Allied Telesis www.alliedtelesis.com

Datasheet | integrated Multiservice Access Platform

NTE8

AT-TN125-A 8 Port T1/E1 MLPPP Service Module

Allied Telesis’ iMAP family of integrated

Multiservice Access Platforms

Bonded

T1/E1 Ports using MLPPP

for Network Backhaul

Remote locations have often been ignored by

Service Providers due to the lack fiber

infrastructure between COs and remote

terminals/locations. As the rest of the last mile

network converges on IP/Ethernet delivery

technologies, these locations need a means to

leverage IP/Ethernet while also offering legacy

POTS and last mile broadband services.

The NetworkTerminating Equipment (NTE8) 8

portsubscriber module is ideal for delivery of

converged POTS and DSL services to remote

locations. Using MLPPP as a bonding

technology, one to 8 ports can be bonded

together to deliver up to 16Mbps of bandwidth

to remote locations fed by traditional T1/E1

circuits. Since the NTE8 uses MLPPP as the

bonding protocol for the 8 individual T1/E1

ports, all ports will carry converged POTS,VoIP

and Data traffic - either collectively or

individually. If port or network outages disable

individual T1/E1 ports on the NTE8 module,

the remaining MLPPP bundled circuits will

continue to carry network traffic.

The NTE8 service module is intended to be

used in any of the iMAP product chassis. In

addition, individual NTE8 modules at a central

location can be used to aggregate traffic from

multiple remote locations. All traffic is mapped

to service carrying VLANs for proper traffic

segmentation and classification.

Provide Business Router

Connectivity

The secondaryapplication that is supported by

the NTE8 service module is providing last mile

access to small and medium sized businesses

utilizing T1/E1 PPP uplinks. As last mile access

continues to evolve, Service Providers can

leverage the same last mile access infrastructure

used to deliver residential services to delivery

T1/E1 services.

Business routersemploying PPP over T1/E1

WAN uplinks can use the NTE8 to terminate

data circuits and transporttraffic over standard

VLAN circuits throughout the last mile

network. Using iMAP elements at a central

location,VLANs can be switched to the

appropriate IP Data network. Leveraging

standards based IP/Ethernet technologies, the

iMAP and NTE8 service modules truly

converge all traffic - residential and business.

Partof a IP Broadband Access

Family

Whether it is broadband ADSL2+, FTTH or

POTS, the iMAP family is the ideal platform for

last mile service delivery.The NTE8 line card

can be used with anyof the iMAP familyof

carrier grade, IP Multiservice Access platforms:

•iMAP 9700 (9RU, 17 service slots)

•iMAP 9400 (3RU,7service slots)

•MiniMAP 9100 (1RU,3service slots)

Provisioning, management, and diagnostics of

subscriber ports can be accomplished from

either the iMAP command line interface or the

NMS.

The AT-TN125 has been designed to survive

the most rugged environmental conditions. It

can be confidentlydeployed in either a central

office or in outdoor enclosures withstanding

extremes of heat, cold, and light exposure.

Key Features

•8T1/E1 ports

•Support for MLPPP Encapsulation

•Network WAN Connectivity Between iMAPs

•Business CPE Support

•Support for Multiple Remote Locations

•Flexible control of traffic priorities for voice,

data and Business applications

•QoS

•Four Queues

•Priority scheduling

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000108 Rev. C

NTE8 |AT-TN125-A 8 Port T1/E1 MLPPP Service Module

*Where XX = 10 for U.S. power cord

=30 for U.K. power cord

=40 for Australia power cord

=50 for Europe power cord

**Where YY =005 for 5 ft

=010 for 10 ft

=015 for 15 ft

=020 for 20 ft

=030 for 30 ft

=040 for 40 ft

=050 for 50 ft

=060 for 60 ft

=070 for 70 ft

=080 for 80 ft

=090 for 90 ft

Ordering Information

iMAP 9x00 Chassis

Model Description Part #

iMAP 9700 17-slot chassis with DC power with faceplates AT-TN-250GF

iMAP 9700 17-slot chassis with DC power without faceplates AT-TN-250G

iMAP 9400 7-slot chassis with DC power with faceplates AT-TN-251GF

iMAP 9400 7-slot chassis with DC power without faceplates AT-TN-251G

MiniMAP 9101 3-slot mini chassis with DC power AT-TN-9101-A-80

MiniMAP 9102 3-slot mini chassis with AC power AT-TN-9102-A-XX*

NTE8

Model Description Part #

NTE8 8ports, T1/E1 MLPPP Service Module AT-TN-125-A

iMAP Common Control

Model Description Part #

CFC24 24GbE switch controller card AT-TN-401-B

GE3 3x GbE WAN interface card AT-TN-301-A

CFC56 56 GbE switch controller card AT-TN-407-A

XE1 10GbE WAN interface card AT-TN-308-A

CFC12 12GbE switch controller card AT-TN-408-A

Interface Specifications

Number of ports: 8

Connector: RJ-21 (Female)

T1Specifications

Line rate: 1.544Mbps

Line code: AMI or B8ZS

Framing: ESF, SF

E1 Specifications

Line rate: 2.0484Mbps

Line code: AMI or HDB3

Framing: G.704, CFC4 or no-CRC4

Other Specifications

Timing Source: Loop timed, Card timed

Holdover Accuracy: Stratum 4 local oscillator

RFC1661 – Point-to-Point Protocol (PPP)

RFC1990 – PPP Multilink Protocol (MP)

RFC1570 – PPP LCP Extensions

RFC3518 – Point-to-Point Protocol (PPP) Bridging

Control Protocol (BCP)

Power Requirements

Maximum power: 17W

Environmental Conditions

Operating Temp: -40C to 65C

Storage Temp: -40C to 75C

Relative Humidity: 5% to 95%, non-condensing

Regulatory Approvals

FCC Part15 Class A/ANSI C63.4

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

VCCI Class A; ITE/ CISPR 22:1997 Class A

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998

EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996

EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999

UL/cUL 60950: IEC60950

NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2

USDA RUS

Related iMAP Line Cards and Accessories

Model Description Part #

POTS24 24-port, POTS Service Module AT-TN-113-A

CES8 8-port, T1/E1 Circuit Emulation Service Module AT-TN-119-A

PAC24 24-port, POTS/ADSL2+ Combo w/Splitters, Annex A AT-TN-123-A

SHDSL24 24-port, G.SHDSL Service Module AT-TN-127-A

VDSL24 24-port, VDSL2 Service Module, Annex B AT-TN-128-A

ADSL24SA 24-port, ADSL2+ w/Splitters, Annex A AT-TN-129-A

NTE8 Cable NTE8 RJ21 to Unterminated AT-TN-C021-A-YY**

Filler Full size service slot filler plate AT-TN-M000-A
