ADT SafeWatch 3000 Bedienungsanleitung

K5309 3/01 Model SASW3000B

6DIHZDWFK3UR

6HFXULW\0DQDJHU

6HFXULW\6\VWHPV

8VHU·V*XLGH

– 2 –

IMPORTANT!

PROPER INTRUSION PROTECTION

For proper intrusion coverage, sensors should be located at

every possible

point of entry

to a home or commercial premises. This would include any

skylights that may be present, and the upper windows in a multi-level building.

In addition, we recommend that radio backup be used in a security system so

that alarm signals can still be sent to the Customer Care Center in the event

that the telephone lines are out of order (alarm signals are normally sent over

the phone lines).

EARLY WARNING FIRE DETECTION

Early warning fire detection is important in a home. Smoke and heat detectors

have played a key role in reducing fire deaths in the United States. With regard

to the number and placement of smoke/heat detectors, we subscribe to the

recommendations contained in the National Fire Protection Association's

National Fire Alarm Code (NFPA 72). These recommendations can be found on

page 34 of this manual.

$ERXW7KLV0DQXDO

This manual is a step-by-step guide that will acquaint you with the system's

features and benefits. It defines the components and their functions, describes

their operation, and provides clear step-by-step instructions for normal and

emergency procedures. Keep this manual in a convenient place so that you can

refer to it as necessary.

– 3 –

7DEOHRI&RQWHQWV

System Overview.................................................................................................................... 5

Introduction.......................................................................................................................... 5

System Basics....................................................................................................................... 5

About The Touchpads ........................................................................................................... 8

General Information.............................................................................................................8

Functions of the Touchpads..............................................................................................10

Entry/Exit Delays.................................................................................................................12

Exit Delay ........................................................................................................................... 12

Entry Delay......................................................................................................................... 12

Exit Alarms......................................................................................................................... 13

Checking For Open Zones..................................................................................................13

Using the [∗] Key................................................................................................................ 13

Arming the System ..............................................................................................................14

Stay Mode: Arms Perimeter Only, Entry Delay On......................................................... 14

Night-Stay Mode: Arms Perimeter Only, Plus Selected Zones....................................... 14

Instant Mode: Arms Perimeter Only, Entry Delay Off.................................................... 14

Away Mode: Arms Entire System, Entry Delay On......................................................... 14

Arming Commands............................................................................................................. 15

Single Button Arming........................................................................................................ 16

Single-Button “Step” Arming............................................................................................. 16

Using the Keyswitch............................................................................................................ 17

Using the Keyswitch .......................................................................................................... 17

Disarming and Silencing Alarms .....................................................................................18

Using the [OFF] key........................................................................................................... 18

Bypassing Protection Zones..............................................................................................19

Using the BYPASS Key ..................................................................................................... 19

Quick Bypass...................................................................................................................... 20

Chime Mode...........................................................................................................................20

Viewing Current Date and Time......................................................................................21

Viewing the Current Date and Time................................................................................. 21

Setting the Date and Time................................................................................................. 21

Panic Keys .............................................................................................................................22

Using Panic Keys................................................................................................................22

– 4 –

7DEOHRI&RQWHQWV

Macro Key Programming & Usage ..................................................................................23

About Macro Keys .............................................................................................................. 23

Example of Macro Programming....................................................................................... 24

Using a Programmed Macro Key ...................................................................................... 24

Using Device Commands....................................................................................................25

Paging Feature.....................................................................................................................26

About Automatic Paging.................................................................................................... 26

Single Button Paging ......................................................................................................... 27

Latch Key Paging ............................................................................................................... 27

Security Codes & Authority Levels .................................................................................28

About Security Codes......................................................................................................... 28

Authority Level Definitions............................................................................................... 28

To assign User Codes and Attributes................................................................................ 29

Accessing Other Partitions (GOTO Command and Multi-Partition Arming)......30

About Accessing Partitions................................................................................................ 30

Using the GoTo Command................................................................................................. 31

Multi-Partition Arming...................................................................................................... 31

Common Zone Operation ................................................................................................... 32

Scheduling .............................................................................................................................33

About Scheduling ............................................................................................................... 33

Creating Schedules............................................................................................................. 33

Event Logging Procedures ................................................................................................35

About Event Logging.......................................................................................................... 35

Viewing the Event Log....................................................................................................... 35

Testing the System (To Be Conducted Weekly)............................................................ 36

Trouble Conditions..............................................................................................................37

Maintaining Your System ..................................................................................................40

Fire Alarm System (If Installed).......................................................................................41

Quick Guide to Basic System Functions........................................................................45

Summary of Audible/Visual Notifications .....................................................................46

Regulatory Statements and Warnings............................................................................48

Charts of Your System's Features.................................................................................... 50

– 5 –

6\VWHP2YHUYLHZ

,QWURGXFWLRQ

Congratulations on your ownership of an ADT Partitioned Security System. You've

made a wise decision in choosing it, for it represents the latest in security protection

technology today, and millions of premises are protected by ADT systems.

This system provides:

•Three forms of protection: burglary, fire* and emergency.

•At least one touchpad which provides control of system operation and displays

the system’s status

•Various sensors for perimeter and interior burglary protection

•Smoke or combustion detectors* designed to provide early warning in case of fire.

Your system may also have been programmed to automatically send alarm or status

messages over the phone lines to a Customer Care Center.

* Commercial installations and some residential systems may not include fire

protection – check with your installer.

6\VWHP%DVLFV

Burglary Protection

•There are four modes of burglary protection: Stay, Night-Stay, Away, Instant.

STAY: arms perimeter zones only and entry delay is on

INSTANT: same as STAY, except entry delay is off

NIGHT-STAY: arms perimeter zones and selected interior zones; entry delay on

AWAY: arms perimeter and all interior zones, entry delay is on

•You can BYPASS selected zones while leaving the rest of the system armed.

•CHIME mode alerts you to the opening of protected doors and windows while the

system is disarmed.

Fire Protection

•Fire protection is always active (if installed) and an alarm sounds if a fire

condition is detected

•If necessary, you can manually initiate a fire alarm using the touchpad.

•Refer to the Fire Alarm System section for information regarding fire protection,

smoke detectors and planning emergency exit routes.

Security Codes

•You were assigned a 4-digit security code during system installation.

•Use your security code when arming and disarming the system, and when

performing other system functions.

•Other users can be assigned different security codes.

•User codes can be assigned different authority levels, which define which system

functions a particular user can perform.

– 6 –

6\VWHP2YHUYLHZ&RQWLQXHG

Zones and Partitions

•The system sensing devices have been assigned to various “zones,” which are

specific areas of protection (e.g., front door, kitchen window, etc.).

•Zone numbers are displayed at the touchpad when an alarm or trouble condition

occurs on a sensor.

•Partitions provide two independent areas of protection, with each partition

containing a group of zones that can be armed and disarmed without affecting

other zones or users.

•Partitioned systems can include a common zone area, which is an area shared by

users of both partitions (such as a lobby in a building).

•Partition identification: 1 = partition 1; 2 = partition 2; 3 = common zone.

Arming, Step-Arming and Disarming Burglary Protection

•The system must be armed before the burglary protection; can sense intrusions.

•To arm your system, enter your user code followed by the desired arming key.

•You can also use the step-arming key to arm the system, if programmed.

•To disarm the system, enter your user code then press the [OFF] key.

•Step-arming, if programmed, lets you use a function key to arm the system in one

of three modes by simply pressing the key repeatedly, where:

first press arms STAY; second press arms NIGHT-STAY; third press arms

AWAY.

Alarms

•When an alarm occurs, both the touchpad and external sounders will sound, and

the touchpad will display the zone(s) causing the alarm.

•If your system is connected to a Customer Care Center, an alarm message will

also be sent.

•To stop the alarm sounding, simply disarm the system.

Memory of Alarm

•When an alarm condition occurs, the touchpad displays the number(s) of the

zone(s) that caused the problem, and displays the type of alarm.

•The message remains displayed even after disarming the system, but can be

cleared with another “off” sequence.

– 7 –

6\VWHP2YHUYLHZ&RQWLQXHG

Phone Access

•If included, a phone module permits you to access the system via a touch-tone

phone, either on-premises or by call-in when away.

•You can receive synthesized voice messages over the telephone regarding the

status of the security system.

•You can arm and disarm the system and perform most function commands

remotely via the telephone, with voice confirmation provided after each command

entry.

•Complete information regarding the use of this feature is provided in a separate

manual entitled “Phone Access User's Guide” that is supplied with the voice

module.

Paging Feature

•If programmed, up to four pagers can automatically display certain system

conditions as they occur in your system.

•The display consists of code numbers that indicate the type of condition that has

occurred.

Function Keys

•The “A”, “B”, “C”, and “D” keys on the touchpad can be programmed to perform

various functions.

•Functions include: activate a Panic alarm; arm the system; provide step arming;

switch lights on/off; send a message to a pager; display Time/Date; start a Macro

Scheduling

•Your system can be programmed to automatically perform certain functions (e.g.,

arm the system) at a predetermined time each day.

– 8 –

$ERXW7KH7RXFKSDGV

*HQHUDO,QIRUPDWLRQ

Your touchpads allow you to control all system functions. The touchpads feature the

following:

•A telephone style (digital) keypad

•Liquid Crystal Display (LCD) which shows the nature and location of all

occurrences

•Built-in sounder which will sound during alarms and troubles. The sounder also

"beeps" during certain system functions and when depressing any of the keys (to

acknowledge the key press).

•Backlighting of the LCD display windows. Backlighting turns on when entering the

premises through any assigned entry/exit door, or when any touchpad key is

pressed. This feature is helpful when a touchpad is located in a dimly lit area.

IMPORTANT: If the touchpad beeps rapidly upon entering the premises, it indicates

that an alarm has occurred during your absence and an intruder may still be on the

premises. LEAVE IMMEDIATELY and CONTACT THE POLICE from a nearby safe

location.

There are two basic types of touchpads which are functionally the same, but they

have different types of displays.

Custom English Display 2-line Custom English display touchpads feature a 2-line,

32-character alphanumeric LCD which can display system

messages in friendly English. These touchpads can also be

programmed with custom zone descriptors. To access the

keys on the touchpad, simply open the swing-down door.

English Display English display touchpads are functionally identical to

Custom English display touchpads, but the LCD display

uses pre-designated words to identify the nature and

location of occurrences. To access the keys on the touchpad,

simply open the swing-down door.

– 9 –

$ERXW7KH7RXFKSDGV&RQWLQXHG

(QJOLVK'LVSOD\7RXFKSDG

AWAY: All burglary zones, interior and

perimeter, are armed.

STAY: Perimeter burglary zones, such as

protected windows and doors, are

armed.

INSTANT: Perimeter burglary zones armed

and entry delay is turned off.

ALARM

FIRE

AWAY

BYPASS

STAY

CHECK INSTANT

NO AC

TEST

NOT READY

CHIME BAT

ENGLISH DISPLAY TOUCHPAD

BYPASS: This appears when one or more burglary protection zones have been

bypassed.

NOT READY: Appears when burglary portion of the system is not ready for arming

(due to open protection zones). The system is ready to arm when this

message disappears and the READY indicator light comes on.

NO AC: Appears when AC power has been cut off. System is operating on

backup battery power.

AC: Appears when AC power is present.

CHIME: Appears when the CHIME feature is activated.

BAT: Low battery condition in a wireless sensor (if zone number displayed)

or low system battery (if no zone number displayed).

ALARM: Appears when an intrusion has been detected and the system is armed

(also appears during a fire alarm or audible emergency alarm).

Accompanied by the protection zone in alarm.

CHECK: Appears when a malfunction is discovered in the system at any time or

if an open is detected in a FIRE zone at any time or a fault in a

DAY/NIGHT burglary zone during a disarmed period. Accompanied by

a display of zone number in trouble.

FIRE:Appears when a fire alarm is present. Accompanied by a display of the

zone in alarm.

A FIRE display, accompanied by a display of zone 95, also appears

when a fire alarm is manually activated.

– 10 –

)XQFWLRQVRIWKH7RXFKSDGV

1. DISPLAY WINDOW.

Custom English Display Touchpads: 2-

line, 32-character Liquid Crystal Display

(LCD) touchpads that display protection point

identification, system status, and messages.

English Display Touchpads: Display

protection zone ID and system status

messages using pre-designated words in the

LCD display.

2. 1 OFF Disarms burglary portion of the

system, silences alarms and audible trouble

indicators, and clears visual display after

problem's correction.

3. 2 AWAY Arms the entire burglary system,

perimeter and interior.

4. 3 STAY Arms perimeter portion of burglary

system only. Interior protection is not armed,

allowing movement within premises

without causing an alarm.

5. 4 This is not a Function key. Used

only as a numeric key.

6. 5TEST Tests the system and alarm

sounder if disarmed. Refer to Testing The

System section for test procedures.

7. 6BYPASS Removes individual protection

zones from being monitored by the system.

8. 7INSTANT Arms in manner similar to the

STAY mode, but without the entry delay

feature. Entering via an entry/exit door will

cause an instant alarm.

9. 8CODE Used to assign additional user

codes for other users of the system.

10. 9 CHIME Turns CHIME mode on and off.

When on, the opening of windows or doors

while the system is disarmed will sound 3

beeps at the touchpad(s).

11. ✱READY Used to display all open protection

zones.

12. #This key can be used for "Quick

Arming" of the system without use of a

security code (if programmed).

13. KEYS 0–9†:Used to enter your security

code(s).

14. READY INDICATOR: (GREEN) Lit when

the system is ready to be armed (no faults

present). While the system is disarmed, this

indicator will go on and off as protection

zones are closed and opened.

15. ARMED INDICATOR: (RED) Lit when the

system has been armed.

16. INTERNAL SOUNDER: The built-in

sounder mimics the alarm sounder during

alarms, and will also "beep" during certain

system functions.

17. FUNCTION KEYS: Keys A, B, C, D may

have been programmed for a variety of

functions, including panic (emergency)

functions. For details, see the Function Keys

section.

†Note: Keys 1 OFF through 3 STAY and 2 AWAY through 7INSTANT each perform their

associated companion system functions (OFF, STAY, AWAY, INSTANT, etc.) when

preceded by an entry of the security code (as described later).

Andere Handbücher für SafeWatch 3000

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere ADT Sicherheitssystem Handbücher

ADT

ADT Security System D7412 Bedienungsanleitung

ADT

ADT Security System 4112 Bedienungsanleitung

ADT

ADT ADTHYBWL Series Bedienungsanleitung

ADT

ADT DSC Impassa Bedienungsanleitung

ADT

ADT IGB-02 Bedienungsanleitung

ADT

ADT EZ Montage- und Bedienungsanleitung

ADT

ADT Safewatch QuickConnect Plus Betriebsanleitung

ADT

ADT Safewatch Pro 3000 Bedienungsanleitung

ADT

ADT On-The-Go Emergency Response System Bedienungsanleitung

ADT

ADT ADT2X16AIO Montageanleitung

ADT

ADT On-The-Go Emergency Response System Bedienungsanleitung

ADT

ADT Safewatch Pro 2000 Bedienungsanleitung

ADT

ADT 3G Cellular Medical Alert System Bedienungsanleitung

ADT

ADT Safe-N-Go Bedienungsanleitung

ADT

ADT FOCUS CADET Bedienungsanleitung

ADT

ADT SA10ADTEG Betriebsanleitung

ADT

ADT Safewatch Pro 3000EN Montageanleitung

ADT

ADT 6160VPADT Montageanleitung

ADT

ADT Smart Home PM360 Bedienungsanleitung

ADT

ADT SECURITY MANAGER 2000 Bedienungsanleitung

ADT

ADT Safewatch Quick Connect Plus Bedienungsanleitung

ADT

ADT Garda Response PM30 Bedienungsanleitung

ADT

ADT Commercial Fire & Burglary Alarm System FOCUS 200... Bedienungsanleitung

ADT

ADT Safewatch QuickConnect Plus Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
