Advantech ICR-3201 Series Bedienungsanleitung

LAN Industrial Router

ICR-3201

USER MANUAL

ICR-3201

Advantech B+B SmartWorx – Americas

Advantech B+B SmartWorx

707 Dayton Road

Ottawa, IL 61350 USA

Website

www.advantech-bb.com

Advantech – Europe

Advantech Czech s.r.o.

Sokolska 71

562 04, Usti nad Orlici,

Czech Republic

Website

www.advantech-bb.com

2020 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or

by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval

system without written consent. Information in this manual is subject to change without notice, and does not

represent a commitment on the part of Advantech.

Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-

ing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

ICR-3201

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

[email protected].

Please see http://ep.advantech-bb.cz/devzone for more information.

Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0050-EN, revision from May 19, 2020. Released in the Czech Republic.

ICR-3201

Contents

1 Safety Instructions 2

2 WEEE directive 3

3 Router Description 4

4 Contents of Package 5

5 Router Design 6

5.1 Router Versions .................................... 6

5.2 Device Labels ..................................... 7

5.3 Order Codes ..................................... 7

5.4 Basic Dimensions of the Router Box (speciﬁed in mm) .............. 8

5.5 Mounting Recommendations ............................ 9

5.6 Removing from the DIN Rail ............................. 10

5.7 Description of the Front Panel ............................ 11

5.7.1 Status Indication ............................... 11

5.7.2 Power Connector PWR ........................... 12

5.7.3 Ethernet Port ETH0 and ETH1 ....................... 13

5.7.4 Reset Button ................................. 14

5.8 Description of the Left Panel ............................. 16

5.8.1 Serial Interfaces and I/O Port ........................ 17

5.9 Description of the Right Panel ............................ 19

5.9.1 WiFi Antenna Connectors .......................... 19

6 First Use 20

6.1 Connecting the Router Before First Use ...................... 20

6.2 Start .......................................... 20

6.3 Conﬁguration ..................................... 20

6.3.1 Conﬁguration by Web Browser ....................... 20

7 Technical Parameters 22

7.1 Basic Parameters ................................... 22

7.2 Standards and Regulations ............................. 23

7.3 Type Tests and Environmental Conditions ..................... 24

7.4 Technical Parameters of WiFi ............................ 25

7.5 Other Technical Parameters ............................. 25

8 Related Documents 26

iii

ICR-3201

9 Troubleshooting 27

9.1 FAQ .......................................... 27

10 Customers Support 29

10.1 Customer Support for NAM ............................. 29

10.2 Customer Support for Europe ............................ 29

10.3 Customer Support for Asia ............................. 29

ICR-3201

List of Figures

1 Version without WiFi ................................. 6

2 Version with WiFi ................................... 6

3 Labels example .................................... 7

4 Basic dimensions of the router box ......................... 8

5 Basic dimensions of the router box ......................... 8

6 Default position of DIN rail clip ........................... 10

7 Removing from the DIN rail ............................. 10

8 The front panel of the router ............................. 11

9 Power connector ................................... 12

10 Connection of power supply ............................. 12

11 Ethernet connector .................................. 13

12 Connection of Ethernet cables ........................... 13

13 Router reset ...................................... 14

14 The left panel of the router .............................. 16

15 Serial + I/O connector ................................ 17

16 Functional scheme of the binary interface ..................... 18

17 The right panel of the router ............................. 19

18 Entering the IP address of the router ........................ 20

19 Entering login information .............................. 20

20 Router web interface ................................. 21

ICR-3201

List of Tables

1 Contents of package ................................. 5

2 Router versions .................................... 6

3 Order Codes Overview ................................ 7

4 Description of the front panel ............................ 11

5 Status indication ................................... 11

6 Connection of power connector ........................... 12

7 Connection of Ethernet connector .......................... 13

8 Overview of router reboot and reset ......................... 15

9 Description of the left panel ............................. 16

10 Connection of RS485 ................................ 17

11 Connection of I/O ................................... 17

12 Connection of RS232 ................................ 17

13 Description of the right panel ............................ 19

14 Basic parameters ................................... 22

15 Standards and regulations .............................. 23

16 Type tests and environmental conditions ...................... 24

17 Technical parameters of WiFi ............................ 25

18 Other technical parameters ............................. 25

ICR-3201

1. Safety Instructions

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and / or a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Power supply must not exceed 36 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•Only routers with appropriate certiﬁcation and labelling should be used in locations where

ﬂammable and explosive materials are present, including gas stations, chemical plants,

or locations in which explosives are used. We remind users of the duty to observe the

restrictions concerning the utilization of radio devices at such places.

•Switch off the router when travelling by plane. Utilization of the router on a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension or

cancellation of telephone services for the respective client and / or may result in legal

sanctions.

•When using the router in close proximity to personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when used in close proximity to TV sets, radio re-

ceivers or personal computers.

•It is recommended that you create an appropriate copy or backup of all important settings

that are stored in the memory of the device.

•The device should not be used in the location where the children are present.

ICR-3201

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-

troduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques in order to minimize impact on the environment. This product contains

high quality materials and components which can be recycled. At the end of it’s life this pro-

duct MUST NOT be mixed with other commercial waste for disposal. The device contains the

battery. Remove the battery from the device before disposal. The battery in the device needs

to be disposed apart accordingly. Check the terms and conditions of your supplier for disposal

information.

ICR-3201

3. Router Description

ICR-3201 is a LAN industrial router intended for the global market. This router is an ideal

device for the realization of a secure connection of two local area networks (LANs). Inter-

connection is carried out using two ETHERNET 10/100 interfaces and secure tunnel (IPSec,

OpenVPN, L2TP). The other equally important ways to use this router is to connect any device

with RS232, RS485 or I/O interface to the local network (LAN).

The standard conﬁguration includes two Ethernet 10/100 ports, serial line RS232, RS485,

one binary input and one output. The router can be equipped with a WiFi module, but this

must be part of the initial conﬁguration – it cannot be added to the router at some point in the

future. The router can be provided only in a metal casing.

Conﬁguration of the router may be done via a password-protected Web interface. Web in-

terface provides detailed statistics about the router’s activities, signal strength, detailed system

log etc. The router supports the creation of VPN tunnels using IPSec, OpenVPN and L2TP

to ensure safe communication. DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, backup primary

connection and many other functions are supported.

The router provides diagnostic functions which include automatically monitoring the PPP

connection, automatic restart in case of connection losses, and a hardware watchdog that

monitors the router status. The user may insert Linux scripts which are started on various

actions. It is possible to create up to four different conﬁgurations for the same router. These

conﬁgurations can be switched whenever necessary via Web interface or binary input status.

The router can automatically upgrade its conﬁguration and ﬁrmware from your central server.

This allows for mass reconﬁguration of numerous routers at the same time.

The router also supports additional software like R-SeeNet for permanent trafﬁc monitoring

of routers or WebAccess/VPN for remote access.

Examples of possible applications

•ﬂeet management

•security system

•telematic

•telemetric

•remote monitoring

•vending and dispatcher machines

Andere Handbücher für ICR-3201 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Advantech Netzwerk-Router Handbücher

Advantech

Advantech Bivias v2 Bedienungsanleitung

Advantech

Advantech SmartFlex SR304 Bedienungsanleitung

Advantech

Advantech B+B SmartWorx SE416 Bedienungsanleitung

Advantech

Advantech B+B SmartWorx SmartStart Leitfaden

Advantech

Advantech UR5i v2 Libratum Bedienungsanleitung

Advantech

Advantech ICR-3831 Leitfaden

Advantech

Advantech ICR-4401 Bedienungsanleitung

Advantech

Advantech B+B Smartworx SEC510-2SFP-T Bedienungsanleitung

Advantech

Advantech EKI2726FHPI Series Installations- und Betriebshandbuch

Advantech

Advantech ICR-2431 Bedienungsanleitung

Advantech

Advantech EKI-6538 Bedienungsanleitung

Advantech

Advantech ESWGP510-2SFP-T Bedienungsanleitung

Advantech

Advantech ICR-2701 Bedienungsanleitung

Advantech

Advantech EKI-7526I Bedienungsanleitung

Advantech

Advantech UR5i v2 Libratum Montage- und Bedienungsanleitung

Advantech

Advantech SmartStart SL304 Bedienungsanleitung

Advantech

Advantech ICR-2030 Bedienungsanleitung

Advantech

Advantech EKI-7556MI Bedienungsanleitung

Advantech

Advantech XR5i v2 Leitfaden

Advantech

Advantech EKI-2726FHPI Series Installations- und Betriebshandbuch

Advantech

Advantech ICR-2441 Bedienungsanleitung

Advantech

Advantech ICR-2436 Bedienungsanleitung

Advantech

Advantech ICR-4453S Bedienungsanleitung

Advantech

Advantech ICR-3231 Bedienungsanleitung

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
