Atmel AT43DK355 Bedienungsanleitung

AT43DK355 USB Controller Development

Kit for the AT43USB35X Family

...........................................................................................................................

User Guide Version 1.0

AT43DK355 USB Controller Dev. Kit User Guide i

3429C–USB–7/04

Table of Contents

Section 1

Introduction ...........................................................................................1-1

1.1 Features....................................................................................................1-1

1.2 Device Support .........................................................................................1-1

1.3 Documentation..........................................................................................1-2

1.4 Free Downloads........................................................................................1-2

Section 2

Getting Started......................................................................................2-1

2.1 Electrostatic Warning ................................................................................2-1

2.2 Unpacking the System ..............................................................................2-1

2.3 System Requirements...............................................................................2-1

2.4 Software Requirements.............................................................................2-1

2.5 Connecting the Hardware .........................................................................2-2

2.6 CD-ROM Contents....................................................................................2-2

2.6.1 USB Wizard Utility ..............................................................................2-2

2.6.2 Code Base Directory ..........................................................................2-3

2.6.3 Application Example ...........................................................................2-4

2.6.4 In-System Programming Tool.............................................................2-4

2.6.5 Atmel USB HID Demo Utility ..............................................................2-4

2.6.6 Binary Files for Uploading ..................................................................2-5

2.7 Checking the Hardware.............................................................................2-5

Section 3

Hardware Description ...........................................................................3-1

3.1 LEDs (LD0 to LD7)....................................................................................3-1

3.2 5x2 Header JP14 ......................................................................................3-1

3.3 8 DIP Switch SW1.....................................................................................3-1

3.4 5x2 Header JP16 ......................................................................................3-2

3.5 DB 25 Female Parallel Port Connector J4 ................................................3-2

3.6 8-pin IC Socket U4....................................................................................3-2

3.7 Variable Resistor R15 ...............................................................................3-2

3.8 2x2 Header JP9 ........................................................................................3-2

3.9 Programmable Logic Device U2 ...............................................................3-2

3.10 5x2 Header JP5 and 2x2 Header JP6.......................................................3-2

3.11 4x2 Header General Purpose I/O PORT A/JP1........................................3-2

3.12 4x2 Header General Purpose I/O PORT B/JP2........................................3-2

3.13 4x2 Header General Purpose I/O PORT D/JP4........................................3-3

3.14 2x2 Header General Purpose I/O JP3 ......................................................3-3

3.15 2x2 Header JP8. .......................................................................................3-3

3.16 2x2 Header JP13 ......................................................................................3-3

Table of Contents

ii AT43DK355 USB Controller Dev. Kit User Guide

3429C–USB–7/04

3.17 2x2 Header JP11 ......................................................................................3-3

3.18 Solid State Power Switch U3 ....................................................................3-3

3.19 2x2 Header JP12 ......................................................................................3-3

3.20 Header GND TP1 and TP2 .......................................................................3-4

3.21 Header JH1...............................................................................................3-4

3.22 USB External Downstream Port J2 and J3 Connectors............................3-4

3.23 USB Upstream Port J1 Connector ............................................................3-4

3.24 Programmable Microcontroller U1 ............................................................3-4

Section 4

SEEPROM Loader................................................................................ 4-1

4.1 Setting Up the Board.................................................................................4-1

4.2 Loading Code............................................................................................4-1

Section 5

Technical Support................................................................................. 5-1

Section 6

Appendix............................................................................................... 6-1

6.1 AT43USB355 Bill of Materials (BOM) .......................................................6-1

6.2 AT43DK355 Schematics...........................................................................6-3

Section 7

Change Log .......................................................................................... 7-1

AT43DK355 USB Controller Dev. Kit User Guide 1-1

3429C–USB–7/04

Section 1

Introduction

Congratulations on your purchase of the AT43DK355 USB Development Kit. The

AT43DK355 is a complete starter kit and development system for Atmel's AT43USB35x

family of AVR®based USB microcontrollers (MCUs). It provides all of the necessary

hardware and firmware components to facilitate rapid prototyping and firmware develop-

ment of the AT43USB35x applications.

1.1 Features The AT43DK355 Development Kit consists of the following:

Development Board for the AT43USB35x USB MCUs featuring

– An AT43USB355 full-speed USB controller programmable as a compound

device, a hub only device or a function only device

– One internal and two external downstream HUB ports

– 1 Kbytes on-chip program SRAM

– 24 Kbytes of program memory

– Parallel interface to PC for In-System firmware programming

– 8 push buttons and 8 LEDs for general use

– Pin header connectors for access to all available GPIO pins

Hardware design files (schematics and PCB layout)

USB 2.0 compliant USB firmware library

USB Wizard firmware source code generation utility

In-System Programming tool

Complete User Guide

1.2 Device Support The AT43DK355 Development Kit and the accompanying software tools are intended to

support firmware development and prototyping for the AT43USB35x family of USB func-

tion controllers, including the

– AT43USB355

– AT43USB353M

– AT43USB351M

Introduction

1-2 AT43DK355 USB Controller Dev. Kit User Guide

3429C–USB–7/04

Binary compatibility across the AT43USB3xx family ensures that only one set of devel-

opment tools (development kit, compilers, etc.) is needed for all of the AT43USB3xx

based applications. Firmware written for one member of the family can be re-used for

another member without modification as long as only features available on both parts

are used.

1.3 Documentation The AT43DK355 Development Kit is accompanied by the following two documents:

– AT43DK355 User Guide

– USB Wizard User Guide

Atmel recommends its customers read the AT43DK355 User's Guide prior to reading

the USB Wizard User Guide.

1.4 Free Downloads The latest version of the USB Wizard can be found in the USB section of the Atmel web

site at http://www.atmel.com. Please refer to the same section for up-to-date informa-

tion on new USB product announcements, software releases and tool upgrades.

AT43DK355 USB Controller Dev. Kit User Guide 2-1

3429C–USB–7/04

Section 2

Getting Started

2.1 Electrostatic

Warning

The AT43DK355 Development Board is shipped in protective anti-static packaging. The

board must not be subjected to high electrostatic potentials. A grounding strap or similar

protective device should be worn when handling the board. Avoid touching the compo-

nent pins or any other metallic elements.

2.2 Unpacking the

System

The AT43DK355 Development Kit is supplied with the following:

– AT43DK355 Development Board

– 2-meter Fully Rated USB Cable

– Male-male DB25 Parallel Cable

– Atmel USB CD-ROM with Software and Documentation

Please contact your local Atmel distribution or e-mail [email protected] if any of the

aforementioned items is missing from the package.

2.3 System

Requirements

The minimum hardware and software requirements are:

– 486 processor (Pentium®is recommended)

–128MBRAM

– 10 MB free hard disk space

– Windows®98/2000/ME/XP

– Parallel printer port

2.4 Software

Requirements

The following third party software are needed to access and modify the documents and

source code in the CD-ROM:

–OrCAD Capture®from www.orcad.com for the .dsn file

–IAR or GNU C Compiler for the sample C source code

–Microsoft®Word from www.microsoft.com for the .doc files

–Acrobat®Reader®from www.adobe.com for the .pdf files

–Winzip®from www.winzip.com to open the .zip files

Getting Started

2-2 AT43DK355 USB Controller Dev. Kit User Guide

3429C–USB–7/04

2.5 Connecting the

Hardware

Atmel has taken great care in creating a reliable demonstration kit for its customers. The

AT43DK355 Development Board is USB bus powered and requires no external power

supplier. In order to ensure proper operation, the supplied components in the kit must be

used in the setup shown in Figure 2-1. Atmel does NOT recommend substitution of

these components.

Connect the AT43DK355 Development Board as follows:

1. Verify that Jumper JP8 and Jumper JP11 are closed.

2. Connect the USB cable from J1 Series B USB receptacle on the Development

Board to the USB Series A receptacle on the PC.

3. Connect the DB25 parallel cable from J4 on the Development Board to the paral-

lel port on the PC.

Figure 2-1. Connection to the AT43DK355

2.6 CD-ROM

Contents

The CD-ROM has a top directory \355_evx\ where xindicates the version of the firm-

ware. All the directory paths used in this User Guide fall under this top directory. There

are three major subdirectories:

–BOARD: hardware design documentation

–Docs: datasheets, tutorial, and user guide

–USBWizard: USB Wizard software tool and examples

2.6.1 USB Wizard Utility USB Wizard utility is a GUI based development tool that facilitates rapid USB application

development for the AT43USBxxx family of AVR USB controllers. It allows the user to

generate firmware templates in ANSI C for USB and AVR®peripherals with few clicks of

the mouse.

This utility is located in \USBWizard\USBWizard direcotry. This directory contains the

USB Wizard executable file and other dependencies files.

DB25 Parallel Cable

J3 J2 J1

AT43DK355 Development Board

USB Cable

Target USB Device Target USB Device

Getting Started

AT43DK355 USB Controller Dev. Kit User Guide 2-3

3429C–USB–7/04

Please refer to the Readme file on the release CD for the installing instructions. The

USB Wizard executable file is supported on Windows®98/2000/ME/XP.

Source code generated by the USB Wizard cannot be programmed directly into the on-

board SEEPROM device. It must be compiled and linked first. The USB Wizard currently

supports IAR and GCC compilers.

Refer to the Atmel “USB Wizard User Guide” and “USB Wizard: Application Examples

and Demos” for detailed descriptions of this utility.

Figure 2-2. USB Wizard Application Window

2.6.2 Code Base Directory This is the directory where all code base needed by USB Wizard are taken from. The

name of this directory is \USBWizard\Codebase. There are two main groups of code

base within this directory. The first one is IARbase, which provides necessary code for

IAR. The second one is GCCbase which contains the code for the GCC compiler. The

following is a brief summary of directory tree of this code base.

Code base

|------------ IARbase

| |------ AT43USB35x

| |------ AT43USB326

| |------ AT43USB325E

|------------ GCCbase

|------ AT43USB35x

|------ AT43USB326

|------ AT43USB325E

Getting Started

2-4 AT43DK355 USB Controller Dev. Kit User Guide

3429C–USB–7/04

2.6.3 Application Example The application examples are also included within this package. They are located in

\USBWizard\Examples\ directory. This directory contains USB Wizard configuration files

(*.usw files) and the corresponding C files for application examples. There are five sub-

directories in this directory:

1. PWM_ADC_GPIO

2. OCR1A

3. OCR1B

4. SPI

5. Hub_Disabled

2.6.4 In-System

Programming Tool

The SEEPROM Loader allows developers to program the SEEPROM device through

the standard parallel port. The tool is located in \USBWizard\ISP\ directory.

Please refer to the Readme file for installation instructions.

Please read Section 4 of this document or Section 3 of Atmel USB Wizard: Application

Examples and Demos on how to use this utility.

Figure 2-3. SEEPROM Loader Tool Window

2.6.5 Atmel USB HID

Demo Utility

This tool, located in \USBWizard\Demo_Utility\, is purposed to exercise the functionality

of application examples.

To install it, copy and paste the executable file in this directory to the desired location.

How to use this utility will be fully explained in Atmel USB Wizard: Application Examples

and Demos especially for example 1 (PWM, ADC, and GPIO).

Inhaltsverzeichnis

Andere Atmel Mikrocontroller Handbücher

Atmel

Atmel AT90PWM2 Bedienungsanleitung

Atmel

Atmel AVR ATtiny15L Betriebsanleitung

Atmel

Atmel AT91SAM9 Montage- und Bedienungsanleitung

Atmel

Atmel ATmega48PV Bedienungsanleitung

Atmel

Atmel AT91CAP9A-DK Bedienungsanleitung

Atmel

Atmel AVR1014 Bedienungsanleitung

Atmel

Atmel AT43DK325 Bedienungsanleitung

Atmel

Atmel AT89C51 Benutzerhandbuch

Atmel

Atmel ATmega8 Bedienungsanleitung

Atmel

Atmel AT97SC3205T-SDK2 Bedienungsanleitung

Atmel

Atmel ATtiny1634-EK1 Bedienungsanleitung

Atmel

Atmel AVR Bedienungsanleitung

Atmel

Atmel ATmega128 Bedienungsanleitung

Atmel

Atmel AVR XMEGA AU series Bedienungsanleitung

Atmel

Atmel SAM HA1G16A Xplained Pro Bedienungsanleitung

Atmel

Atmel C51 Montage- und Bedienungsanleitung

Atmel

Atmel ATmega161 Bedienungsanleitung

Atmel

Atmel SAM D09 Montage- und Bedienungsanleitung

Atmel

Atmel AT89C5130A-M Bedienungsanleitung

Atmel

Atmel SAM4N Xplained Pro Bedienungsanleitung

Atmel

Atmel ATSAMB11 BluSDK SMART Bedienungsanleitung

Atmel

Atmel UC3 Series Bedienungsanleitung

Atmel

Atmel megaAVR Bedienungsanleitung

Atmel

Atmel AT91 Series Montage- und Bedienungsanleitung

Beliebte Mikrocontroller Handbücher anderer Marken

AMS

AMS AS7261 Demo Kit Bedienungsanleitung

Novatek

Novatek NT6861 Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266 SDK Einrichtungshandbuch

Nuvoton

Nuvoton ISD61S00 ChipCorder Leitfaden

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Bedienungsanleitung

Texas Instruments

Texas Instruments Chipcon CC2420DK Bedienungsanleitung

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Bedienungsanleitung

NEC

NEC 78GK0S/K 1+ Series Montage- und Bedienungsanleitung

Mikroe

Mikroe SEMITECH N-PLC Click Montage- und Bedienungsanleitung

Intel

Intel Agilex Bedienungsanleitung

Cypress

Cypress CY4607 HX2VL Bedienungsanleitung

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Bedienungsanleitung

Texas Instruments

Texas Instruments TMS320F2837 D Series Bedienungsanleitung

CYPRES

CYPRES CY14NVSRAMKIT-001 Bedienungsanleitung

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Bedienungsanleitung

Espressif Systems

Espressif Systems ESP8266EX Betriebsanleitung

Abov

Abov AC33M8128L Bedienungsanleitung

Laird

Laird BL654PA Bedienungsanleitung
