ARCOL eMirror Bedienungsanleitung
User Manual
eMirror Camera Monitor System
English V 12/2022
Contents
Page
1.
System 3
1.1 System ON/OFF signal 3
1.2. Ambient light sensor 3
2.
System Failure 3
2.1. Visual Alert 3
2.2. Sound Alert 4
2.3 Possible Failure System 4
2 of 4
English V 12/2022
eMirror Camera Monitor System
1. System
1.2. Ambient light sensor
The system detects ambient light using light sensors in order to automatically adjust the backlighting of the
display, providing a comfortable view for the driver. Position of the sensors (see figure 1.1).
2.1. Visual Alert
In the event of a system malfunction, the LED at the bottom centre of the monitor will flash.
The warning light will be as shown in figures 2.1 below:
In the event that the cameras do not meet the regulation’s requirements due to a malfunction, a blue image
will be displayed in the corresponding category (see figure 2.2).
2. System Failure
1.1. System ON/OFF signal
The eMirror system will display the image in less than 7 seconds once the System ON/OFF signal goes from
0V to 12V/24V.
The eMirror system will stop displaying the image after a few minutes depending on the vehicle configuration.
3 of 4
English V 12/2022
eMirror Camera Monitor System
Error
Figure 2.2
Do not obstruct the light sensors
Figure 1.1
Light sensors
If a minor error occurs, the driver should stop the
vehicle, reset the system and if the error does not
disappear, contact the technical support service.
Error
(Orange light)
Figure 2.1
2.2. Sound Alert
At the same time that a light signal appears, the system will audibly indicate the existence of an anomaly in the
system that must be attended to by the driver and corrected by the technical support service (see figure 2.3).
4 of 4
English V 12/2022
eMirror Camera Monitor System
2.3. Possible Failure System
Rear side
Figure 2.3
Failure Error Indication Action
PowerLoss
Black screen
Driver should stop the vehicle in a safe manner,
check connection and restart the system. If the
problem persists, get in touch with technical service
immediately.
No power
Temporary error
Driver should stop the vehicle in a safe manner,
check connection and restart the system. If the
problem persists, get in touch with technical service
as son as possible.
Internal error LED visual alert
Display error
(for example: enlarged in image formation
time) Black screen
LED visual alert
Sound alert
Display backLight error
BackLight sensor error LED visual alert
No camera connection at monitor
Blue screen at class II
LED visual alert
Sound alert
Camera power failure
Camera communication link failure
(for example: electronic noise or resolution
reduction)
No camera connection at monitor
Blue screen at class IV
LED visual alert
Sound alert
Camera power failure
Camera communication link failure
(for example: electronic noise or resolution
reduction)
No camera connection at monitor
Blue screen at class V
LED visual alert
Sound alert
Camera power failure
Camera communication link failure
(for example: electronic noise or resolution
reduction)
