AT-TN7100 SERIES

Multiservice Access Platform

MULTISERVICE ACCESS PLATFORM

AT-TN7101

Multiservice access plaform with 48 ADSL ports

(without POTS splitters)

AT-TN7102

Multiservice access plaform with 24 ADSL ports

(with POTS splitters)

THE AT-TN7100:THE TRIPLE PLAY

SOLUTION

The AT-TN7100 delivers high-quality voice, tiered

IP/Ethernet data services, and broadcast-quality

video over existing copper lines. As the newest

member of Allied Telesyn’s TN7000 series of

Multiservice Access Platforms, the AT-TN7100—

together with Triple Play—helps carriers grow rev-

enue and enhance subscriber loyalty.

The Allied Telesyn TN7100 features three card

slots and an environmentally hardened structure

designed for installation in remote enclosures

where reliability is critical.

DELIVERING QOS AND SECURITY

The Allied Telesyn TN7100 employs industry stan-

dard ADSL/ ADSL2+.The AT-TN7100 makes effi-

cient use of network bandwidth by employing

IGMP Snooping to limit broadcast video-streaming

to those channels being watched.The platform also

prevents channel theft with advanced subscriber

filtering capabilities.

Quality of Service implemented with 802.1p prior-

ity bits four classes of service, and Layer 3+ classifi-

cation work together to eliminate jitter and net-

work delay, and to ensure that video and voice

receive network priority.

EASY TO MANAGE

The AT-TN7100 is available in two configurations:

24 ports with integral POTS splitters and 48 ports

without POTS splitters. Also, subtending capabilities

built into the AT-TN7100 make it easy to add

capacity.

The AT-TN7100 and all the members of Allied

Telesyn’s TN7000 series can be managed remotely

and provisioned through the Allied Telesyn

Network Management System (NMS), eliminating

the need for on-site service. Additionally, all net-

work and local management interfaces are located

on the front panel for easy maintenance access.

KEY FEATURES

Designed for Triple Play services:

•Based on IP/Ethernet

•Industry-standard ADSL, upgradeable to ADSL2+

•Rapid Spanning Tree

•IGMP for multicast video

•Quality of Service support

•Subscriber filtering and security

Carrier class:

•Environmentally hardened

•Compact, one RU tall design

•Up to 48 ports

•Integral POTS splitters available

•Centrally managed

AT-TN7100 SERIES

Multiservice Access Platform

SERVICES

ADSL 10, 12, 24Mbps

UPLINKS

2 100BT Ethernet

2 Gigabit Ethernet

QOS

Wirespeed QoS per port

4 Classes of Service

802.1p marking

Classification by TOS

Support for 256 VLANs

SUBSCRIBER SECURITY

Subscriber filtering

RFC 3046, DHCP Relay for IP management

OAM&P

Auto-Provisioning

Management via CLI, SNMP

In-band and out of band network management with Telesyn

NMS

POWER CHARACTERISTICS

Power Dual -48vDC, -36vDC to -57.7vDC

ENVIRONMENTAL SPECIFICATIONS

Operating Temp. -40°C (-40°F) to 65°C (149°F)

Non-operating Temp. -40°C (-40°F) to 85°C (185°F)

Relative Humidity 5% to 85%, non-condensing

PHYSICAL CHARACTERISTICS

Height 4.4cm (1.75")

Width 44cm (17.375")

Depth 30cm (11.8")

Weight 4kg (8.8lbs), fully loaded

Single Rack Unit

Full front access

STANDARDS

IEEE

802.1d Spanning Tree

802.1w Rapid Spanning Tree

802.1q 256 VLAN Support

802.1p Traffic Class Expediting

IETF

RFC 1112 IP Multicasting / IGMP Snooping

REGULATORY APPROVALS

NEBS Level 3-Compliant GR-1089, GR-63

Safety UL 1950

EMC FCC Part 15 Class A

ORDERING INFORMATION

AT-TN7101

Multiservice access platform with

48 ADSL ports (without POTS splitters)

AT-TN7102

Multiservice access platform with

24 ADSL ports (with POTS splitters)

ABOUT ALLIED TELESYN

Allied Telesyn was founded in 1987 with the goal of producing reliable, standards-based

networking products. Focused on Ethernet/IP solutions geared to applications, Allied Telesyn

offers access-edge products like switches, fiber/copper MAPs, and CPE.We’re also a leading

global manufacturer of media converters, unmanaged switches, and NICs. Our customer-driven

approach has made Allied Telesyn the ideal choice for IT professionals looking for high-quality,

feature-rich network solutions at a lower price.Allied Telesyn – It’s Our Network,Too.

www.alliedtelesyn.com

All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.

617-00546-00 Rev.C

USA Headquarters 19800 North Creek Pkwy, Suite 200, Bothell, WA 98011, USA

Tel 800.424.4284 Fax 425.481.3895

European Headquarters Via Motta 24, 6830 Chiasso, Switzerland

(Corporate) Tel (+41) 91 697.69.00 Fax (+41) 91 697.69.11

(European Sales) Tel (+39) 02 414.112.1 Fax (+39) 02 414.112.61
