Agilent Technologies 11716A Kurzanleitung

Agilent Technologies

11716A/C

Interconnection Kit

Operating Note

Agilent Part Number: 11716-90004

Printed in USA

June 2002

Supersedes: April 2002

Advanced Test Equipment Rentals

www.atecorp.com 800-404-ATEC (2832)

ii 11716A/C Operating Note

Notice

The information contained in this document is subject to change without

notice.

Agilent Technologies makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

merchantability and ﬁtness for a particular purpose. Agilent Technologies

shall not be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing, performance, or

use of this material.

Agilent Technologies assumes no responsibility for the use or reliability of

its software on equipment that is not furnished by Agilent Technologies.

This document contains proprietary information which is protected by

photocopied, reproduced, or translated to another language without prior

written consent of Agilent Technologies.

Restricted Rights Legend

Use, duplication, or disclosure by the U.S. Government is subject to

restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical

Data and Computer Software clause at DFARS 252.227-7013 for DOD

agencies, and subparagraphs (c)(1) and (c)(2) of the Commercial Computer

Software Restricted Rights clause at FAR 52.227-19 for other agencies.

11716A/C Operating Note iii

Warranty

Certiﬁcation Agilent Technologies certiﬁes that this product met its published

speciﬁcations at the time of shipment from the factory.

Documentation

Warranty THE MATERIAL CONTAINED IN THIS DOCUMENT IS

PROVIDED "AS IS," AND IS SUBJECT TO BEING CHANGED,

WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER, TO

THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,

AGILENT DISCLAIMS ALL WARRANTIES, EITHER EXPRESS

OR IMPLIED WITH REGARD TO THIS MANUAL AND ANY

INFORMATION CONTAINED HEREIN, INCLUDING BUT NOT

LIMITED TO THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. AGILENT SHALL NOT BE LIABLE FOR ERRORS

OR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN

CONNECTION WITH THE FURNISHING, USE, OR

PERFORMANCE OF THIS DOCUMENT OR ANY

INFORMATION CONTAINED HEREIN. SHOULD AGILENT

AND THE USER HAVE A SEPARATE WRITTEN AGREEMENT

WITH WARRANTY TERMS COVERING THE MATERIAL IN

THIS DOCUMENT THAT CONFLICT WITH THESE TERMS,

THE WARRANTY TERMS IN THE SEPARATE AGREEMENT

WILL CONTROL.

Assistance Product maintenance agreements and other customer assistance agreements

are available for Agilent Technologies products.

For assistance, call your local Agilent Technologies Sales and Service Ofﬁce

(refer to “Support and Service”).

iv 11716A/C Operating Note

Support and Service

You can ﬁnd a list of local service representatives on the Web at:

http://www.agilent.com/find/assist

Click on “Contact Us” and select your country.

If you do not have access to the Internet, one of these centers can direct you

to your nearest Agilent Technologies representative:

United States (800) 403-0801

Canada (877) 429-9969

Europe (41 22) 780.6111 (Switzerland)

(33 1) 69 82 66 66 (France)

(49 7031) 464-6222 (Germany)

(44 188) 9696622 (Great Britain)

Japan 0120-32-0119

Latin America (11) 7297-3700 (Brazil)

Australia/New

Zealand 1-800-802-540 (Australia)

0800-738-378 (New Zealand)

Asia-Paciﬁc 080-047-669

11716A/C Operating Note 1

General Information

This operating note contains information for the 11716A and 11716C

Interconnection Kits. Included in the note is a list of parts with part numbers

and instructions for using the kit.

Description The 11716A and 11716C Interconnection Kit provides the necessary parts to

connect various attenuators in series. See Table 1 for possible combinations.

The 11716A interconnection ridged cable has type-N connectors, and the

11716C has SMA connectors.

•Overall height with attenuators is 3.235 inches.

•Typical return loss of the cable is ≤20 dB.

Interconnection Kit

Matrix

Items Supplied Parts included in the interconnection kits are listed in Table 2.

Table 1 Interconnection Kit Parts

8494 8495 8496

8494 Yes Yes Yes

8495 Yes No Yes

8496 Yes Yes Yes

Table 2 Interconnection Kit Parts

Description Qty Part Number

Combining bracket 1 11716-00001

Base 1 11716-00002

Interconnect rigid cable

Type-N male connectors 11716A

SMA connectors 11716C 1

111716-20001

11716-20003

Felt feet 4 0403-0309

Screw 4-40 x 7.9 mm (0.312 inch) 4 2200-0105

Screw 4-40 x 9.5 mm (0.375 inch) 2 2220-0769

211716A/C Operating Note

Installation

Initial Inspection Inspect the shipping container for damage. Inspect the kit for any

mechanical damage incurred in transit. If the shipping container or

cushioning material is damaged, it should be kept until the contents of the

shipment have been checked for completeness and the kit has been checked

mechanically and electrically.

If the contents of this shipment are incomplete, or if there is mechanical

damage or defect, notify the nearest Agilent Technologies Ofﬁce. If the

shipping container is damaged, or the cushioning material shows signs of

stress, notify the carrier as well as the Agilent Technologies ofﬁce. At

Agilent’s option, the ofﬁce will arrange for repair or replacement without

waiting for claim settlement.

Installing

Interconnection Kit

CAUTION Do not allow connectors on the Interconnection Kit to bear torque or support

weight.

To connect two attenuators using the kit:

1. Remove the pedestal bases of both attenuators.

2. Select the attenuator to be located on top and connect it to the outer

bracket surface that has the three small holes. Use two of the

4-40 x 7.9 mm (0.312 inch) screws supplied.

NOTE If one of the two attenuators is an 8495 70 dB attenuator, this physically

shorter unit should be selected for the top location.

3. Fasten the remaining attenuator to the inside of the bracket, with or

without the sheet metal base. The screws should pass through the two

elongated holes. Do not tighten these screws at this time.

NOTE The 4-40 x 9.5 mm (0.375 inch) screws are for fastening to a plastic

attenuator pedestal base. The 4-40 x 7.9 mm (0.312 inch) are for fastening to

the bracket.

11716A/C Operating Note 3

Installation

4. Connect the rigid cable between the two attenuators. The lower

attenuator should be adjusted laterally so that the rigid cable connects

easily without strain.

5. Firmly tighten the two screws holding the lower attenuator to the

bracket.

6. If no sheet metal base is being used, the adhesive-backed felt feet that

are supplied may be attached to the underside of the bracket to prevent

marring the surface on which the combined attenuators are set. Figure 1

shows how the interconnection kit is typically used.

7. When using the sheet metal base, use the .375 long screws to connect the

attenuator bracket to the sheet metal base.

Figure 1 Typical Installation
