Assemble seat cushion and pump

Assemble mattress overlay or mattress replacement and pump

CPR unit is clicked into

closed position.

Connect the tubeset.

Seat cushion:

Place on chair surface.

Use the xing straps to attach.

Place pump on oor, cable under chair,

tubeset placed alongside chair.

Connect the tubeset.

Connect power cable to power source.

• cells facing up

• tubeset at front right corner

• cells horizontal across chair,

V-shape towards front

Front of chair

Back of chair

Zip the protective cover

over the mattress. Arjo

logo visible at the foot

end.

Auralis

Mattress overlay:

Place on top of base mattress.

Secure with 4 xing straps.

Mattress replacement:

Place on bed base. Attach the 8

securing straps to moving parts of

bed frame (+ 3 at head end for Auralis

Plus only)

• tubeset at foot end

• CPR at head end

• cells facing up

Hang the pump at the

foot end of the bed.

Place cable in the cable

management. Close the

ap around the cable with

the press studs.

Connect power cable to

power source.

1 2

08.AI.02EN_04 • 09/2022 • Page 1/4

QUICK REFERENCE GUIDE - USE

Auralis

10s

Autorm mode

Activate: Press and

hold the button.

Comfort indicators ash

and mattress inates to

Autorm.

Extend: Press button to

extend 5 minutes. Max.

30 minutes.

If not extended, pump

goes back to previous

mode.

Deactivate: Press and

hold the button or select

another mode.

Pressure reached –

Autorm and Control

comfort indicators turn to

constant.

CPR rapid deation unit

Activate: Press both CPR release

buttons simultaneously.

Reset: Press down the open part

until it clicks into closed position.

Make sure the front part is open.

The air evacuates rapidly.

Alternating mode, default setting

Activate:

Press button, the Alternating mode indicator is shown.

Adjacent cells inate and deate on a 10 minute cycle.

15 min

Start the Auralis system

When the pump is connected to a power

source it runs a self check:

Beep – 10 seconds – 2 beeps – ready to use.

Press and hold Run/Standby button.

The following indicators are shown:

• Run/Standby

• Wait indicator

• Alternating mode button

• Comfort control indicator

• Battery charge indicator

• Green indicators on the front of the pump

Once the Wait indicator turns

o󰀨, place bed sheet on mattress.

Make sure that the CPR rapid

deation unit is clearly visible.

Place patient on the mattress or

seat cushion.

Alternating mode is set by default.

Auralis

Deactivate:

Select Reactive CLP or Autorm mode.

If no further therapy is required, remove patient from

the surface and turn o󰀨 the pump.

08.AI.02EN_04 • 09/2022 • Page 2/4

Deactivate:

Reconnect the tubeset.

The pump goes back to the previous mode.

Transport mode (mattresses only)

Reactive CLP mode

Activate:

Press and hold the button.

Reactive CLP mode indicator is shown.

Deactivate:

Select Alternating mode or Autorm mode.

If no further therapy is required, remove patient from

the surface and turn o󰀨 the pump.

Activate:

Press side buttons simultaneously and remove tubeset.

The mattress supports the patient for up to 12 hours.

Lock out mode

Locking:

Push and hold the comfort control buttons

simultaneously.

Comfort control indicators ashes.

Pump is now locked.

Unlocking:

Push and hold the comfort control buttons

simultaneously.

Comfort control indicators ashes.

Pump is now unlocked.

2s 2s

08.AI.02EN_04 • 09/2022 • Page 3/4

Bolster ination and deation (Auralis Plus only)

Bolster deation:

Locate the valve symbol (A).

Turn the valve (B) on the bolster fully clockwise

Repeat on the other bolster, if required.

Leave to deate for 5 minutes.

Note: Deate bolsters before reducing the bed frame

width.

Bolster ination:

Locate the valve symbol (A).

Turn the valve (B) on the bolster fully anticlockwise

Repeat on the other bolster, if required.

Leave to inate for 8 minutes.

Note: Extended bed frame width before inating the

bolsters.

Risk of injury or discomfort

Deactivate transport mode

Bolster congurations:

• One bolster inated (left or right)

• Both bolsters inated (left and right)

• Both bolsters deated (left and right)

ArjoHuntleigh AB

Hans Michelsensgatan 10

211 20 Malmö, Sweden

www.arjo.com 08.AI.02EN_04 • 09/2022 • Page 4/4
