Datasheet | integrated Multiservice Access Platform

FX10LX

AT-TN107-A 10 Port 100Mbps LX FTTx Service Module

Fiber to the Home/Business over

Dual Fiber

The FX10LX is one of three Allied Telesis

FTTH/B service modules for the iMAP product

family.This card provides 10 ports at 100Mbps

(full-duplex) over two fibers(Single-mode). Also

available are Single-mode single fiber and Multi-

mode dual fiber variations. The Gigabit feed

into the iMAP backplane allows the FX10

modules to operate completely at wirespeed.

The additional Layer 2+ switching allows

Service Providersto meet the demands of

multi-cast IP video,Video on Demand, voice and

data services. With the FX10 modules, you can

be assured future bandwidth needs of HDTV

will be addressed as consumer demand

increases.

Allied Telesis’ OAM solution allows for individual

full configuration and monitoring of each port.

The FX10 modules provide configuration tools

to:

•Control or limit subscriber access

•Enforce port security rules

•Limit services to a port

•Manage QoS across the card

•Support network double-tagging

•Control ingress or egress service rates

A multitude of applications can be supported

with the fiber-based 100Mbps access interfaces

including:

•FTTH for Voice,Video and Data Services

•FTTB for IP PBX, Ethernet and VPN services

•Campus LAN network uplinks

Whether it is derived voice or HDTV IP Video,

the FX10 will satisfy all bandwidth and mission

critical services with ease.

Part of Allied Telesis’ IP Broadband

Access Family

Whether it is broadband ADSL2+, FTTH, POTS

or T1/E1 circuits, the iMAP family is the ideal

platform for last mile service delivery.The

FX10LX line card can be used with any of the

iMAP family of carrier grade, IP Multiservice

Access platforms:

•iMAP 9700 (9RU, 17 service slots)

•iMAP 9400 (3RU, 7 service slots)

•MiniMAP 9100 (1RU, 3 service slots)

Provisioning, management, and diagnostics of

subscriber ports can be accomplished from

either the iMAP command line interface or the

NMS.

The FX10LX has been designed to survivethe

most rugged environmental conditions. It can be

confidentlydeployed in either a central office or

in outdoor enclosures withstanding extremes of

heat, cold, and light exposure.

Allied T

elesis provides a large portfolio of FTTx,

Ethernet and xDSL transport and access

equipment. In addition, Allied Telesis provides a

complete set of xDSL and FTTx CPE solutions

in the form of Multiservice Gateways, Layer 2/

Layer 3 switches, routers or media converters

to terminate the broadband link.

Key Features

Port-based

•VLANs

•VLAN translation

•Double-tagging (HVLAN)

•Filtering

•Ingress Metering

•Egress port rate limiting

•Countings

•Classification and remarking

•RMON

QoS

•Four Queues

•Priority scheduling

Security

•MAC limiting (up to 64)

•MAC flooding – VLAN-based

Services

•STP and RSTP

•Video-optimized

•Upstream forwarding only

Support for

•Business services

•Residential service

•Dual fiber, Single-mode

AT-TN107-A 10 Port 100Mbps LX FTTx Service Module

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000047 Rev. D

FX10LX |AT-TN107-A 10 Port 100Mbps LX FTTx Service Module

Interface Specifications

Number of ports: 10

AT-TN107: Single-mode, Dual Fiber

TxRx 1310nm

16dB Optical Budget

SFF with LC Connector

Backplane capacity: 1Gbps

Physical design: Front Access

Protocols and Specifications

IEEE 802.1d,w Rapid Spanning Tree

IEEE 802.1D Bridging

IEEE 802.1Q VLAN Bridging

IEEE 802.1p Prioritization

IEEE 802.3ah EFM OAM

IEEE 802.3ad Link Aggregation

IETF RFC 1112 IP Multicasting/IGMP Snooping v1

IETF RFC 2236 IP Multicasting/IGMP Snooping v2

DHCP Relay Agent option 82 (RFC 3046)

Power Requirements

Maximum power 37W

Environmental Conditions

Operating Temp: -40C to 65C

Storage Temp: -40C to 75C

Relative Humidity: 5% to 95%, non-condensing

Regulatory Approvals

FCC Part 15 Class A/ANSI C63.4

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

VCCI Class A; ITE/ CISPR 22:1997 Class A

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998

EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996

EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999

UL/cUL 60950: IEC60950

NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2

USDA RUS

Ordering Information

iMAP 9x00 Chassis

Model Description Part #

iMAP 9700 17-slot chassis with DC power with faceplates AT-TN-250GF

iMAP 9700 17-slot chassis with DC power without faceplates AT-TN-250G

iMAP 9400 7-slot chassis with DC power with faceplates AT-TN-251GF

iMAP 9400 7-slot chassis with DC power without faceplates AT-TN-251G

MiniMAP 9101 3-slot mini chassis with DC power AT-TN-9101-A-80

MiniMAP 9102 3-slot mini chassis with AC power AT-TN-9102-A-XX*

*Where XX = 10 for U.S. power cord

=20 for no power cord

=30 for U.K. power cord

FX10LX

Model Description Part #

FX10LX 10ports, 100Mbps LX Single-mode, Dual fiber AT-TN-107-A

iMAP Common Control

Model Description Part #

CFC24 24GbE switch controller card AT-TN-401-B

GE3 3x GbE WAN interface card AT-TN-301-A

CFC56 56 GbE switch controller card AT-TN-407-A

XE1 10GbE WAN interface card AT-TN-308-A

CFC12 12GbE switch controller card AT-TN-408-A

Related iMAP FTTX Line Cards

Model Description Part #

FTTX (MM) 10-port100Mbps multimode fiber line card AT-TN-104-A

FTTX (SM, Single Fiber) 10-port100Mbps singlemode, single fiber line card AT-TN-109-A

GE8 8-port GbE line card AT-TN-117-A

GEPON2 2-port GEPON line card AT-TN-118-A

Filler Full size service slot filler plate AT-TN-M000-A

Related FTTX CPE

Model Description Part #

RG613LH intelligent Multiservice Gateway, 3x LAN, 2x FXS,

Dual fiber WAN interface

AT-RG613LH-10

=40 for Australia power cord

=50 for Europe power cord

Allied Telesis’ iMAP family of integrated

Multiservice Access Platforms
