Agilent Technologies 16702B Bedienungsanleitung

Logic Analysis Systems

Publication Number 16700-97014

16allp01

Installation Guide

16700B

Measurement

Modules

16702B

16allp02

Contents

System Overview Agilent 16700B

System Overview Agilent 16702B

16522A

16517/18A

General Installations

16533/34A

16557D

16710/11/12A

16715-19A /50-52A

16720A

Mouse and Keyboard

Proper Cooling

Monitor Connection

Monitor Configuration 16700B

Changing Monitors

Printers

Software Installation

LAN

16701A/B Expander Frame

Probing

Self-Test

Specifications & Characteristics

Disaster Recovery

Saving System Settings

External Disk Drive 15

External Disk Drive & CD-ROM Drive

Reloading System Settings 36

Monitor Configuration 16702B 10

Multiframe 37

Proper Cleaning 40

Additional Connections

Keyboard

and

Mouse

Printer

and

Cable

Power Cable

16701A/B

Expander Frame

16allp04

Making Basic

Measurements

(If ordered)

Monitor

Monitor Cable

Monitor Power Cable

16700B Mainframe

Training Board and Training Kit

External Disk Drive and Cable

(Data Drive - Option 008)

(Boot Drive - Option 009)

16700B Overview

Additional Connections

Printer and

Cable

16702B

Mainframe

16701A/B Expander Frame

16allp05

Monitor

Monitor Cable and

Monitor Power Cable

(If ordered)

Making Basic

Measurements

Mouse and

Keyboard

Training Board and

Training Kit

16702B Overview

External Disk Drive and Cable

(Data Drive - Option 008)

(Boot Drive - Option 009)

Power Cable

To 16701 Expansion FrameTo 16701 Expansion Frame

Target

Control

Target

Control

Keyboard Mouse

Keyboard

Mouse

16700B

16702B

16allp06

Mouse & Keyboard

for 16700B/ 16702B

The 16700B must have the system mouse and keyboard connected for the system to boot

up properly.

Once enabled on the LAN, the system can be operated remotely without a keyboard or

mouse.

To 16701 Expansion FrameTo 16701 Expansion Frame

Target

Control

Target

Control

Keyboard Mouse

16700B

16702B

16allp07

If applicable, international versions of the power cables can be found in the accessories

box.

Monitor & Power Cable

(Optional for 16702B)

Monitor Connection

for 16700B /16702B

Power

Busy

Allow a minimum of 5 cm spacing between instruments for proper cooling.

16allp08

Power

Busy

>5cm

16700B

Proper Cooling

for 16700B/ 16702B/ Measurement Modules

16702B

16allp09

Enter

Monitor power

(Cycling choices)

System power

If you ordered the optional monitor with your logic analyzer, the monitor resolution setting is pre-

configured for 1280 x 1024 at the factory.

If you already have a monitor and ordered your logic analysis system without the optional

monitor, you will need to configure your monitor. The display will change on the screen every

few seconds as the system cycles through the monitor resolution choices. Make the appropriate

selection when it appears.

(Your monitor)

16700B

Monitor choice.

Clear

Images

Monitor Configuration

for 16700B

Press ENTER to select the

monitor choice and "Y" to

confirm.

16allp10

Use this procedure if you wish to configure an optional monitor to an 16702B.

Enter

Press ENTER to select the

monitor choice and "Y" to

confirm.

Monitor power

System power

Immediately press the

TAB key about ten times.

TabTab

Tab

(Cycling choices)

Monitor choice.

Clear

Images

Monitor Configuration

for 16702B
