AIRFLO AFV618 Bedienungsanleitung

Instruction Manual

Hush Power

AFV618

Know your vacuum cleaner

Important safety instructions

Do not use for absorbing detergent, kerosene,

glass, needle, cigarette ash, water, match etc.

The appliance should not be exposed to heat

Do not vacuum any moist or liquid substances ,

Never immerse the appliance in water.

Unplug the appliance from the mains supply

Socket after use and before every cleaning pull

the mains cable, in order to disconnect the

appliance from the mains

This appliance is not intended for use by

persons (including children) with reduced

physical,

sensory or mental capabilities, or

lack of experience and knowledge, unless they

have

been given supervision or instruction

concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure

that they do not play with the appliance

If the supply cord is damaged, it must be

replaced by the manufacture or its service

agent or a similarly qualified person in order to

avoid a hazard. For household use only

Important safety instructions

Do not put any object into openings. Do not

use with any opening blocked. Keep the

appliance free of dust, lint, hair etc.

Do not use the vacuum cleaner without dust

container or dust filter in place

Do not vacuum any flour, cement etc, in order

to avoid the overloads.

The appliance should only be cleaned with a dry

or damp cloth ,it should never immersed in water.

Do not use any solvents for cleaning

Assembly vacuum cleaner

Connect the hose with vacuum cleaner

Insert flexible hose into the air-intake:

Press the knob until it clicks into the position

Remove the flexible hose:

Unplug the appliance and press the knob at the end of the hose

Remove it from the air-intake opening.

Fit the telescopic to the angled pipe

Fit the floor brush to the telescopic tube

Operation

●A yellow mark on power co

rd shows the ideal cable

length. Do not expend the cable beyond the red mark

●To rewind the power cord, press the rewinder pedal

with one hand and guide the cord with the other hand

●press the power switch to switch the appliance on.

●

Use the electronic speed adjusting to control the

suction power of the cleaner

●

Set the required suction power by means of the

electronic suction regulator

●The suction power can be adjusted with the sliding

control on the angled pipe too

• If the suction flow is interrupted or the dust bag is full,

the indicator lights up red. Turn off the machine

immediately, and clean the inlet filter. Empty the dust

bag. Turn the unit on again

• Note: Pay attention to unusual noises when using the

device.

This could indicate a malfunction or a

blocked suction.

Cleaning tools

●Crevice tool:

For cleaning corner edge and draws etc:

Where is difficult to reach, such as gaps and the

keyboard, bookshelf and windows

●Sofa brush:

For cleaning bed, sofa, couch etc.

Use of the selector on floor brush :

Bristles extended for carpets.

Bristles retracted for hard floors

●If the angled pipe has blockage

Insert it into the air-intake and

switch the appliance on

Cleaning and maintenance

●Empty the dust container

⑴After removing the flexible hose ,press the cover

lock button and open the dust container

⑵Remove the dust filter form the container

⑶Replace the dust filter in the container.

⑷Close the dust container until it is locked in the position

●

Change filter

Replace the motor filter: Replace the outlet filter:

Open the dust container and remove the motor Detach the grille by pulling firmly away from

filter. Fix the new filter in the position the appliance, remove the outlet filter and

replace the new filter. Fix the grille again

Clean the filter

Clean the motor filter in water and allow them

to dry completely before replace

them.

Error detection:

Before you contact our services center, please check the following points

Problem Possible reason Active

Motor does not start

-Power card not firmly

plugged into outlet

-Outlet damaged

-Cleaner not switch on

-Plug unit firmly

-Check the outlet

-Switch on the appliance.

Suction power is weaker

-unit clogged

-Dust filter needs

cleaning

-Du

st container not in

position

-Filter blocked

-Remove the blockage

-Clean the dust filter

-Close the dust container

-Clean the filter

The wire can not be

winded completely .

The wire may diverge

the wire wheel.

Draw the wire a little then

rewind.

The wire can not be draw

out.

The wire may wind

disorder

Press the rewinder

button and try again.

Speed adjust does not

work

Appliance is defective

Repair the appliance

(only specialist)

Power card winds

unwanted back

Rewind mechanisms is

defective

Repair the appliance

(only specialist)

The dust container can

not be closed

Dust filter is not in the

position

Fix the dust filter and try

again

Warming:

If the supply card is damaged, It must be replaced by the

manufacturer or its server agent of a similarly qualified person in

order to avoid a hazarded.

Technical data

Rated voltage: 220-240V AC

Rated frequency: 50/60Hz

Power:

VL-614E-A 750W

Operating pressure: >18.0kPa

Sound level: <76dB(A)

Operating radius: 7M

Correct Disposal of this product

This marking indicates that this product should not be disposed with

other household wastes throughout the EU. To prevent possible harm

to the environment or human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable reuse of material

resources. To return your used device, please use the return and

collection systems or contact the retailer where the product was

purchased. They can take this product for environmental safe

recycling.

Warranty information

The manufacturer provides warranty in accordance with the legislation of the

customer’s own country of residence, with a minimum of 1 year (Germany:2

years).starting from the date on with the appliance is sold to the end user.

The warranty only covers defects in material or workmanship.

The repairs under warranty may only be carried out by an authorized service centre.

When making a claim under the warranty, the original bill of purchase (with purchase

date) must be submitted

The warranty will not apply in cases of:

-Normal wear and tear

-Incorrect use, e.g. overloading of the appliance, use of non-approved accessories

-Use of force, damage caused by external influences.

-Damage caused by non-observance of the user manual, e.g. connection to an

unsuitable mains supply or non-compliance with the installation instructions

-Partially or completely dismantled appliances
