Ameriwood HOME 6786015COM Bedienungsanleitung

6786335COM

6DrawerDresser

B346786000COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com AssemblyDifficultyMeter

Easy Tough

WARNING

Thispieceoffurniturecanoverturnandcauseserious

injuries&ordeath.

Anchorthefurnituretoastudinthewall(ifthisisrequired).

Donotallowchildrentoclimbonfurniture

Keepheavieritemsonlowershelves.

6786015COM

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

36786015010

RightPanel

36786015020

Top

36786015040

Bottom

36786015060

SideKick(2)

36786015050

Partition

36786015030

LeftDrawerFront(3)

36786015080

LeftDrawerSide(6)

39991167346410L

RightDrawerSide(6)

39991167346410R

DrawerBack(6)

39991167060218B

DrawerBottom(6)

39991340061310D

Thispieceispaperboard

construction.Itisnotmade

fromwood,butisrequired

fortheassemblyofyourunit.

BackPanel

K678600000

CenterKick

36786015070

RightDrawerFront(3)

36786015090

ABC

HIDWR

BACK

DWR

BTM

BACK

PANEL

LEFT

DWR

SIDE

RIGHT

DWR

SIDE

6

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

36786335010

RightPanel

36786335020

Top

36786335040

Bottom

36786335060

SideKick(2)

36786335050

Partition

36786335030

LeftDrawerFront(3)

36786335080

LeftDrawerSide(6)

39991167346410L

RightDrawerSide(6)

39991167346410R

DrawerBack(6)

39991167060218B

DrawerBottom(6)

39991340061310D

Thispieceispaperboard

construction.Itisnotmade

fromwood,butisrequired

fortheassemblyofyourunit.

BackPanel

K678600000

CenterKick

36786335070

RightDrawerFront(3)

36786335090

ABC

HIDWR

BACK

DWR

BTM

BACK

PANEL

RIGHT

DWR

SIDE

LEFT

DWR

SIDE

7

ameriwoodhome.com

BoardIdentification

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butisrequired

fortheassemblyofyourunit.

BACK

PANEL

DWR

BACK

DWR

BTM

DWR

BTM I

DWR

BACK

RIGHT

DWR

SIDE

LEFT

DWR

SIDE

RIGHT

DWR

SIDE

LEFT

DWR

SIDE

8

ameriwoodhome.com

PartList

ActualSize

NotActualSize

578

(x10)

#A22700

cam lock

(x10)

#A22710

cam bolt

(x3)

#A21660

wood dowel

(x6)

#A23030

confirmat screw

(x46)

#A21110

nail

(x60)

#A12120

#8X7/16"pan

(x4)

#A22760

quickloc

(x60)

#A11080

#6X7/16"flat

Notethatyourunitmaycontainextrahardware

(x24)

#A21975

metal drive fastener

(x12)

#A17400

7/8"8‐32thread

(x12)

#A54520

drawerbracket

(x6)

#A50415

handle

9

ameriwoodhome.com

PartList

13a

13b

13c

13d

(x6)

#A56740

slidekit

NotActualSize

(x6)

#A54900

metaldrawerbrace

(x1)

#A84050

safety bracket kit

15a

15b

15c

15d

10

ameriwoodhome.com

STEP1

markedwithan"L"

(x2)

(x1)

(x9)

13a

(x3)

Propercam

orientation

13a
