Datasheet | integrated Multiservice Access Platform

iMAP Express 7112

integrated Multiservice Access Platform

The iMAP Express 7112 is a member of Allied

Telesyn’s iMAP family of IP-based integrated

multiservice access platforms. The 7112 is 1RU

and is optimal for delivery IP based services

including IP Video and high speed Internet.

Leveraging the same core technology as the

modular iMAP 9000 series of products, the 7112

is best suited for small density, cost-effective

deliveryof ADSL2+ services

Small enough for remote cabinet or CO

deployments, the 7112 also offers optional AC

power kits that enable Service Providers or

Enterprise customer’s deployment flexibility -

CO, RT, MDU/MTU, Hospitality and Enterprise.

Dense ADSL2+ Delivery

The 7112 supports 48 ports of ADSL2+

(Annex A) from a single RU. Utilizing Allied

Telesyn’sADSL2+ optimized amphenol

connectors, the 7112 ensures maximum Rate

vs. Reach performance.

Networking Capabilities

With support for Allied Telesyn’s Ethernet

Protection Switched Ring and RSTP, the 7112

offers numerous flexible network deployment

options – Rings, point-to-point, hub and spoke,

and mesh. Whether using SFP based GbE or Fast

Ethernet, the 7112 enables seamless integration

into any Service Provider or Enterprise network.

Pay as you grow Scalability

Stacking capabilities ensures pay as you grow

Access with common network transport per

location. Using either Fast Ethernet or GbE, the

7112 units can be stacked together in either

daisy chain or ring fashion. Aggregate network

traffic can be transported from single or multiple

Fast Ethernet or GbE uplinks thereby minimizing

networktransportcosts.

Service Differentiation

QoS schemes for iMAP access solutions are

designed to ensure that application performance

and availability are not impacted with network

growth. Features such as IPDiffServ and 802.1p/q

enable tiered data services for both residential

and business/enterprise users.

Manageability

All iMAP access solutions are designed to be

managed and provisioned remotely using Allied

Telesyn's AlliedView™ Network Management

Software (NMS), a comprehensive network

management platform designed to increase

networkuptime and throughput while reducing

operating expense.

iMAP Express 7112 System

Configuration

1RU system (Fixed Configuration)

•1control module slot

•48 ADSL2+ ports

iMAP Express 7112 Key Features

•Carrier-class IP/Ethernet access

•Video-optimized for IP Triple Play services

•IGMPv2 with Fast Joins/Leaves

•Environmentally-hardened

•Dual DC Power Feeds

•Optional AC Power kit

•Industry standard ADSL2+

•Network compatible with iMAP 9000 family

of products

•ETSI and ANSI compliant

•Managed via AlliedView NMS

•Stacking for managed scaling

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000095 Rev. B

iMAP Express 7112 |integrated Multiservice Access Platform

Ordering Information

iMAP Express Accessories

Model Description Part #

Optimized Splitter Chassis 3RU, 4 slot POTS Splitter Chassis AT-TN-S004-A

Optimized Splitter Card 24-port Splitter card AT-TN-S101-A

CPE Attenuator ADSL2+ Attenuator AT-TN-S900-A

SFP – 13dB 1310nm SM SFP, 13dB Optical Budget AT-TN-P000-A

SFP – MM 850nm MM SFP, 12db Optical Budget AT-TN-P001-A

SFP – 24dB 1550nm, SM SFP, 24dB Optical Budget AT-TN-P002-A

SFP – 18dB 1310nm, SM SFP, 18dB Optical Budget AT-TN-P003-A

Optimized Splitter Cable ADSL24 to High Performance Splitter Cable AT-TN-C013-A-XX**

Standard Splitter Cable ADSL24 to Standard Splitter Cable AT-TN-C018-A-XX**

iMAP Express 7112

Model Description Part #

iMAP Express 7112 Fixed 1RU Configuration, 48 ADSL2+ ports AT-TN-7112-A

iMAP Power Options

Model Description Part #

AC Power Kit 7100 AC power kit AT-TN-R108-A-YY*

Specifications

Uplinks

2100BT Ethernet

2Gigabit Ethernet (SFP)

Physical Characteristics

Dimensions: 44cm x 30cm x 4.45cm

17.4” x 11.9” x 1.75” (W x D x H)

Weight: 8.8lbs

Rack Unit: Single Rack Unit

Access: Full Frontal Access

Power Characteristics

Dual -48v DC, -36v DC to -57.7v DC

100-220V AC and 50-60Hz (using Optional AC Power kit)

Max Power: 154W

ADSL Standards

ITU-T G.992.1 (ADSL, S = 1/2, G.DMT, T1.413)

ITU-T G.992.5 (ADSL2+)

Annex A (ONLY)

ADSL Port Specifications

Interface Type: RJ21 (Qty 2)

Number of VCs per port: 4

Number of priority queues per VC: 8

Dropped packet counter: Yes

Full traffic classifier support: Yes

Full traffic classifier action support: Yes

ARP Filtering: Yes

Ingress Metering: Yes (1Mbps increment)

Peak Cell Rate Limiting per VC: Yes

Ingress Max Burst Size: 64kbps

Egress Max Burst Size: 64kbps

Environmental Specifications

Operating Temp: -40C to 65C

Storage Temp: -40C to 85C

Relative Humidity: 5% to 95%, non-condensing

Regulatory Approvals

FCC Part 15 Class A/ANSI C63.4

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

VCCI Class A; ITE/ CISPR 22:1997 Class A

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998

EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996

EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999

UL/cUL 60950: IEC60950

NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2

USDA RUS

Standards and Compliance

IEEE 802.1d,w Rapid Spanning Tree

IEEE 802.1q MEV (Double Tagging)

IEEE 802.1p Traffic Class Expediting

IEEE 802.3ad Link Aggregation

IETF RFC 1112 IP Multicasting/IGMP Snooping v1

IETF RFC 2236 IP Multicasting/IGMP Snooping v2

IETF RFC 3619 EAPS w/ATI Extensions for EPSR

IETF RFC 2131 DHCP

IETF RFC 1350 TFTP

*Where YY =10 for U.S.power cord

=20 for no power cord

=30 for U.K. power cord

=40 for Australia power cord

=50 for Europe power cord

**Where XX =005 for 5 ft

=010 for 10 ft

=015 for 15 ft

=020 for 20 ft

=030 for 30 ft

=040 for 40 ft

=050 for 50 ft

=060 for 60 ft

=070 for 70 ft

=080 for 80 ft

=090 for 90 ft
