Audiovox XAPH1 Bedienungsanleitung
User Guide
ADDITIONAL HOME KIT
i
3
Table of Contents
Introduction....................................................5
Features.................................................................... 6
SafetyandCareInformation .................................................. 7
What’sintheBox?...........................................................8
HomeDock ................................................................. 9
RemoteControlFunctions ....................................................10
Home Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Step1:ConnecttheHomeDock................................................12
Step 2: Install the Indoor/Outdoor Home Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Troubleshooting................................................21
ProductSpecifications ..........................................25
PatentInformation.......................................................... 27
EnvironmentalInformation...................................................27
4
5
Introduction
6
Introduction
Features
Congratulations on your purchase of the XMp3i™ Additional Home Kit!
Your new Home Kit lets you play your XMp3i™ or Pioneer XMp3™ Radio through
another stereo system or a set of powered speakers.
• Add Satellite Radio to another room: No need for a second subscription.
Just connect this Kit with another stereo system or set of powered
speakers – in the den, the kitchen, a bedroom, or at the office — and then
simply move your Radio between the two.
• Listen with any system: Works with any stereo system or set of powered
speakers that have audio input jacks.
• Easily change channels and volume: Included Remote Control lets you turn
your XMp3i™ Radio on or off, change channels, adjust the volume, and
more, even from across the room.
• Stay charged: Charges your Radio while you listen.
And for the latest information about this and other SIRIUS|XM products and
accessories, visit xmradio.com or your favorite retailer.
Please read the entire User Guide before installing your Home Kit!
7
Safety and Care Information
IMPORTANT! Always read and understand all the instructions to avoid
injury to yourself and/or damage to your device. SIRIUS XM Radio Inc.
disclaims all responsibility for damage from data loss due to breakdown,
repair, or other causes.
• Do not expose to extreme temperatures (above 140ûF or below -4ûF, or
above 60ûC or below -20ûC).
• Do not expose to moisture. Do not use device near or in water. Do not
touch the device with wet hands.
• Do not let any foreign matter spill into device.
• Do not store in dusty areas.
• Do not expose to chemicals such as benzene and thinners. Do not use
liquid or aerosol cleaners. Clean with a soft damp cloth only.
• Do not expose to direct sunlight for a prolonged period of time, and do
not expose to fire, flame, or other heat sources.
• Do not try to disassemble and/or repair device yourself.
• Do not drop your device or subject it to severe impact.
• Do not place heavy objects on device.
• Do not subject device to excessive pressure.
WARNING!
• Opening the case may result in electric shock.
• Make sure that you insert the Home Power Adapter’s plug all the way
into the outlet.
8
Introduction
What’s in the Box?
Indoor/Outdoor
Home Antenna Stereo Audio
Cable
Home Power
Adapter
Home Dock
Remote Control
9
Home Dock
Color-Coded Connections
The Color-Coded Home Dock makes it simple to connect.
ANT (Silver)
Connection for
the Indoor/Outdoor
Home Antenna.
AUDIO (Green)
Connection for stereo
system or set of
powered speakers.
Rear/Side View
POWER (Red)
Connection for
the Home Power
Adapter.
ANT
AUDIO
10
Remote Control Functions
30-Minute Replay Buttons
Pause and replay up to 30
minutes of Satellite Radio
programming.
Power Button
Record
Record a song or a
channel. Also schedule a
recording and set channel
to auto record.
Arrow Buttons
Navigates through
lists and highlights list
items.
Options
Displays a menu in context
according to what you are
doing.
Select Button
Press to confirm
highlighted selections.
Back
Return to previous
screen. Press and
hold to return to the
previous channel.
Jump
Switches between current
channel and previously
tuned channel.
Menu
Go to Satellite Radio,
My Music Library, Auto
Recordings, or Settings.
Number Keys
Enter a channel number
directly to tune to the
channel.
+ and —
Change channels or
control volume for audio
system (sold separately).
Mute
Silences the audio.
