Advantech SL305 Bedienungsanleitung

LTE Industrial Router

SmartStart SL305

USER MANUAL

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

any means, electronic or mechanical, including photography, recording, or any information storage and retrieval

system without written consent. Information in this manual is subject to change without notice, and does not

represent a commitment on the part of Advantech.

Advantech Czech s.r.o. shall not be liable for incidental or consequential damages resulting from the furnish-

ing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0056-EN, revision from June 8, 2023. Released in the Czech Republic.

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

Contents

1 Safety Instructions 2

2 WEEE directive 3

3 Router Description 4

3.1 LTE Category 4 (Cat.4) ............................... 4

3.2 Basic HW Information ................................ 4

3.3 Conﬁguration and Diagnostics ............................ 4

3.4 Usage of the Router ................................. 5

4 Contents of Package 8

5 Router Design 9

5.1 Router Versions .................................... 9

5.2 Product Revisions .................................. 9

5.3 Delivery Identiﬁcation ................................ 10

5.4 Order Codes ..................................... 10

5.5 Basic Dimensions of the Router ........................... 11

5.5.1 Front view ................................... 11

5.5.2 Top view .................................... 11

5.5.3 Bottom view .................................. 12

5.5.4 Rear view ................................... 12

5.6 Mounting recommendations ............................. 13

5.7 Removal from the DIN rail .............................. 14

5.8 Description of the Rear Panel ............................ 15

5.9 Description of the Front Panel ............................ 15

5.9.1 Status indication ............................... 16

5.9.2 Power PWR/IO Connector .......................... 17

5.9.3 Antenna Connector ANT, DIV and WiFi .................. 20

5.9.4 SIM Card Reader ............................... 21

5.9.5 Ethernet Port ETH .............................. 22

5.9.6 Serial Port RS232 .............................. 23

5.9.7 Reset ..................................... 24

6 First Use 25

6.1 Connecting the Router Before the First Use .................... 25

6.2 Start .......................................... 26

6.3 Conﬁguration ..................................... 26

6.3.1 Conﬁguration by web browser ........................ 26

iii

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

7 Technical Parameters 28

7.1 Basic Parameters ................................... 28

7.2 Technical speciﬁcation of user interfaces ...................... 29

7.3 Standards and Regulations ............................. 29

7.4 Type Tests and Environmental Conditions ..................... 30

7.5 Technical Parameters of Module .......................... 31

7.6 Technical Parameters of WiFi ............................ 32

7.7 System Conﬁguration ................................ 32

8 Related Documents 33

9 Troubleshooting 34

9.1 FAQ .......................................... 34

10 Customer Support 37

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

List of Figures

1 Access to the Internet from LAN .......................... 5

2 Backed up access to the Internet .......................... 6

3 Using a VPN tunnel ................................. 6

4 Serial Gateway .................................... 7

5 Contents of package ................................. 8

6 Front panel ...................................... 9

7 Product label ..................................... 10

8 Front view ....................................... 11

9 Top view ........................................ 11

10 Bottom view ...................................... 12

11 Rear view ....................................... 12

12 Default position of metal DIN rail clip ........................ 14

13 Removal from the DIN rail .............................. 14

14 SmartStart front panel ................................ 15

15 PWR / IO connector .................................. 17

16 Circuit example – connection of power supply ................... 17

17 Binary connection .................................. 18

18 Connecting the antenna ............................... 20

19 SIM cards ....................................... 21

20 Ethernet connector .................................. 22

21 Connection of Ethernet cable ............................ 22

22 RS232 connector ................................... 23

23 Router reset ...................................... 24

24 Router connection .................................. 25

25 Entering the IP address of the router ........................ 26

26 Router web interface ................................. 27

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

List of Tables

1 Router versions .................................... 9

2 HW Revisions History ................................ 9

3 Delivery identiﬁcation ................................ 10

4 Order codes overview ................................ 10

5 Front panel description ................................ 15

6 Status indication ................................... 16

7 Connection of PWR / IO connector ......................... 17

8 Characteristics of binary input ............................ 18

9 Connection of Ethernet connector .......................... 22

10 Connection of RS232 connector .......................... 23

11 Description of router reset and restart ....................... 24

12 Basic parameters ................................... 28

13 Technical speciﬁcation of user interfaces ...................... 29

14 Standards and Regulations ............................. 29

15 Type tests and environmental conditions ...................... 30

16 Technical parameters of module for EMEA ..................... 31

17 Technical parameters of WiFi ............................ 32

18 Other technical parameters ............................. 32

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

1. Safety Instructions

Please, observe the following instructions:

• The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

• To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and / or a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

• The router can not be opened.

• Turn off the router and disconnect it from power supply before handling the SIM card.

•Caution! This equipment is not suitable for use in locations where children are likely to

be present. The SIM card could be swallowed by small children.

• Input voltage must not exceed 36 V DC max.

• Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

• Only routers with appropriate certiﬁcation and labelling should be used in locations where

ﬂammable and explosive materials are present, including gas stations, chemical plants,

or locations in which explosives are used. We remind users of the duty to observe the

restrictions concerning the utilization of radio devices at such places.

• Switch off the router when traveling by plane. Utilization of the router on a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension or

cancellation of telephone services for the respective client and / or may result in legal

sanctions.

• When using the router in close proximity to personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

• The router may cause interference when used in close proximity to TV sets, radio re-

ceivers or personal computers.

• It is recommended that you create an appropriate copy or backup of all important settings

that are stored in the memory of the device.

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-

troduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques to minimize the environmental impact. This product contains high quality

materials and components which can be recycled. At the end of it’s life this pro- duct MUST

NOT be mixed with other commercial waste for disposal. The device contains a battery. Re-

move the battery from the device before disposal. The battery in the device needs to be

disposed of apart accordingly. Check the terms and conditions of your supplier for disposal

information.

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

SmartStart SL305

3. Router Description

Cellular router SmartStart is designed for wireless communication in mobile networks that

use traditional cellular technologies. The primary purpose of this router is its use in the newest

Category 4 (Cat.4) services on the cellular LTE network.

3.1 LTE Category 4 (Cat.4)

LTE Category 4 (Cat.4) is the next step in 4G LTE device capability. Cat.4 rated SmartStart

routers are capable of achieving typical speeds in 4G coverage areas where the network is

enabled with 20 MHz of contiguous spectrum. The peak downlink data rate for a Category 4

is approximately 150 Mbps. Also in the uplink, LTE Category 4 provides a peak data rate of

50 Mbps.

3.2 Basic HW Information

As a standard, the SmartStart router is equipped with one Ethernet 10/100 Mbps, one

serial interface RS232, one binary input and one output. SL305 also contains two readers for

3 V and 1.8 V SIM cards, which are placed on the rear panel of the device. The router can

be equipped with a WiFi module, but this must be part of the initial conﬁguration – it cannot

be assembled to the router at some point in the future. The SmartStart router is supplied in a

plastic casing.

3.3 Conﬁguration and Diagnostics

The router can be conﬁgured using a password-protected Web interface. The web interface

provides (after logging in) detailed statistics about the router activities, signal strength, detailed

system logs etc. This device supports the creation of VPN tunnels using technologies IPSec,

OpenVPN and L2TP for secure communications. There are also supported functions such as

IPv6 (the latest revision of the Internet Protocol), DHCP, NAT, NAT-T, DynDNS, NTP, VRRP,

control by SMS, primary connection backups and many other functions are also supported.

Other diagnostic functions ensuring continuous communication include automatic inspec-

tion of PPP connection offering an automatic restart feature in case of connection is lost, or

hardware watchdog which monitors the status of the router. Using a special window (start up

script window) you may insert Linux scripts for various actions. For some applications is the

key possibility to create several different conﬁgurations for one router which can be switched

as needed (e.g. using SMS or status of the binary input). Cellular routers may automatically up-

date conﬁguration and ﬁrmware from server. This allows mass reconﬁguration of many routers

in one time.

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

Andere Handbücher für SL305

Inhaltsverzeichnis

Andere Advantech Netzwerk-Router Handbücher

Advantech

Advantech UR5i v2 Libratum Bedienungsanleitung

Advantech

Advantech Libratum ICR-2834 Bedienungsanleitung

Advantech

Advantech SmartMotion ST355 Bedienungsanleitung

Advantech

Advantech ICR-2000 Leitfaden

Advantech

Advantech SmartFlex SR309 Bedienungsanleitung

Advantech

Advantech ICR-4453S Bedienungsanleitung

Advantech

Advantech EKI-2748FI Bedienungsanleitung

Advantech

Advantech SmartMotion ST355 Bedienungsanleitung

Advantech

Advantech ICR-2701 Bedienungsanleitung

Advantech

Advantech ICR-2432 Bedienungsanleitung

Advantech

Advantech ICR-2436 Bedienungsanleitung

Advantech

Advantech ICR-4453 Bedienungsanleitung

Advantech

Advantech ICR-2031 Bedienungsanleitung

Advantech

Advantech EKI-3525 Installations- und Betriebshandbuch

Advantech

Advantech Libratum ICR-2834 Leitfaden

Advantech

Advantech SmartFlex SR307 Bedienungsanleitung

Advantech

Advantech SmartStart Series Leitfaden

Advantech

Advantech SmartMotion ST352 Bedienungsanleitung

Advantech

Advantech SmartFlex SR303 Bedienungsanleitung

Advantech

Advantech ICR-1601 Merkblatt

Advantech

Advantech EKI-7529MI Bedienungsanleitung

Advantech

Advantech ICR-2441 Bedienungsanleitung

Advantech

Advantech ICR-3211 Leitfaden

Advantech

Advantech ICR-4453W Leitfaden

Beliebte Netzwerk-Router Handbücher anderer Marken

Allnet

Allnet ALL0333AU Bedienungsanleitung

HomeSeer

HomeSeer HT-SEL Bedienungsanleitung

Sercomm

Sercomm Genesis OC3505D Bedienungsanleitung

Billion

Billion BIPAC 5102 Series Bedienungsanleitung

TP-Link

TP-Link TD-8817 Bedienungsanleitung

Motorola

Motorola MR1900 Bedienungsanleitung

Digi

Digi IX14 Bedienungsanleitung

Cisco

Cisco NCS 540 Handbuch

XAVi

XAVi X8821e Bedienungsanleitung

BEC

BEC 6200WZL Bedienungsanleitung

MikroTik

MikroTik hAP ac3 Series Bedienungsanleitung

Korenix

Korenix JetNet 5428G Series Bedienungsanleitung

NETGEAR

NETGEAR FS526T - Switch Bedienungsanleitung

Korenix

Korenix JetNet 5710G Series Bedienungsanleitung

Automated Logic

Automated Logic ZN551 Betriebsanleitung

Cisco

Cisco ASR 1000 Series Bedienerhandbuch

EnGenius

EnGenius ESR-9710 Bedienungsanleitung

Cisco

Cisco 805 Series Bedienungs- und Sicherheitshinweise
