AlkaViva Vesta H2 Montage- und Bedienungsanleitung
Vesta H2, Athena H2, Melody II
Manual Addendum
While AutoAdjust automatically provides very fine real-time adjustments to the pulse width, you can also manually
adjust the power to best suit your unique water quality and desired performance requirements. By manually changing
the power-steps for each Alkaline and Acidic level, you can change the main power settings, making bigger and more
impactful changes in performance. There are 4 Power Levels (1 –4). Power Level 1 is the lowest and Power Level
4 the highest. Follow this procedure to adjust the Power Levels:
1. Start with unit plugged in, water flow turned off..
2. Simultaneously press and hold the Alkaline 1 and Alkaline 2 buttons for 3—5 seconds, until the screen
looks like Fig. 1.
Fig. 1
3. Press and release the Alkaline 2 button 6 times. The display should now look like Fig. 2
Fig. 2
4. Each time the Acidic 1 button is pressed, the display will cycle through the alkaline and acidic levels,
first in Forward polarity and then in Reverse polarity. (refer to Fig. 3a, 3b, and chart 3c)
© AlkaViva, LLC 4/4/2017
Recommended Method for Manually Adjusting
Power Settings
5. Pressing and releasing the acidic 2 button will change the power step (indicated on the display by the
digit on the right.)
Fig. 3a Fig. 3b
Fig. 3c
6. When setting the power step for a particular level, for best results, be sure to set the power step to the
same setting for both the forward and reverse polarity.
7. When all levels are set as desired, simultaneously press and release the Alkaline 1 and Alkaline 2
buttons to return the display to stand by.
Level Forward Polarity
Displayed As:
Reverse Polarity
Displayed As:
Alkaline 1 1 11
Alkaline 2 2 12
Alkaline 3 3 13
Alkaline 4 4 14
Alkaline 5 5 15
Acidic 1 6 16
Acidic 2 7 17
