Aerpro APMSWC1 Bedienungsanleitung

APMSWC1

aerpro.com

manual

WIRELESS CHARGING

DASH & VENT MOUNT

MAGNETIC HOLDER

Product Information

Fixing Plate

Hook

Clip

Adjustable Collar

Power Input Port

Adhesive

Mount

Charging

Contact

Magnetic

Head

Alignment

Magnet Charging

Indicator LED

Attaching the mount to the holder

1. Place the adjustable collar over the ball of

the mount

2. Press the ball of the mount into the back of

the magnetic wireless charging head

3. Move the magnetic wireless charging head

to the desired position and tighten the

adjustable collar.

Attaching the adhesive mount to a flat

surface

1. Clean any oil, debris, or dust on the area

where 3M base is to be placed. If possible use

an alcohol wipe to help with adhesion.

2. Peel off the protection sheet from the 3M

base and stick to chosen area by strongly

pressing the base for an extended period of

time.

3. The strength of the 3M tape will perform

perfectly after 4-5 hours of installation.

4. Do not use the magnetic holder for the above

period of time or the mount may become

unstuck.

Attaching the hook mount to a vent

1. Unfasten the hook clip sufficiently by

rotating the fixing plate.

2. Insert the hook clip to the center of the vents

3. Rotate the adjustable collar so that the fixing

plate tightens against the hook to avoid the

presence of any gap between fixing plate and

vent.

4. Check if vent clip is fixed firmly and

correctly.

The Vent Mount is designed to be used only

with FLAT air vent blades.

Attaching the hook mount to a vent

Charging your device

1. Connect the supplied USB cable to the

power input port of the magnetic wireless

charging head

2. Connect opposite end of the supplied USB

cable into a USB car charger or USB power

adapter (Not Included).

3. The charging indicator LED will turn white.

The magnetic wireless charging holder is now

ready for your smartphone or device.

4. Placing your smartphone on to the

magnetic wireless charging head is made

easy by the alignment magnet.

5. With successful alignment the charging

indicator LED will turn blue and charging will

commence.

6. If the charging indicator LED flashes white

and blue there is a problem with the

connection. Reposition your smartphone to fix

the problem.

CAUTION

1. The magnet used in this product will have no

negative impact on the phone. In case of any

applications not working correctly, please

restart application and slightly adjust the

position of where smartphone is mounted.

2. Never mount a smartphone onto holder with

a magnetic credit card in the smartphone case.

3. Be careful not to have the magnet be in

reach of medical devices.

4. Periodically check the tightness of the hook

vent clip to prevent unexpected dropping of

phone.

5. When removing your smartphone from the

magnetic holder, twist and slide, rather than

pulling off directly. This will help protect the

vent blades from being removed or damaged

due to the extreme strength of the magnets.

6. Do not install the holder where it will obstruct

the drivers view.

7. Periodically check the strength of the 3M

base.

8. Do not operate phone and holder while

driving.

1. The car charger or adapter used to power

the Wireless Charging Magnetic Holder that

outputs the proper voltage is required (Not

included).

2. The connected power car charger or

adapter used must output DC

5V/2A,9V/2A,12V/2A. Using a charger or

adapter with a lower output may result in

malfunction or overheating.

3. Charging speed may vary depending on

device specifications, input voltage and

environment.

5. Phone cases or metal plates for magnetic

attachment may interfere with wireless

charging.

6. It’s normal for the charger and your device

to get hot whilst charging. It will get even

hotter if the device is also being used while

charging. Allow the charger to cool if too hot.

NOTE

Inclusions

Wireless charging magnetic head

Vent mount

Adhesive mount

Type C USB charging cable

Technical assistance

If you need assistance with your Aerpro

product call Aerpro Support Australia.

TEL: 03 – 8587 8898 FAX: 03 – 8587 8866

Mon-Fri 9am – 5pm AEST

This manual is considered correct at time of

writing but is subject to change. For latest

manuals and updates refer to the website.

www.aerpro.com
