8208500COM

BookcaseRoomDivider

B348208500COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

OptionB

OptionA

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

38208408010

RightPanel

38208408020

Partition

38208408030

Top

38208408040

Bottom

38208408050

LeftShelf

38208408060

RightShelf

38208408070 Upright(x2)

38208355090

Shelf(x4)

38208408080

5

ameriwoodhome.com

BoardIdentification

Notactualsize

6

ameriwoodhome.com

PartList

ActualSize

Items#5&7NotActualSize

(x20)

#A23030

confirmat

(x14)

#A14220

1/2"screw

(x16)

#A80250

shelfsupport

(x8)

#A22910

connectorbolt

(x8)

#A22920

connector

(x1)

#A84050

safetybracketkit

(x2)

#A95530

7

ameriwoodhome.com

STEP1

(x12)

ThissideofPartitionhas3holes.

Holesshouldbetotop.

NOTE:

The right side of the Top and Bottom

does not have surface holes at top edge.

8

ameriwoodhome.com

STEP2

(x8)

PositionConnectorasshownand

tapintoholewithhammer.

9

ameriwoodhome.com

STEP3

(x4)

Withthehelpofanotherperson,placetheunitonitsRightPanel(B).

PositiontheUpright(I)asshownandattachbyscrewingintoendholesofUpright.

Makesurethecenter

endholeisatthis

end.

This is a reference

hole only to determine

that this is the top

edge of part I.

10

ameriwoodhome.com

OptionA

OptionB

ForOptionA,see

assemblysteps4to10.

ForOptionB,see

assemblysteps11to16.
