Ameriwood HOME 8689013COM Bedienungsanleitung

8689013COM

Fireplace TV Stand-White

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B348689013COM00SF

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Follow Ameriwood Home

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Follow Ameriwood Home

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a R (right) and L (left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

PEOPLE NEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not Actual Size

Top panel

T8689013010SF

ameriwoodhome.com

Top shelf apron

T8689013060SF

Bottom panel

T8689013020SF

Side panel

T8689013030SF

QTY: 2 PCS

Left partition

T8689013040SF

Right partition

T8689013050SF

Board Identification

Not Actual Size

Left partition rail

T8689013070SF Right partition rail

T8689013080SF

Adjustable central foot

T8689013090SF

Back panel

T8689013100SF

QTY: 2 PCS

Glass shelf

T8689013110SF

QTY: 2 PCS

ameriwoodhome.com

Board Identification

Not Actual Size

Front leg

T8689013120SF

ameriwoodhome.com

Rear leg

T8689013130SF

Fireplace

FA23V60L-C7

Support tube

T8689013140SF

QTY: 2 PCS

Remote control FA23V60L-C701

Acrylic crystal FA23V60L-C702

LED light bar (2) FA23V60L-C703

ameriwoodhome.com

Board Identification

Not Actual Size

Actual Size

Part List

ameriwoodhome.com

Hardware Bag Reference Number:

28689013COM0SF

x 22

Ø8X30mm

Wood dowel

TSF0501

Ø3.5X14mm

Screw

TSF1201

2x 24

Ø4X12mm

Screw

TSF1004

4x 10

Ø1/4X15mm

Bolt

TSF1404

3x 10

x 6

Ø3.5X14mm

Screw

TSF0805

x 6

Screw

TSF1213

Ø3X12mm

Bolt

TSF1402

Ø1/4X35mm

5x 2

Not Actual Size

Part List

Hardware Bag Reference Number:

28689013COM0SF

Shelf support

TSF0552

10 x 8

Cam bolt

TSF0355

x 23

Cam lock

TSF0308

9x 23x 1

Glue

TSF0015

x 12

Ø7X13XT1.5mm

Washer

TSF2453

x 1

M4X54mm

Hex key

TSF2801

x 2

61X35X20(T1.5)

Angle Bracket

TSF0012

x 2

Metal plate

TSF2401

WARNING

ADVERTENCIA

AVERTISSEMENT

Warning label

TSF2904

19 x 1

x 2

Wire clip

TSF2852

x 12

Ø7 X10XT1.5mm

Spring washer

TSF2451

x 8

Cam cover

TSF3511

HD-02

ameriwoodhome.com

STEP

x 8

Ø8X30mm

810 x 19

x 2

lue

Wooden Dowel

Hole for wooden dowel

Use one drop of glue in dowel hole.
