HOB H6

HOB H6A

ENGLISH • NORSK • SVENSKA

art. nr. 72369920/T92059

GB IE

english page 1 - 23

norsk side 24 - 47

svenska sida 48 - 71

appliance description H6 description of the control panel

twin area zone

2000/1000 W

left rear zone

1200 W

rear right zone

1800 W

front right zone

1200 W

child safety lock

timer

zone operating buttons

rear left and rear right and

timer for each zone

zone operating touch controls

front left and front right

control for twin-area zone

selection

where to find ASKO/ONE

introduction

general information about your hob

for your safety

tips for use

selecting a setting

timer

connecting the timer to a zone

twin area zone switching

child safety lock

automatic boiling / automatic frying

cooking comfortably

limiting cooking time automatically

caring for the appearance of the appliance

dealing with faults yourself

building-in – preliminary notes

electrical connection

building-in

technical details

disposal of packaging and appliance

ASKO/ONE’s guarantee

18 |

|19

20 |

|21

22 |23

24 |25

contents

indications in the display

still hot

standby

fault codes

appliance overheating

settings

automatic boiling

automatic frying

{

F00 - F18

1 - 12

A1 - A7

A8 - A9

GB IE

english

}

appliance description H6A

for Australia

twin area zone

1900/950 W

left rear zone

1200 W

rear right zone

1800 W

front right zone

1200 W

introduction

general information

about your hob

Reading these instructions will tell you

quickly what the appliance can do. You

can read about safety and how you

should maintain the appliance.

There are also tips about the

environment and information that can

help to save energy.

Keep the instructions for use and the

installation instructions. Any later user

of this appliance could benefit from

them.

Enjoy your cooking!

When you first connect the appliance to

the mains it will test itself automatically

and the displays will light briefly.

The appliance adjusts itself. At first the

controls can react very quickly. After a

few days of use this will have adjusted

to the surroundings.

If you do not select a setting within 5

seconds the zone will switch itself off

automatically.

The control panel uses touch controls.

The appliance bleeps when you touch a

control. If you touch a control for

longer than 2 seconds the function will

be repeated but there will be no bleep.

This repeat function does not apply to

switching zones on and off.

You can switch in the timer for the two

rear zones so that at the end of the

cooking time the zone will be switched

off automatically.

}

where you can find

ASKO/ONE

Australia

Adress:

Phone:

Fax:

New Zealand

Adress:

Phone:

Fax:

Norway

Adress:

Phone:

Fax:

Sweden

Adress:

Phone:

Fax:

ASKO Appliances

19, Trent Street

3125 Burwood

Victoria, Australia

03 - 9809 2599

03 - 9809 1358

Award Appl Ltd.

388/390 Blenheim Road

PO Box 4007 Christchurch

New Zealand

03 - 348 0556

03 - 348 0687

ASKO Elto AS

Vevelstadveien 113

1404 Siggerud

Norge

6486 8860

6486 7625

ASKO Cylinda AB

S-534 82 Vara

Sverige

0512 320 00

0512 320 10

Keep the control panel clean.

This cooking appliance is designed for

domestic use. Use it for the preparation

of dishes.

Use the hob for cooking only. Be careful

with aluminium foil, plastic (shrink film)

and sugar. Once melted they are difficult

to remove from the hob surface.

Use pans that are suitable for cooking by

electricity. Place only pans with a clean

dry base on the hob zones. This will

prevent marking by lime-scale or other

stains that are difficult to remove.

Do not place objects on the touch

controls. This will switch off the hob

and a fault code will appear. See

page 14, "Dealing with faults yourself".

Do not use the appliance as a working

surface.

A grain of sand can cause a scratch that

cannot be removed. Do not slide pans

across the hob surface and do not clean

vegetables on it.

Do not use pans that are smaller than

the cooking zone. This will prevent food

spills on the very hot cooking zone.

Burnt-on food spills are difficult to

remove.

tips for use

operating panel

for cooking only

pans

}

]

what you should do

If a crack appears in the hob surface you

must switch off or disconnect the

appliance from the mains by taking out

the plug. Do not use the appliance

anymore and get in touch with the

Service department (see page 20).

The appliance is hot during and after

use. Remember this if there are young

children near the appliance.

what you should not do

Be careful when you are using

earthenware, glass or metal objects

above the cooking surface. A dropped

herb jar, for example, can cause a

crack.

Do not leave young children alone near

an appliance that is hot.

}

]

for your safety

crack in the hob surface

young children

wrong

right

connecting the timer to a zone

You can connect the timer to one of the

rear zones. The zone will switch off

automatically when the time set has been

reached.

Press

and set the required

power with

Press

and set a time with

Press the timer control required (

The power set will appear in the

display.

The timer will start to count back five

seconds after setting the time required.

At the end of the time set the timer will

ring and the zone will be switched off.

1 setting the zone

2 set the timer

3 connect the timer to the zone

}

]

}

Press

A zero will appear in the display.

The timer will start to count back five

seconds after setting the time required.

At the end of the time set the timer will

ring.

When no control is touched the signal

will stop itself after 30 minutes.

timer

The timer only gives a signal at the end of

the time set. 1 switch the timer on

2 set the time required

3 switch the timer off

}

]

}

Press

. You can also adjust

the power with these controls.

Press

A horizontal bar lights up to show that

the hob is on standby.

If you press

you will start from

setting 12.

If you press

you will start from

setting 1.

An H will appear in the display to show

that the hob is still hot.

selecting a setting

You can select settings between 1 and 12.

You can also select the automatic boiling

settings A1 to A7 or the automatic frying

settings A8 and A9 (see also pages 10 and

11).

If the zone is cold it will be brought up to

temperature quickly at high power.

1 switch a zone on

2 select a setting

3 switch the zone off

You can use the remaining heat to

continue heating a dish for the last few

minutes.

}

]

}

higher/lower

on/off

timer

6/7*

* The numbers below the illustrations refer to the corresponding numbers on the fold out page

()

Press

in the lower part of the control

panel. The light above the control will come

on.

twin area zone switching

You cannot use the outer ring on its own. switch on the twin area zone

}]}

Press

in the upper part of the control

panel.

Keep pressing the control for 3 to 4

seconds.

The light above the key will come on.

The selected settings are locked. You

can still switch off the zones and the

timer.

As soon as you press the control you

will hear a signal. When the lock is

switched off the signal sounds again

and the light will go out.

child safety lock

When the lock is switched on the settings

selected cannot be changed.

You can also use the child safety lock as a

cleaning setting.

1 switch on the child safety lock

2 switch off the child safety lock

}

]

}

* The numbers below the illustrations refer to the corresponding numbers on the fold out page

Press

A horizontal bar shows that the hob is

on standby.

Setting 12 will appear in the display.

A1 to A7 will appear after each other in

the display.

automatic boiling/

automatic frying

Automatic boiling is particularly useful if

you regularly cook the same quantities.

setting rapid heating time

A1 1,5 minutes

A2 2 minutes

A3 3 minutes

A4 4 minutes

A5 6 minutes

A6 10 minutes

A7 13 minutes

setting frying heating time

A8 2 minutes

A9 2,5 minutes

1 switching a zone on

2 select setting 12

3 select the automatic boiling setting

required

}

]

}

You do not need first to select a high

setting and then to turn it down.

A prerequisite is a good quality pan,

with a heavy base.

With a small quantity on a large zone

automatic boiling can be too fierce.

Select a smaller zone with a lower

power.

Usually you bring the dish to the boil

at a high setting, you then switch to a

lower setting to finish cooking the

dish.

Automatic boiling does this for you. It

works automatically. First bring to the

boil at full power and then switch

automatically to the lower cooking

setting.

Cooking using automatic boiling

requires some experience.

You will notice after some time that

you always use the same setting to

complete the cooking of certain

dishes. For example, you always finish

cooking potatoes at setting 5.

Using automatic boiling you can select

the A5 setting.

1110

1312

Press

The hob will be heated and will switch

off automatically after a certain time.

This time will differ according to the

setting selected. See the table.

limiting cooking time

automatically

setting duration

1 10 hours

2 10 hours

3 5 hours

4 5 hours

5 5 hours

6 4 hours

7 4 hours

8 4 hours

9 3 hours

10 2 hours

11 1 hour

12 1 hour

1 switch a zone on

2 select a setting

}

]

setting 1 _4

_simmering bouillon

_lightly stewing pears

_preparing stewed meats

_completing the cooking of dishes

_braising vegetables

setting 4 _7

_ completing the cooking of large

quantities

_ thawing hard vegetables, for example

green beans

setting 8

_ cooking thick pancakes

_ frying thick pieces of meat in

breadcrumbs

_ cooking through thin pieces of meat

_ broiling large pieces of meat

_ frying blocks of ham or bacon

_ frying raw potatoes

_ frying beef olives

_ frying fish in breadcrumbs

_ frying thin pieces of meat in

breadcrumbs

_ cooking omelettes

setting 9 _12

_sealing meat

_frying flat fish, thin slices or fillets

_frying cooked potatoes

_preparing smooth thickened soups

and sauces

_cooking omelettes

_frying beefsteaks (medium,

medium-rare)

_deep fat frying (depending on

temperature and quantity)

setting 12

_bringing quickly to the boil

_shrinking leaf vegetables

_blanching vegetables

_heating oil, fat and butter

_frying beefsteak (very rare, rare)

_bringing a pressure cooker up to

pressure

_cooking smooth thickened desserts

cooking comfortably

select a setting using this table

}

]}

}

1514

what you should do

Clean the ceramic hob after use. You can

use, for example, a little washing-up

liquid in water. Switch on the child

safety lock before cleaning the control

panel.

Special maintenance products for

ceramic hobs, such as Collo Profi or

Cerafix give the ceramic hob a protective

layer. Treat the hob with these products

also when obstinate stains have been

removed.

You can remove burnt-on stains, metal

and lime scale stains from the ceramic

hob with such special cleaning materials

as Jif, Collo Luneta or Stahlfix.

Remove boiled-over food residues with a

glass scraper. Molten plastic and sugar

can also be removed with a glass

scraper.

what you should not do

Never clean the ceramic hob with an

abrasive cleaning material!

Do not first allow the hob to cool

completely.

caring for the appearance

of the appliance

Special maintenance products for ceramic

hobs (e.g. Collo Luneta) form an antistatic

layer on the hob so that it attracts dust less

readily.

daily

weekly

obstinate stains

boiled-over food residues

}

]

}

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Asko Kochfeld Handbücher

Asko

Asko HG11 series Bedienungsanleitung

Asko

Asko HG8953BGBx Bedienungsanleitung

Asko

Asko HIHM934M Stücklistenhandbuch

Asko

Asko HIG1995AD Bedienungsanleitung

Asko

Asko HI6471E Bedienungsanleitung

Asko

Asko HG8320BGBx Bedienungsanleitung

Asko

Asko IG9571MB Bedienungsanleitung

Asko

Asko HG1666AD Bedienungsanleitung

Asko

Asko HI1995G Bedienungsanleitung

Asko

Asko HG1935AB Bedienungsanleitung

Asko

Asko HG9ADE1A Bedienungsanleitung

Asko

Asko HG8144BGB Series Bedienungsanleitung

Asko

Asko HG8BDE1A Bedienungsanleitung

Asko

Asko SIVK7QATX HI1774IQ Bedienungsanleitung

Asko

Asko H4 Bedienungsanleitung

Asko

Asko HG1825AB Bedienungsanleitung

Asko

Asko SIVK9DTA Bedienungsanleitung

Asko

Asko HG1615ab Bedienungsanleitung

Asko

Asko HT1334S Bedienungsanleitung

Asko

Asko HG1986SB Bedienungsanleitung

Asko

Asko HG1145AB Bedienungsanleitung

Asko

Asko HIG1995AD Bedienungsanleitung

Asko

Asko HG1935ad Bedienungsanleitung

Asko

Asko HG1825AD Bedienungsanleitung

Beliebte Kochfeld Handbücher anderer Marken

Siemens

Siemens EX875KYV1E Technisches Datenblatt

AEG

AEG CERAMIC HOB 6010 K Bedienungsanleitung

VALERA

VALERA CT 70A Bedienungsanleitung

Zanussi

Zanussi ZGF 6420 Bedienungsanleitung

Gaggenau

Gaggenau CI 273 Bedienungsanleitung

G3 Ferrari

G3 Ferrari Energy Bedienungsanleitung

Pkm

Pkm IN4B Bedienungsanleitung

Award

Award H903BG Bedienungsanleitung

Zanussi

Zanussi VCH 5005 RZ Bedienungsanleitung

Miele

Miele KM 523 Bedienungsanleitung

Hotpoint

Hotpoint IS67V8CCXT/E Bedienungsanleitung

AEG

AEG HK854870XB Bedienungsanleitung

Cookology

Cookology SEP600BK Bedienungsanleitung

Bauknecht

Bauknecht Hob Bedienungsanleitung

Zanussi

Zanussi ZGM 782 Bedienungsanleitung

dipo INDUCTION

dipo INDUCTION DIBK218S Bedienungsanleitung

Miele

Miele KM 5987 Bedienungsanleitung

Miele

Miele KM 360 G Bedienungsanleitung
