Advance Technologies; Automate the World.

Manual Rev. 2.00

Revision Date: April 14, 2005

Part No: 50-15039-1000

PCI-3488

IEEE488 GPIB Interface Card

User’s Manual

The information in this document is subject to change without prior

notice in order to improve reliability, design, and function and does

not represent a commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, spe-

cial, incidental, or consequential damages arising out of the use or

inability to use the product or documentation, even if advised of

the possibility of such damages.

This document contains proprietary information protected by copy-

right. All rights are reserved. No part of this manual may be repro-

duced by any mechanical, electronic, or other means in any form

without prior written permission of the manufacturer.

Trademarks

Product names mentioned herein are used for identification pur-

poses only and may be trademarks and/or registered trademarks

of their respective companies.

Getting Service from ADLINK

Customer Satisfaction is top priority for ADLINK Technology Inc.

Please contact us should you require any service or assistance.

ADLINK TECHNOLOGY INC.

Web Site: http://www.adlinktech.com

Sales & Service: [email protected]

TEL: +886-2-82265877

FAX: +886-2-82265717

Address: 9F, No. 166, Jian Yi Road, Chungho City,

Taipei, 235 Taiwan

Please email or FAX this completed service form for prompt and

satisfactory service.

Company Information

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL FAX:

Web Site

Product Information

Product Model

Environment

OS:

M/B: CPU:

Chipset: Bios:

Please give a detailed description of the problem(s):

Table of Contents i

Table of Contents

1 Introduction ........................................................................ 1

Performance ................................................................... 1

Compatibility ................................................................... 1

1.1 Features............................................................................... 2

1.2 Specifications....................................................................... 2

GPIB Bus Properties ....................................................... 2

Certificates ...................................................................... 2

General Specifications .................................................... 3

1.3 Software Support ................................................................. 3

2 Installation .......................................................................... 5

2.1 Contents of Package .......................................................... 5

2.2 Unpacking........................................................................... 6

2.3 Mechanical Drawing ............................................................ 7

2.4 PCI Configuration ................................................................ 8

Plug and Play ................................................................. 8

Configuration .................................................................. 8

Trouble shooting ............................................................. 8

2.5 Hardware Installation ........................................................... 9

Installation Procedures ................................................... 9

Cabling ........................................................................... 9

2.6 Software Installation .......................................................... 11

Driver installation .......................................................... 11

Using VISA ................................................................... 13

Using the ADLIINK GPIB Utility .................................... 21

3 Operation Theory ............................................................. 25

3.1 Connection Configuration .................................................. 25

Data Lines .................................................................... 27

Handshake Lines .......................................................... 27

System management lines ........................................... 27

3.2 PCI-3488 Block Diagram ................................................... 28

ii List of Tables

List of Tables

Table 1-1: Power Requirements ................................................ 3

Table 3-1: GPIB Bus ................................................................ 26

List of Figures iii

List of Figures

Figure 2-1: PCB layout of the PCI-3488 ...................................... 7

Figure 2-2: Linear Connection Configuration ............................. 10

Figure 2-3: Star Connection Configuration ................................ 10

Figure 3-1: Standard GPIB Connector....................................... 25

Figure 3-2: PCI-3488 Block Diagram ......................................... 28

Introduction 1

1 Introduction

ADLINK’s PCI-3488 GPIB controller interface card, fully compati-

ble with the IEEE488.2 instrumentation control and communica-

tion standard, is capable of controlling up to 14 stand-alone

instruments via IEEE488 cables. It is designed to meet the

requirements for high performance and maximum programming

portability. The 1KB on-board FIFO and a block transfer mode pro-

vide up to 1.5MB/s GPIB transfer rate. With an NI-like driver API

and VISA support, the PCI-3488 provides the greatest compatibil-

ity with your existing applications and instrument drivers.

Performance

ADLINK’s expertise in PCI interface cards was leveraged when

developing this newly designed GPIB controller. The PCI-3488

supports both 3.3V and 5V PCI buses and can be adapted to most

industrial and desktop computers. On-board 1KB FIFO is placed

between the GPIB bus and PCI controller to buffer GPIB read/

write operations. The FIFO eliminates the gap between the slow

GPIB bus (~1.5MB/s) and the fast PCI bus (132MB/s), and dra-

matically increases overall system performance.

Compatibility

ADLINK’s PCI-3488 is delivered with complete software support,

including a driver API that is fully binary compatible with NI’s

GPIB-32.DLL. All programs written based on GPIB-32.DLL can be

executed on the PCI-3488 without any modification. VISA library is

also supported to ensure compatibility with applications utilizing

VISA. The ADLINK PCI-3488 provides the “Plug and Play” com-

patibility with all your existing applications.

2Introduction

1.1 Features

The PCI-3488 IEEE 488 GPIB interface card provides the follow-

ing advanced features:

XFully compatible with the IEEE 488 standard

XSupports a 32-bit 3.3V or 5V PCI bus

XUp to 1.5MB/s data transfer rates

XOn-board 1KB FIFO for read/write operations

XProvides NI-like driver API & VISA support

XInteractive utility for testing and diagnostics

XCompact, half-size PCB

1.2 Specifications

GPIB Bus Properties

XUp to 14 instruments can be connected to one controller

XMaximal 1.5 MB/s data transfer rate

XCable length

Z2 meters between each instrument (suggested)

Z20 meters total cable length

XData transfer mode: 8 bits parallel

XHandshake: 3 wire handshake, reception of each data byte

is acknowledged

Certificates

XEMC/EMI: CE, FCC Class A
