Anemoment TriSonica Mini Bedienungsanleitung

ANEMOMENT LLC

TriSonica Mini Sensors

User

Manual

0 Release Date 9 July 2021 Anemoment LLC

1 Release Date 9 July 2021 Anemoment LLC

ANEMOMENT LLC

TriSonica Mini Sensors: User Manual

2021 Anemoment LLC

353 Main Street

Longmont, CO 80501

Phone 720.600.7241 • Fax 720.223.7504

Email: info@anemoment.com

2 Release Date 9 July 2021 Anemoment LLC

NOTES:

Sensor Unit Numbers: ___________________________________________________

Purchase Date: _________________________________________________________

3 Release Date 9 July 2021 Anemoment LLC

Table of Contents

Hello World!...............................................................................................................................5

Guide to User Manual ............................................................................................................. 5

The TriSonica Mini Family of Products..................................................................................... 5

Tell Us!....................................................................................................................................6

Limitation Alerts......................................................................................................................6

Compact Fluorescent Lamps................................................................................................6

Electro-Mechanical Motors and Magnetic Sensors .............................................................. 6

Ice and Snow.......................................................................................................................7

Just the Facts, Ma’am..........................................................................................................7

Sorry, No Apples Today .......................................................................................................7

Wind Tunnels & Ultrasonic Frequency................................................................................. 7

TSM Body, Drawings, & Mounting Specifications.......................................................................9

TSM Sensor Body Composition................................................................................................9

Orientation .............................................................................................................................9

TSM-FB ................................................................................................................................... 9

Considerations for User-Supplied Mounting Platform for TSM-FB...................................... 10

TSM-FB Tripod Mounting Plate.......................................................................................... 10

TSM-PM................................................................................................................................ 10

TSM-PM Tripod Adapter.................................................................................................... 10

Connecting Up.......................................................................................................................... 11

TSM-FB ................................................................................................................................. 11

Connecting the TSM-FB to Other Anemoment Products .................................................... 11

TSM-PM................................................................................................................................ 12

Connecting the TSM-PM to Other Anemoment Products................................................... 14

Data Output ............................................................................................................................. 15

Viewing Serial Data Stream ................................................................................................... 15

Serial Data Format ................................................................................................................ 15

Custom Delimiters (New in 2.0)............................................................................................. 16

Error Codes ........................................................................................................................... 16

Customizing the TSM Sensor Configuration ............................................................................. 17

Serial Communication - Defaults ........................................................................................... 17

Serial Communication – Access Methods .............................................................................. 17

Serial Menu (New in 2.0) ................................................................................................... 17

Command Line Interface - Basic ........................................................................................ 18

4 Release Date 9 July 2021 Anemoment LLC

Command Line Interface - Expert Mode.............................................................................21

Application Programming Interface (New in 1.9)................................................................23

Triggering – TSM-PM Only .....................................................................................................23

Display Command..................................................................................................................24

Show, Hide, Tag, Untag, and Decimal Commands ..................................................................24

Tag and Parameter Delimiters (New in 2.0)............................................................................24

Calibration Procedures and System Memory............................................................................25

Anemometer Calibration .......................................................................................................25

Level Calibration....................................................................................................................25

Compass Calibration..............................................................................................................25

Wind Direction Scale Command (wd540)...............................................................................27

Non-Volatile Parameters .......................................................................................................27

TSM Sensor Meteorological Data Collection.............................................................................29

Humidity................................................................................................................................29

Absolute Pressure..................................................................................................................29

Tilt.........................................................................................................................................29

Compass................................................................................................................................29

TROUBLESHOOTING your TriSonica Mini Sensor ......................................................................31

Common Set-up Errors ..........................................................................................................31

Symptom: The TSM Sensor doesn’t seem to be doing anything. ........................................31

Symptom: There is no serial data coming from the TSM Sensor.........................................31

Symptom: The TSM Sensor sends garbled data..................................................................31

Updating TSM Sensor Firmware.............................................................................................32

Updating TSM Sensor Bootloader (New in 2.0) ......................................................................32

WARRANTY AND DISCLAIMER ..................................................................................................31

Limited Warranty...................................................................................................................31

Warranty Returns ..................................................................................................................31

Limitation of Liability .............................................................................................................31

LISTS OF FIGURES AND TABLES .................................................................................................32

5 Release Date 9 July 2021 Anemoment LLC

Hello World!

Welcome to the User Manual for the TriSonica Mini (TSM) family of

products from Anemoment.

We hope you find this information useful and wish you every success

in your research. We welcome comments and questions about this

manual by email at info@anemoment.com.

Guide to User Manual

This User Manual provides technical information to mount, connect, receive

data, and configure the TSM Sensors. For specific information on

FUNCTIONALITY, CONFIGURATIONS, plus TECHNICAL DATA and DRAWINGS,

use the Table of Contents in this User Manual to find information you seek.

The TriSonica Mini Family of Products

1. TSM-WS TriSonica Mini Wind Sensor (discontinued)

2. TSM-FB TriSonica Mini Wind and Weather Sensor – Flat Base

3. TSM-PM TriSonica Mini Wind and Weather Sensor – Pipe-Mount Base

4. USB-Interface TriSonica Mini USB Interface Module

5. TSM-FBSK TriSonica Mini Flat Base Starter Kit includes one each:TSM-FB,

USB-Adapter, and USB A-to-B cable.

6. TSM-PMSK TriSonica Mini Pipe Mount Starter Kit includes one each: TSM-PM,

USB-Adapter, USB A-to-B Cable, and 2-meter single terminated cable.

As used in this Manual, the term “TSM Sensor” means the information specified applies to both

the TSM-WS and the TSM-PM.

Chapter

6 Release Date 9 July 2021 Anemoment LLC

TRISONICA MINI SENSOR COMPARISON GUIDE

Table 1: TSM SENSOR COMPARISON GUIDE

MOUNT

STYLE

CONNECTION

TYPE

VAILABLE

COMMUNICATION

PROTOCOLS

DATA OUTPUT ON-BOARD SENSOR

TYPES

TSM-WS

(discontinued) Flat Base 4 Wires •EIA232 Configurable

ASCII String

•Wind Direction

& Velocity

•Air Temp.

TSM-FB Flat Base 4 Wires •EIA232 Configurable

ASCII String

•Wind Direction

& Velocity

•Air Temp.

•Air Pressure

•Humidity

•Tilt

•Compass

TSM-PM Pipe-Mount

with 3 Set

Screws

12-pin

Mating

Connector

•EIA232

•EIA422

•EIA485

•LVTTL-UART

•Modbus (future)

Configurable

ASCII String

•Wind Direction

& Velocity

•Air Temp.

•Air Pressure

•Humidity

•Tilt

•

Compass

Tell Us!

Did you spot a bug, a spelling error, or something that just didn’t make sense to you? We’d love

to hear about it. Please send feedback to info@anemoment.com, with a detailed explanation of

your concern. Screenshots and photos can be extremely helpful!

Limitation Alerts

Anemoment wants you to get the best possible use from your TSM Sensor investment, and we

understand that each User has a unique idea they want to create. You know best what you are

trying to accomplish. We know the TSM Sensors can help you access essential and actionable

wind and weather data in new places and new ways, but we cannot promise that they can do

everything or go everywhere the human mind can think up. We want to alert you to these

points up front, to empower your decisions as you plan your project.

Compact Fluorescent Lamps

Many compact florescent lamps operate at ultrasonic frequencies that interfere with

the operation of a TSM Sensor. If the TSM Sensor is operated near compact florescent

lamps, erroneous and erratic readings may result. Turning off the compact florescent

lamps or moving the TSM Sensor away from the CFL should result in proper instrument

operation.

Electro-Mechanical Motors and Magnetic Sensors

Electro-mechanical motors generate magnetic fields; the effect of the field on a

magnetic sensor varies by distance of the sensor to the motor, and by the speed (and

variations of speed) at which the motor is operated. The magnetic sensor aboard your

TSM Sensor will be affected by the field generated by motors nearby. We recommend

7 Release Date 9 July 2021 Anemoment LLC

that you consider the effects of magnetic fields arising from your unique use

configuration in both your hardware and software design.

Ice and Snow

The small size and light weight that are the hallmark of the TSM-FB and TSM-PM leave

no space for on-board heaters. These TSM Sensors are designed to function in outdoor

conditions; however, if ice or snow accumulate within the Sensor the acoustic pathways

between transducers can be blocked. While the dark coloring of the TSM-Sensors

facilitates natural solar removal of ice and snow, the TSM Sensors may not be the best

choice of sensor for sustained use in wintery weather.

Just the Facts, Ma’am

TSM Sensors combine powerful detection elements with a high-speed processor to

produce near-realtime data facts about atmospheric conditions at the site of the sensor.

The TSM Sensor transmits these collected data facts over wires in the form of a User-

configurable ASCII data stream. It is up to the User, however, to interpret this data in

the User’s unique situational context, which may require combination with additional

User-provided data or other post-processing. Anemoment is not responsible for such

additional data or processing.

Sorry, No Apples Today

The data stream from the TSM Sensor can be received, stored, and interpreted by the

User’s choice of device so long as it is connected to the Sensor by the proper

communications protocol. We recommend the use of a Terminal Emulator, such as Tera

Term, to review the data stream and to communicate with or configure the sensor.

Available for download at the Anemoment website is a rudimentary User interface app

for use on Windows™ operating systems; this app is not suitable for data logging

functions. The App’s OS choice is simply a result of skill-set limitations; we do not

presently have a timeline for developing an interface app for other operating systems.

Wind Tunnels & Ultrasonic Frequency

Ultrasonic anemometers operate by generating ultrasonic pulses and measuring the

time of flight of those sound pulses between transducers. The time-of-flight

measurements can be disturbed by external noise sources in or near the same

frequency band used by the ultrasonic anemometer’s transducers. (The TSM Sensors

operate in the 60KHz ultrasonic frequency range) We have found that some wind

tunnels generate ultrasonic noise that can cause erroneous readings from the

anemometer. This is not an indication of failure of the anemometer, but an artifact of

using the anemometer in what is to it an ultrasonically noisy environment.

8 Release Date 9 July 2021 Anemoment LLC

Andere Handbücher für TriSonica Mini

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Anemoment Zubehör Handbücher

Anemoment

Anemoment TriSonica Sphere Bedienungsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

Panasonic

Panasonic HG-T Series Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung
