INSTALLATION AND OPERATING MANUAL

200W C-Band Hub-mount

SOLID STATE POWER BLOCK UP-CONVERTER (SSPB)

SSPBMg–C200–BRE

PM GR0-3161A0-3N0R, Rev. 5

SSPBMg-C200-BRE

WARRANTY

This Advantech Wireless product is warranted against defects in material and workmanship for a

period of 2 years from date of shipment. During the warranty period, Advantech Wireless will, at

its option, either repair or replace products that will prove to be defective.

To return a product for warranty or repair service, you must first request a Return Material

Authorization (RMA) number by contacting Advantech Wireless at:

Phone: (514) 420-0045 or Fax: (514) 420-0073

Website: www.advantechwireless.com or e-mail: support@advantechwireless.com

The unit should be shipped to the following address, in original shipping container (box), with

shipping charges prepaid.

Advantech Wireless

657 Orly Avenue

Dorval, Quebec

H9P 1G1

CANADA

Please indicate the RMA number on all shipping documentation.

Units shipped without prior issued RMA, or shipped not in original packing, may be subject of

rejection and returned at sender’s own expense.

LIMITATIONS OF WARRANTY

Advantech Wireless warrants this product to be free of materials and workmanship defects.

The foregoing warranty shall not apply to defects resulting from improper handling or abuse by

the Buyer, unauthorized modification, operation outside of the environmental specifications for

the product, or improper installation or maintenance.

Advantech Wireless shall not be liable for any direct, indirect, special, incidental or

consequential damages.

Page 1

SSPBMg-C200-BRE

CONTENTS

1. SAFETY..............................................................................................................................6

2. GENERAL INFORMATION...........................................................................................8

2.1 INTRODUCTION ...........................................................................................................8

2.2 DESCRIPTION................................................................................................................8

2.2.1 Power Supply...............................................................................................................8

2.2.2 Up-Converter Assembly ..............................................................................................9

2.2.3 10 MHz Reference Oscillator ......................................................................................9

2.2.4 HPA Assembly...........................................................................................................10

2.2.5 Controller Board ........................................................................................................10

2.3 SSPB SPECIFICATIONS .............................................................................................13

3. UNPACKING AND INSTALLATION..........................................................................17

3.1 INITIAL INSPECTION.................................................................................................17

3.2 UNPACKING................................................................................................................17

3.3 INSTALLATION ..........................................................................................................17

3.3.1 Mechanical Installation..............................................................................................17

3.3.2 Electrical Connections...............................................................................................18

3.3.3 RF Connections..........................................................................................................18

3.3.4 Cooling Considerations..............................................................................................19

4. INTERFACES..................................................................................................................20

4.1 SYSTEM CONTROL CONNECTOR (RS-485 RS-232) .............................................20

4.2 REDUNDANT INTERFACE........................................................................................21

4.3 LED................................................................................................................................21

4.4 RF OUTPUT MONITOR INTERFACE.......................................................................21

5. PRE POWER AND CHECKOUT .................................................................................22

5.1 PRE-POWER PROCEDURES......................................................................................22

Page 2

SSPBMg-C200-BRE

6. MAINTENANCE.............................................................................................................23

6.1 PREVENTIVE MAINTENANCE.................................................................................23

6.1.1 Mechanical Preventive Maintenance.........................................................................23

6.1.2 Checking the Cooling Fans........................................................................................23

7. RS-232 SERIAL COMMUNICATION .........................................................................24

7.1 HAND-HELD TERMINAL ..........................................................................................24

7.2 RS-232 PC TERMINAL................................................................................................26

8. RS-485 SERIAL COMMUNICATION .........................................................................34

9. PACKING LIST...............................................................................................................35

10. SAFETY AND EMC COMPLIANCE...........................................................................36

11. APPENDIX A: RS-485 SERIAL COMMUNICATION PROTOCOL.......................37

11.1 INTRODUCTION .........................................................................................................37

11.2 FRAME STRUCTURE .................................................................................................37

11.3 COMMANDS................................................................................................................38

11.4 RESPONSES TO COMMANDS FROM SLAVE TO MASTER.................................40

11.4.1 Condition Status Response ....................................................................................40

11.4.2 Read Identification Response ................................................................................40

11.4.3 Read GAIN/ATTENUATION Range Response...................................................41

11.4.4 Read Unit Status Response....................................................................................41

12. APPENDIX B: RS-485 SKYWAN SERIAL COMMUNICATION PROTOCOL....42

12.1 HARDWARE CONSIDERATIONS.............................................................................42

12.2 RS-485 INTERFACE ON 4 WIRES.............................................................................42

12.3 TRANSMISSION PROTOCOL....................................................................................42

12.3.1 Transmission Interface...........................................................................................43

12.3.2 Command Message Structure (IDU to SSPB).......................................................44

12.3.3 Response Message Structure (SSPB to IDU) ........................................................45

12.3.4 Data Field Definitions............................................................................................45

Page 3

SSPBMg-C200-BRE

FIGURES

FIGURE 1: PRODUCT OUTLINE ...................................................................................................... 11

FIGURE 2: BLOCK DIAGRAM......................................................................................................... 12

FIGURE 3: CONNECTORS ............................................................................................................... 15

FIGURE 4: HAND-HELD TERMINAL HELP MENU.......................................................................... 24

FIGURE 5: HAND-HELD TERMINAL STATUS MENU..................................................................... 25

FIGURE 6: HYPERTERMINAL RS-232 COMMUNICATION – HELP COMMAND AND RESPONSE......... 27

FIGURE 7: HYPERTERMINAL RS-232 COMMUNICATION – STATUS COMMAND AND RESPONSE..... 28

FIGURE 8: HYPERTERMINAL RS-232 COMMUNICATION – HELP RF, RF AND RF OFF COMMANDS

AND RESPONSES ..................................................................................................................... 29

FIGURE 9: HYPERTERMINAL RS-232 COMMUNICATION – HELP ATT, ATT, GAIN AND ATT <VALUE>

COMMANDS AND RESPONSES.................................................................................................. 30

FIGURE 10: HYPERTERMINAL RS-232 COMMUNICATION – HELP GAIN, GAIN, ATT AND GAIN

<VALUE> COMMANDS AND RESPONSES.................................................................................. 31

FIGURE 11: HYPERTERMINAL RS-232 COMMUNICATION – “HELP BAUD” AND “BAUD RS232”

COMMANDS AND RESPONSES.................................................................................................. 32

FIGURE 12: HYPERTERMINAL RS-232 COMMUNICATION – “HELP RS485”, “RS485 ASCII” AND

“RS485 BINARY” COMMANDS AND RESPONSES ...................................................................... 33

FIGURE 13: GRAPHICAL USER INTERFACE (GUI) – RS-485 COMMUNICATION BASED ON RS-485

PROTOCOL ............................................................................................................................. 34

Page 4

SSPBMg-C200-BRE

TABLES

TABLE 1: ELECTRICAL SPECIFICATIONS........................................................................... 13

TABLE 2: MECHANICAL SPECIFICATIONS ........................................................................ 14

TABLE 3: POWER REQUIREMENTS...................................................................................... 14

TABLE 4: ENVIRONMENTAL CONDITIONS........................................................................ 14

TABLE 5: CONNECTORS......................................................................................................... 16

TABLE 6: AC LINE (J5) – PIN ASSIGNMENTS...................................................................... 16

TABLE 7: SYSTEM CONTROL (RS232 RS485) – PIN ASSIGNMENTS .............................. 20

TABLE 8: SERIAL INTERFACE RS-232 CONNECTION INFORMATION.......................... 26

TABLE 9: PACKING LIST (P/N 19R-3171A0-3NXC)............................................................. 35

TABLE 10: COMMANDS .......................................................................................................... 38

TABLE 11: CONDITION STATUS RESPONSE ...................................................................... 40

TABLE 12: READ IDENTIFICATION RESPONSE................................................................. 40

TABLE 13: READ GAIN/ATTENUATION RANGE RESPONSE........................................... 41

TABLE 14: READ UNIT STATUS RESPONSE ....................................................................... 41

TABLE 15: COMMAND MESSAGE STRUCTURE ................................................................ 44

TABLE 16: RESPONSE MESSAGE STRUCTURE.................................................................. 45

Page 5

SSPBMg-C200-BRE

1. SAFETY

In addition to this section, included by reference are the following pertinent sections of the

International Standard IEC-215, ‘Safety requirements for radio transmitting equipment’:

Appendix D, ‘GUIDANCE ON ASSESSING THE COMPETENCE OF PERSONNEL FOR

DESIGNATION AS SKILLED’ and also Sub-clause 3.1 of the Standard.

Appendix E, ‘GUIDANCE ON SAFETY PRECAUTIONS TO BE OBSERVED BY

PERSONNEL WORKING ON RADIO TRANSMITTING EQUIPMENT’, also Sub-clauses 3.2,

3.7 and 22.1 of the Standard.

To prevent the risk of personal injury or loss related to equipment malfunction Advantech

Wireless uses the following symbols for safety related information. For your own safety, please

read the information carefully BEFORE operating the equipment.

Symbols used in this manual:

WARNING! Indicates a hazardous procedure that may result in serious injury or death, if

not performed properly.

CAUTION! Indicates a dangerous procedure that may result in light-to-severe injury or loss

related to equipment malfunction, if proper precautions are not taken.

Page 6

SSPBMg-C200-BRE

-------------------------------------------- WARNING ---------------------------------------------

The operator cannot repair this unit. DO NOT attempt to remove the top cover or

disassemble the internal components. Only qualified service technicians should service this unit.

There is a risk of damaging the precision components.

----------------------------------------------- WARNING ------------------------------------------

ALWAYS TERMINATE THE OUTPUT WAVEGUIDE OF THE UNIT WITH AN RF LOAD

CAPABLE OF DISSIPATING FULL CW RF POWER. SIMILARLY TERMINATE THE RF

INPUT PORT TO AVOID THE POSSIBILITY OF THE UNIT BEING DRIVEN BY STRAY

LEAKAGE SIGNALS. Incorporate the terminations prior to applying prime power to the unit.

This procedure prevents self-oscillation and irradiation from and into the local environment. If

an RF source is not connected to the RF input port, the unit may go into a self-induced mode and

generate high levels of RF energy. Destruction caused by an excessive load voltage standing

wave ratio (VSWR) will void the warranty.

----------------------------------------------- WARNING -------------------------------------------

DO NOT LOOK INTO THE RF OUTPUT PORT OF THE POWERED BLOCK

UP-CONVERTER! Handle the powered SSPB with extreme care. Keep in mind that the levels

of microwave radiation, which do not induce immediate physical discomfort in most individuals,

can be sufficiently high to induce long term effects. The eyes are the most vulnerable parts of

the body.

The maximum permissible levels of exposure are quite low in comparison to the power levels

produced by the equipment built by Advantech Wireless (e.g. less than 10 mW versus 4 to 700

W delivered by the different units). The maximum permissible levels are currently being studied

by a number of organizations. In the past the U.S. Safety Code established a dosage rate of 10

mW/cm2. Currently, there is consideration being given to reducing the permissible level to

1 mW/cm2in the United States, as has been the case for several European countries.

Page 7

SSPBMg-C200-BRE

2. GENERALINFORMATION

2.1 INTRODUCTION

This manual contains information that describes the installation, operation and maintenance

procedures for the 200-Watt C-Band hub-mount (outdoor) Solid State Power Block Up-

Converter model SSPBMg-C200-BRE. Because specialized training is required for some phases

of installation and operation, certain parts of this manual are directed only to properly trained

personnel. Warnings appear at the appropriate points to caution all users of the potential RF

hazards.

For a safe and versatile operation, please read the information carefully BEFORE using the

equipment.

Advantech Wireless has prepared this manual for use as a guide for the proper installation,

operation and maintenance of Advantech Wireless equipment and computer programs. The

drawings, specifications and information contained herein are the property of Advantech

Wireless. Unauthorized use or disclosure of these drawings, specifications and information is

strictly prohibited. They shall not be reproduced, copied or used in whole or in part as the basis

for manufacturing or sale of the equipment or software programs without the prior written

consent of Advantech Wireless.

2.2 DESCRIPTION

The SSPBMg-C200-BRE is a 200-Watt C-Band hub-mount (outdoors) Solid State Power Block

Up-Converter (SSPB). The entire SSPB is self-contained and is intended for mounting on to the

antenna hub, see Figure 1: Product Outline at page 11. It incorporates an Interface Assembly, Up-

Converter Assembly, High Power Amplifier (HPA) Assembly, Power Supply Assembly and a Main

Controller Board. The block diagram of the SSPB is shown in Figure 2: Block Diagram (page 12)

and the various connectors are shown in Figure 3: Connectors (page 15).

2.2.1 POWER SUPPLY

There are two power supply assemblies in this SSPB. The first power supply provides +12 V DC

high current and – 9 V DC low current for the SSPB and +12 V DC for the fans. The second

power supply provides +48 V DC for the final GaN devices in the High Power Amlifier

Assembly. The unit is configured for operation from 90 - 264 V AC, single phase, 47-63 Hz.

It has a Power Factor Correction (PFC) of 95%, minimum.

The overall power consumption is 750 W (@ PLIN RF Output Power) and 900 W (@ PSAT RF

Output Power), typical.

Page 8

SSPBMg-C200-BRE

2.2.2 UP-CONVERTER ASSEMBLY

The L-Band signal arriving from a modem enters the Up-Converter Assembly through a ‘N-type’

connector, see Figure 3: Connectors (page 15). The L-Band signal (950 MHz to

1525 MHz) enters the high gain Low Noise Amplifier (LNA) and Medium Power Amplifier

(MPA) stages that boost the RF power level sufficient for the transmission through the Up-

Converter Assembly.

Integral to the UP-Converter Assembly is a variable attenuation section that maintains the overall

gain of this module constant against changes in temperature (global temperature compensation).

A temperature dependent DC voltage is sent from a temperature sensor from within the HPA

Assembly through the power conditioner board to the attenuator. The amount of attenuation is

varied with the change in the DC voltage.

The Up-Converter Assembly converts and amplifies the incoming L-Band carrier signal into a C-

Band carrier. To achieve this requirement, this assembly contains a synthesizer, a mixer, a

multiplier, two LNAs and a band-pass filter, see Figure 2: Block Diagram (page 12). For this

application, the Up-Converter requires the L-Band signal, which is sent to the mixer and the

internal 10 MHz reference provided by the 10 MHz oscillator, which is fed into the synthesizer.

The synthesizer contains a phase-locked loop local oscillator (PLL LO), which is normally

phase-locked with the incoming 10 MHz internal reference signal. When functioning correctly,

the PLLLO generates a 4.900 GHz LO signal. The 4.900 GHz LO signal and the L-Band signal

are fed into a mixer to produce the required C-Band signal. The frequency-range provided by the

Up-Converter Assembly is from 5.850 GHz to 6.425 GHz.

The synthesizer also contains an out of lock protection circuitry that prevents frequency shifts

from occurring to the resulting C-Band signal. When the oscillator is not phase-locked, a signal

is sent to the power conditioner board within the HPA Assembly to shutdown the RF devices.

The band-pass filter removes the unwanted harmonic frequencies, allowing the C-Band signal to

pass through the HPA Assembly.

2.2.3 10 MHZ REFERENCE OSCILLATOR

This module is used to generate a highly stable and very low phase noise 10 MHz reference

frequency with a high stability (of ±5 x 10-8 MHz/year typical), which is required by the

converter module.

Page 9

Inhaltsverzeichnis

Andere Advantech Medienkonverter Handbücher

Advantech

Advantech B+B SmartWorx 232USB9M Bedienungsanleitung

Advantech

Advantech B+B SmartWorx 485DRCI-PH Bedienungsanleitung

Advantech

Advantech SSPBM-K125-BTE Bedienungsanleitung

Advantech

Advantech EKI-2541S/SC Bedienungsanleitung

Advantech

Advantech BB-SCP211-DFTB3 Bedienungsanleitung

Advantech

Advantech USB-4604B Bedienungsanleitung

Advantech

Advantech B+B SMARTWORX 485LDRC9 Bedienungsanleitung

Advantech

Advantech PCI-1784U Bedienungsanleitung

Advantech

Advantech B+B SmartWorx MiniMc TP-TX/FX Bedienungsanleitung

Advantech

Advantech B+B SmartWorx 485OI9TB Bedienungsanleitung

Advantech

Advantech EKI-2741SX-AE Bedienungsanleitung

Advantech

Advantech BB-485LDRC9 Bedienungsanleitung

Advantech

Advantech VEGA-2001 Gebrauchsanweisung

Advantech

Advantech B+B SmartWorx BB-485USBTB-2W-A Bedienungsanleitung

Advantech

Advantech B+B SmartWorx IMcV-10G Bedienungsanleitung

Advantech

Advantech PCL-833 Bedienungsanleitung

Advantech

Advantech ADAM-4561 Bedienungsanleitung

Advantech

Advantech SSPBM-K80-BTE Bedienungsanleitung

Advantech

Advantech EKI-2541M/SC Bedienungsanleitung

Advantech

Advantech B+B SmartWorx 485USBTB-2W Bedienungsanleitung

Advantech

Advantech DVP-7020 Bedienungsanleitung

Advantech

Advantech ADAM-6541 Bedienungsanleitung

Advantech

Advantech SSPB-K40-CSE Bedienungsanleitung

Advantech

Advantech B+B SmartWorx IMcV-Giga-FiberLinX-III Bedienungsanleitung

Beliebte Medienkonverter Handbücher anderer Marken

SoundTraxx

SoundTraxx Blunami BLU-2200 Bedienungsanleitung

SPROLINK

SPROLINK VA1 Bedienungsanleitung

Acclaim Lighting

Acclaim Lighting DDC-1-AC Bedienungsanleitung

Nikon

Nikon AF-S TC-20E III Bedienungsanleitung

Axis

Axis AXIS Q7406 Bedienungsanleitung

Omega

Omega TAC80B-J Bedienungsanleitung

Zoom

Zoom Thunderbolt TAC-2R Bedienungsanleitung

OST

OST iConverter 10/100M Bedienungsanleitung

Vertiv

Vertiv Netsure Bedienungsanleitung

birddog

birddog MINI Bedienungsanleitung

Roland

Roland GI-10 Bedienungsanleitung

Wallenstein

Wallenstein WX310 Bedienungsanleitung

Pace

Pace MSS 200-1 Bedienungsanleitung

Solar Converters

Solar Converters EQ 12/24-50 Bedienungsanleitung

CYP

CYP EL-7400V Bedienungsanleitung

TIE

TIE MIDI 1i1o Bedienungsanleitung

DCS

DCS Vivaldi Upsampler Bedienungsanleitung

Westermo

Westermo MCW-211 SERIES Bedienungsanleitung
