Artic FUSION SPLICER 5.7 Bedienungsanleitung

OUTDOOR MULTIFUNCTION FUSION

SPLICER

FUSION SPLICER 5.7

AR-FUSPLICE-5.7

OPERATION

MANUAL

1. Noticebeforeusing...............................................................................................3

1.1. Safetyinstruction.................................................................................................................................3

1.2. Note...............................................................................................................................................................3

1.3. Legalstatement....................................................................................................................................3



2. Starttocomprehendsplicer...............................................................................4

2.1. Overviewofsplicer............................................................................................................................4

2.2. Key..................................................................................................................................................................4

2.3. Technicalparameters......................................................................................................................8

2.4. Toolsconﬁguration...........................................................................................................................9



3. Acompletesplice................................................................................................10

3.1. Poweron..................................................................................................................................................10

3.2. Preparationofﬁberendface...................................................................................................10

3.3. Fiberclamping...................................................................................................................................12

3.4. Opticalﬁberfusion..........................................................................................................................13

3.5. Heat-shrinkable..................................................................................................................................13

3.6. Cooling.....................................................................................................................................................14



4. Menuinstruction.................................................................................................14

4.1. Parametersettingmenu.............................................................................................................15

4.2. Setup.........................................................................................................................................................17

4.3. Function..................................................................................................................................................19

4.4. Maintenance........................................................................................................................................22

4.5. Heater........................................................................................................................................................25

4.6. Electrodes...............................................................................................................................................25

4.7. Status.........................................................................................................................................................27

4.8. Information...........................................................................................................................................27

5. Routinemaintenance.........................................................................................28

5.1. Cleaning..................................................................................................................................................29

5.2. Replacingelectrode.......................................................................................................................30

5.3. Electrodeaging..................................................................................................................................31

5.4. Softwareupgrade............................................................................................................................32

6. Commonfaultandsolution..............................................................................31



7. AppendixA...........................................................................................................32

CONTENTS

Notice before using

Safetyinstruction

Pleasereadthefollowinginformationbeforeﬁrstusing.

1.Usingthespeciﬁedbatteryandadaptor,otherwiseitmaycauseanexplosionorpermanent

damagetothemachine.

2.Don'tusethemachineinahightemperature,ﬂammableorexplosiveenvironment(such

asagasstationnearby).

3.Don'tattempttodisassemblethemachineoritsaccessories,onlyauthorizedagenciescan

repairit.

4.Pleasedon'ttouchelectrodesduringworkingtime,oritmaycausepersonalinjury.

5.Whenliquidorforeignbodyintothemachine,orsmoke,odor,noise,etc.,orastrong

impact,pleaseimmediatelyshutdownthemachine,andpullouttheACpower.

Note

Whenusingthemachine,improperoperationmaycausedamagetothemachineoreven

dangerforhumanhealth.Itissuggestedtooperateinthefollowingway.

1.Thistypeofthemachineisonlyusedforsplicingquartzglassﬁber,notinplaceofanyother

matter.

2.Don'tuseorstorethemachineinahightemperatureorhumidityenvironment(otherwise

itmaydamagetheequipmentorcausethemachineperformancedegradation).

3.Whileusingthemachineinadustenvironment,trytoavoiddustasfaraspossible.

4.Whenmovingthemachinefromlowtemperaturetoahightemperature,thereshouldbe

anyheatingprocesstoeliminatecondensation.

5.Pleaseuseahigh-purityanhydrousalcohol(purity>99%)tocleanmagnifyinglens,reﬂector

andﬁberv-groovesurface.

6.Thesplicingthemachinemustbehandledgentlytoavoidstrongvibrationorimpact,and

withcarryingcasefortransportationorstorage.

7.Maintainthewholethemachineonceayear.

Legalstatement

Withoutthewrittenconsentofourcompany,anyunitorindividualwillnotbeallowedto

extractorcopypartofthecontentsofthismanual,ortransmittedinanyform.

Productsdescribedinthismanual,includingourcompanysoftware,unlessapprovedbythe

relatedoblige,otherwisenoonecanbeinanyformforthesoftwaretocopy,distribute,

modify,excerpts,decompiling,disassembling,decryption,reverseengineering,lease,transfer,

sublicenseandotherACTSofinfringingthesoftwarecopyright.

Attention:Themanualdescribessomefeaturesandfunctionsoftheproductanditsacces-

sories,relatedtotheproductionbatch,therefore,thedescriptioninthismanualmaynot

exactlymatchtheproductyoupurchased,aswellasitsaccessories.

OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7

Start to comprehend splicer

Overviewofsplice

Key

Keyappearance

OurCompanyreservestherighttomodifyanyinformationinthismanualatanytime,without

anypriornoticeanddoesnotundertakeanyresponsibility.

Limitationofliability:Withinthescopeofapplicablelaw,ourcompany,inanycase,donʼt

compensateforanyspecial,incidental,indirect,secondarydamageduetousingthismanual

ortheproduct,andalsodonʼtcompensateforanylossofproﬁts,data,goodwilloranticipated

savings.Withinthescopeofapplicablelaw,inanycase,ourcompanywillundertakethe

greatestresponsibilityforthelossessuﬀeredintheuseoftheproductdescribedinthis

manualinthelimitofthepriceyoupaidfortheproduct.(Exceptincasesinvolvingpersonal

injuryaccordingtoapplicablelawfordamages).

FIGURE 2.1

FIGURE 2.2

OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7

Keyfunctions

Table

Table

1Power

4Up

7Right

10Reset

2Enter

5Left

8Heat

11SwitchVideo

3Menu/Exit

6Down

9Arc

12AutoSplice

WhilePowerOn,pressthiskeytoshutdown.

WhilePowerOFF,pressthiskeytoPowerOn.

Underthestandbyinterface,pressthiskeytodischargeaweakarc.

Inmenu,pressthiskeytoenterthenextsubmenu.

Ifpermitted,pressthiskeytorun.

Ifpermitted,pressthiskeytoswitchbetweentheleftandrightsidesofCMOS

Sensor,Motorsandsoon.

Underthestandbyinterface,pressthiskeytoenterthemainmenu.

Underthemainmenuinterface,pressthiskeytoreturntheuppermenu.

Underthestandbyinterface,pressthiskeytoincreasetheLCDbacklight.

IntheCMOSsensorstep,pressthiskeytoincreasetheCMOSsensorbacklight.

Inmotoradjustment,pressthiskeytodriveupthefiber.

Ifpermitted,pressthiskeytomoveupthecursor.

OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7

Underthestandbyinterface,pressthiskeytogapthefiber.

Underthemainmenu,pressthiskeytoselectthelefticon.

Inmotoradjustment,pressthiskeytodrivethecorrespondingmotortomoveto

theleft.

Underthestandbyinterface,pressthiskeytodecreasetheLCDbacklight.

InthesetupoftheCMOSsensor,pressthiskeytodecreasetheCMOSsensor

backlight.

Infunctionofamotortest,pressthiskeytomovedownthecorrespondingmotor.

Ifpermitted,pressthiskeytomovedownthecursor.

Underthestandbyinterface,pressthiskeytoalignthefiber.

Underthemainmenu,pressthiskeytoselecttherighticon.

Inmotoradjustment,pressthiskeytodrivethecorrespondingmotortomoveto

theright.

Underthestandbyinterface,pressthiskeytofuse.

OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7

InthePowerOnstate,pressthiskeytoresetthemotorposition.

Underthestandbyinterface,pressthiskeytoswitchvideomode.

Underthestandbyinterface,pressthiskeytorunautosplice.

OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7

Fittedfiber

Claddingdiameter

Coatingdiameter

Typicalloss

Echoloss

Cuttinglength

Program

Operationmode

Autotoheat

Splicetime

Heatingtime

Magnification

Observationmode

FusionRecords

Estimateloss

Tension

OperationInterface

Batterycapacity

Powersupply

Electrodestimes

Interface

OperationEnvironment

Volume/weight

SM，MM，DS，NZDS

80-150um

100-1000um

SM:<=0.02dB;MM:<=0.01dB;

DS:<=0.04dB;NZDS:<=0.04dB

>60dB

10-16mm(CoatinglayerDiameter:<250µm)

16mm(CoatinglayerDiameter:250~1000µm)

40groups

AutomodeandManualmode

Supported

7seconds

30seconds(heat-shrinkingtubewidthis40mmor60mm)

150times/doubleshow,300times/singleshow

AhighsensitivityCMOSsensor,ColorLCDof5.6inchwithpixels640x480

Supporttostore4000groupsofFusionRecords

Supported

Supported,2N

GUI

10.8Ah;Typical220timesfusion;Showremainingreal-time

Adapter:AC100-240V(50/60HZ);Output:DC11~13.5V

4000timesInterface

12VDCpowerinput,USB2.0

Altitude:0-5000m;Humidity:0-95%;Temp:-10℃-+50℃;Airspeed:<=15m/s

160mm（L）×150mm（W）×145mm（H）/2.8kg(BatteryIncluded)

Technicalparameters

OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7

INSTALLATION MANUAL FIBER ACCESS TERMINAL CLOSURE AR-DB16F

CarryingCase:

KeepthesplicerawayfromthebumpingandcompactWorkingplatform.

FiberCleaver:

Cuttingfiber

Preparationofthefiberendface.

Spareelectrodes:

Replacetheagingelectrodes.

Stripclamp:

Strippingthefibercoating.

Alcoholpumpbottle:

Usedtoholdalcohol.

Coolingtray:

holdheatshrinktubetocool.

AC-DCAdapterforsplicer.

ToolsConﬁguration

A complete splice

Afullﬁberspliceprocedureincluding:theﬁberendfacepreparation,ﬁbersplicing,tension

test,heatingandcoolingofshrinktube.Thischapterwillintroducedetailsofthespeciﬁc

processoftheﬁbersplice.

Pressandholdthepowerbuttonuntilthepowerindicatorlight,then,LCDalsoenterthe

self-testscreen.

Preparetwoopticalﬁbers,asshowninFigure3.2,inwhichanopticalﬁberissetintotheheat

shrinktube.

Poweron

Preparationofﬁberendface

FIGURE 3.1

FIGURE 3.2

OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7
