, attach the six Velcro straps of the textile on the Addbike’s backrest;
Tighten the fabric on each side, centering very well the textile on the backrest
Figure 8 –Fastening the back of the textile
