Allied Telesis AT-SPFXBD-LC-13 Bedienungsanleitung

Datasheet | Pluggable Transceivers

AT-SPFXBD

Small Form Pluggable (SFP) Modules

Allied T

elesis www.alliedtelesis.com

AT-SPFXBD-LC-13

15km, 100FX, BiDi SFP (1310/1550)

AT-SPFXBD-SC-13

15km, 100FX, BiDi SFP (1310/1550)

AT-SPFXBD-LC-15

15km, 100FX, BiDi SFP (1550/1310)

AT-SPFXBD-SC-15

15km, 100FX, BiDi SFP (1550/1310)

Industry Standard

The AT-SPFXBD-xx offers the latest industry

standard in Bi-Directional 100FX connectivity.

These hot swappable, fiber interfaces simply

plug into an SFP slot on an Allied Telesis 100FX

SFP compatible product.

Description

The AT-SPFXBD-xx is a 3.3V SFP BiDi

transceiver module designed for high-speed

applications which require up to 155Mbit/sec

transmission rates. It is compliant with Fast

Ethernet (100mbps), ATM, SONET

,OC-3/SDH,

and STM-1 standards, as well as the SFP

Multisource Agreement (MSA).

The SFP uses the industry standard SC

connector type.The transceiver includes a LOS

(Loss Of Signal) circuit that provides a TTL

logic-high output when an unusable optical

signal level is detected.The module includes

1310nm un-cool FP laser,InGaAs PIN, Pre-

amplifer and WDM filter in a high-integrated

optical assembly for high density system

application.

Using an SFP Bi-Directional transceiver can

upgrade transmission capacity on a typical

network without installing new fibers by utilizing

asingle fiber for both the send/receive signals.

Options

Allied Telesis offers a wide range of SFP

modules. Available in multi-mode and single-

mode, ranging in speed from Fast Ethernet to

Gigabit and with distances of up to 80km, Allied

Telesis offers options for your network.

Product Compatibility

The SPFX series SFPs are compatible with all

the Allied Telesis range of products that support

100Mbps SFP uplink connections.

Key Features

•SC or LC connector

•Connect up to 15km

•Compact size

•Hot swappable

•Self-locking mechanism

•Support for ATM, SONET, OC-3/SDH, STM-1

•Two year warranty

•RoHS compliant

•SFF-8472 MSA compliant

•Industrial operating temperature

•China RoHS

Specifications

Technical Specifications

Absolute Maximum Ratings

Recommended Operating Conditions

Specification of Transmitter

Ordering Information

AT-SPFXBD-LC-13

15km, 100FX, BiDi SFP (1310/1550)

AT-SPFXBD-SC-13

15km, 100FX, BiDi SFP (1310/1550)

AT-SPFXBD-LC-15

15km, 100FX, BiDi SFP (1550/1310)

AT-SPFXBD-SC-15

15km, 100FX, BiDi SFP (1550/1310)

AT-SPFXBD |Small Form Pluggable (SFP) Modules

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 T

ai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

elesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000274 Rev A

Model Media Type Wavelength Transmit

Max. Data Rate Operating Temp Distance

AT-SPFXBD-13 SMF 1310Tx/1550Rx 155Gbps 0to 70°C 15km

AT-SPFXBD-15 SMF 1550Tx/1550Rx 155Gbps 0to 70°C 15km

Parameter Symbol Min. Typ. Max. Unit Note

Storage Temperature TS-40 85 ºC

Storage Ambient Humidity HA5 95 %

Power Supply Voltage VCC 0 5 V

Signal Input Voltage -0.3 VCC+0.3 V

Optical Input Power (Peak) 4 dBm

Parameter Symbol Min. Typ. Max. Unit Note

Ambient Operating Temperature TS0 70 ºC

Ambient Humidity HA5 85 % Non-condensing

Power Supply Voltage VCC 3.13 3.3 3.47 V

Power Supply Current ICC 250 mA

Power Supply Noise Rejection 100 mVp-p 100Hz to 1MHz

Data Rate 10 155.52 Mbps

Transmission Distance 15 km

Parameter AT-SPFXBD-13 AT-SPFXBD-15

Symbol Min. Typ. Max. Unit Symbol Min. Typ. Max. Unit

Average Launched Power Po -14 -8 dBm Po -14 -8 dBm

Optical Extinction Ratio ER 10 dB ER 10 dB

Center Wavelength λc1260 1310 1360 nm λc1480 1520 1580 nm

Spectrum Width (RMS)

6 nm

3 nm

Transmitter OFF Output Power POff -45 dBm POff -45 dBm

Optical Rise/Fall Time tr/tf1.3 ns tr/tf1.3 ns

Total Jitter TJ 1 ns TJ 1 ns

Optical ReturnLoss Tolerance ORLT 14 dB ORLT 14 dB

Relative Intensity Noise RIN -116 dB/Hz RIN -116 dB/Hz

Dispersion Penalty TDP 1 dB TDP 1 dB

Output Eye Mask Compliant with Bellcore TR-NWT-000253

and ITU recommendation G.957

Compliant with Bellcore TR-NWT-000253

and ITU recommendation G.957
