Ameriwood HOME 2129341COM Bedienungsanleitung

2129341COM

FireplaceMantel

B342129341COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

32129341010

RightPanel

32129341020

Top

32129341030

Bottom

32129341040

Shelf

32129341050

VerticalRail(x2)

32129341070

TopRail

32129341080

BottomRail

32129341090

Back

32129341060

MiddleRail

32129341100

6

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x12)

#A22700

camlock

(x12)

#A22710

cambolt

(x6)

#A21670

wood dowel

(x10)

#A22760

quicklock

(x6)

#A23030

confirmat screw

(x3)

#A53510

angle bracket

(x13)

#A12120

716" pan head

(x1)

#A53655

bracket

(x1)

#A84000

safety strap kit

(x1)

#A95020

fireplace insert

9b 9c

9d 9e

7

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

234

(x2) (x4) (x1) (x3)

Insertquicklocks(4)intoholesinleftpanel(A).Pressverticalrail(G)

againstfrontedgeofleftpanel(A)engagingthequicklocks(4).Turn

quicklocks(4)clockwisetolockbothpartsinplace.Installrestof

hardwareasshown.

Turnclockwisetolock

bothpartsinplace.

8

ameriwoodhome.com

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

234

Turnclockwisetolock

bothpartsinplace.

(x2) (x4) (x1) (x3)

Insertquicklocks(4)intoholesinrightpanel(B).Pressverticalrail(G)

againstfrontedgeofrightpanel(B)engagingthequicklocks(4).Turn

quicklocks(4)clockwisetolockbothpartsinplace.Installrestof

hardwareasshown.

9

ameriwoodhome.com

STEP3

(x4) (x1)

9a 9c

FinishedEdge

10

ameriwoodhome.com

STEP4

(x6)

(x3)

Do not fully tighten the screws

going into the top (C) at this time.
