RF-310

PROFESSIONAL VEHICLE SECURITY SYSTEM

OPERATION MANUAL

IS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY

TRANSMITTER OPERATION:

Transmitter Button System Function Remark

Button Arm / Lock door

–Button Arm and Delete Optional Sensor Press twice.

Button Car Locator System in Armed.

Button for 3 seconds Panic function Press 3 seconds

Button Disarm & Unlock Door

–Button Two Steps Door Unlock &

Disarm System Press twice within 3

seconds.

Button Car Locator

Button for 2 seconds

Pop Trunk Release Press 2 seconds

Button for 3 seconds

Panic function If the H3/6 Gray Wire is

not Trunk release Output

(See Alarm Feature III-2)

+Button Silent Arm / Disarm

Silent Arm / Disarm

Side button 2nd Car Operation or

Garage Door Opener Side Button

Switching Code

ACTIVE ARMING –LOCK & ARM:

1. Press

button on transmitter.

2. The siren will chirp once and parking light will flash once indicating that the system is now

armed. The vehicle doors will lock upon arming when interfaced with the security system.

Note: Defective sensor reminder: If the siren sounds 3 chirps, then you have left a door,

trunk, or hood lid ajar. (See Feature “I -3 Programming)

SILENT ARMING / DISARMING: Press the button on the transmitter to arm or disarm

your security system with no chirp sound heard; arm / disarm confirmation will be through the

vehicles parking lights only.

SHOCK SENSOR / OPTIONAL SENSOR BY-PASS: Press the

button on the transmitter

twice within 3 seconds will arm the security system, by-pass the shock sensor or the optional

sensor connected to 4 pin plug. The system will chirp one additional time to confirm the

sensor bypass mode was activated. The sensor bypass feature is programmed to activate for

one arming cycle only. The security system will return to normal operation during the next

arming cycle.

PASSIVE ARMING: (See Feature “II -2” Programming)

Active arming / disarming is controlling your security system via the remote transmitter. This

security system is equipped with an optional Passive Arming feature, which allows the

security system to arm 30 seconds after the last door is closed. Operation is as follows.

1. Turn the ignition to the “OFF” position and exit the vehicle. (CONT. NEXT PAGE)

2. After all entrances are closed, the security system LED will flash fast for 30 seconds. If you

reopen any door / hood / trunk, the security system LED will stop flashing. It will begin

flashing again once all vehicle entrances are closed.

3. After 30-second timer has elapsed, the security system will automatically “ARM”. The siren

will chirp [1] time and the parking lights will flash [1] time.

PASSIVE DOOR LOCKING: (See Feature “II -2” Programming)

The vehicle doors will automatically lock after passive arming cycle has been completed.

ACTIVE DISARMING –UNLOCK & DISARM:

1. Press the

button on the transmitter.

2. The siren will chirp twice and parking lights will flash twice to indicate that the security

system is now disarmed. The vehicle doors will unlock and disarm when interfaced with the

security system.

TAMPER DISARMING: If the alarm is triggered; upon disarm the system, the siren will chirp 4

times and parking lights will flash 3 times.

TWO STEP DOOR UNLOCK: (See Feature III –2 Programming.) This feature will

independently unlock the driver’s door only when disarming the security system. Pushing the

button on the transmitter a second time within 3 seconds will unlock the entire vehicle.

AUTOMATIC RE-ARM (See Feature “I -2” Programming): If this feature is selected, the

security system will automatically re-arm itself 60 seconds after disarming with remote

transmitter. Automatic rearm will cancel if any door is opened before the 60 seconds timer has

elapsed.

DISARMING WITHOUT A TRANSMITTER

The Override function may be used if the remote transmitter is lost or inoperative.

1. Enter the vehicle and turn the ignition switch to 'ON’ position. (Alarm will sound.)

2. Within 10 seconds push and release the valet switch

The alarm will stop sounding and enter the disarm mode. You can now start and operate the

vehicle normally.

VALET MODE:

The valet switch allows you to temporarily bypass all alarm function, eliminating the need to

hand your transmitter to parking attendants or garage mechanics. When the system is in

valet mode, all alarm functions are bypassed, however, the remote panic feature and remote

door locks will remain operational.

Enter Valet Mode:

1.Turn the ignition to “ON” position.

2. Push and hold valet switch for 2 seconds or until the LED turns on. The LED will remain on

as long as the system is in 'valet mode'.

Exit Valet Mode:

1. Return to normal operation, turn ignition 'ON'.

2. Push and hold valet switch for 2 seconds; the LED will turn off indicating the system is

exiting the valet mode.

PANIC FUNCTION:

The transmitter can be used as a remote panic switch to manually trigger the alarm in case of

emergency.

1. Press and hold the button on the transmitter for 3 seconds. The alarm will immediately

sound.

2. To stop the alarm, press and hold the or button on the transmitter, the panic mode

will be turned off immediately.

3. If the button is not pressed, the alarm will automatically stop after 30 seconds.

Note: If the H3/6 Gray Wire is not a Trunk release Output, (See Alarm Feature III-2

Programming), Press and hold the button on the transmitter for 3 seconds. The alarm will

immediately sound.

TRIGGER THE SYSTEM

When armed, your vehicle is protected as follows:

1. Light impacts will trigger the warn-away signal. A long chirp from siren/horn.

2. Heavy impacts / Doors open / Hood open / Trunk open / Turning on the ignition switch-All

will trigger the programmed sequence.

The starter disable relay (if installed) prevents the vehicle’s starter from cranking. The siren and

parking lights will turn on to alert of an intrusion for 30 seconds. Then the siren will stop and

automatically reset and re-arm. If any the sensors or detectors are still active, the alarm system

will sound a maximum of six-30 second cycles.

IGNITION CONTROL DOOR LOCKS. (See Feature II –3 Programming.).

If the vehicle’s door locks have been interfaced to the security system, the system will

automatically lock the vehicle's doors when the ignition is turned “ON” and /or unlock the

vehicle’s doors when the ignition is turned “OFF”.

TRUNK RELEASE. (See Feature III –2 Programming.).

Press and hold button on transmitter for two seconds to remote control the trunk release

or other electric devices.

CAR LOCATOR

Press the button on the transmitter to active car locator function. The siren will chirp 6

times. The parking light will flash 12 times, allowing you to easily locate your car.

P. PATHWAY ILLUMINATION (See Feature III -3 Programming.)

When disarming the security system, the vehicle’s parking lights will stay on, illuminating a

pathway to the vehicle. The vehicles parking lights will stay on for 30 seconds or until the

vehicle’s ignition is turned to the “ON” position.

ALARM OPERATING CONDITION:

Function

Siren Parking

Lights LED Doors Starter

Disable

Pager

Option

1. Arm 1 Chirp 1 Flash Slow flash

Locking On

2. Disarm 2or4

Chirps 2 or 3

Flashes

Off or

Fast flash

Unlocking Off

3. Trigger Alarming Flashing Slow flash

On On

4. Panic Alarming Flashing Slow flash

Locking On

ALARM INDICATORS

CHIRP INDICATORS: PARKING LIGHTS:

Chirp Function Parking Light Function

1 chirp Arm 1 flash Arm

2 chirps Disarm

2 flashes Disarm

3 chirps Defective

reminder 3 flashes Disarm/

Intrusion

4 chirps Disarm/

Intrusion

12 flashes Car

Locator

6 chirps Car

Locator

LED INDICATORS:

LED Function

Off Disarmed

flashes...

pause

Trigger on trunk/hood

Slow

flash Armed

flashes...

pause

Trigger on door switch

Fast

flash Passive

arming

flashes...

pause

Trigger on Dual Zone

Shock Sensor

(solid) Valet mode

flashes...

pause

Trigger on Ignition

switch

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions.

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that

may cause undesired operation.

LIMITED LIFETIME WARRANTY PROVISIONS

( U.S. and Continental U.S. Only)

1. AutoPage, Inc. WARRANTS that this new unit has been thoroughly inspected and tested at the

factory prior to delivery. Your AutoPage equipment is guaranteed for “life” to the original

purchaser/user of the equipment under the following conditions: If the product proves defective

(according to AutoPage’s testing) within the first year, the defective unit may be exchanged or

repaired free of charge. “Proof of Purchase” (dated sales receipt) must accompany all warranty

returns; otherwise, your return will be rejected and sent back.After one(1)year,thepurchaser

should ship the unit prepaid to AutoPage with a money order in the amount of $20.00 to cover

shipping and handling charges. Note:The enclosed Warranty Card may be required to receive

warranty services.

2. This WARRANTY will be considered void if the equipment has been misused, neglected,

improperly serviced, altered, dropped or damaged by water, contrary to the AutoPage

OPERATIONS MANUAL. Or, if used with accessories not approved by AutoPage, which may

have contributed to the defect. See note below regarding product installation.

3. The purchaser’s remedies under this WARRANTY shall be limited to the repair or replacement of

electronic components only. THE FOLLOWING IS NOT COVERED:Damagesordeterioration

to cases, batteries, covers and cabinets; the cost of repairs, replacement and labor of which shall be

borne by the purchaser even if occurring during the WARRANTY period.

4. Any equipment or parts which are claimed to be defective under this WARRANTY must be sent to

the AutoPage Service center with “proof of purchase” at the purchaser’s expense prior to such

return, a Return Authorization Number should be obtained. AutoPage will return the equipment,

charges prepaid. Warranty Service can be provided through the dealer where the equipment is

originally purchased.

5. Any unexpired WARRANTY shall be applicable to equipment and parts in the possession of the

original purchaser only.

6. THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR

IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTYOFMERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE.

7. AutoPage shall not be liable, under the foregoing WARRANTIES or otherwise, for: Any personal

injury of any kind to the purchaser, its employees or agents or anyone else whomsoever resulting

directly or indirectly from the use or presence of the equipment or parts; Consequential damages of

any kind; any inability of the purchaser to use the equipment.

IMPORTANT NOTE: Any damages to the alarm system resulting from an

installation performed by anyone other than a professional installation

technician authorized by a dealer of Auto Page will void the product’s warranty.

This WARRANTY CARD is for your record. However, AutoPage reserves the right to request

you to submit this WARRANTY CARD which must have complete information to receive

warranty service. Please keep this card in a secured place.

AUTOPAGE WARRANTY SERVICE CARD

Model: _______________

Serial # _______________

CUSTOMER TO COMPLETE DEALER TO COMPLETE

Mr./Mrs./Ms.

_______________________________ ________________________________

Your Name (Please Print) Company Name

_______________________________ ________________________________

Address Dealer’s Address

_______________________________ ________________________________

City, State, Zip Code City, State, Zip Code

_______________________________ ________________________________

Telephone Number Dealer’s Telephone Number

_______________________________ ________________________________

Year / Make / Model of Vehicle Date of Installation / Purchase

________________________________

Dealer’s Signature

“Proof of Purchase” which includes the store name and date of purchase must

accompany all warranty returns.

It is the purchaser’s responsibility to keep this card for any future warranty service.

1815 West 205th Street Suite 101

Torrance, California 90501-1525

Main Office: 310-618-2002

Customer Service: 800-262-2527 Ext. 462

www.autopageusa.com

Inhaltsverzeichnis

Andere Auto Page Autoalarmanlage Handbücher

Auto Page

Auto Page RF-425LCD Bedienungsanleitung

Auto Page

Auto Page RF-302 Bedienungsanleitung

Auto Page

Auto Page RF-420LCD Bedienungsanleitung

Auto Page

Auto Page RF-502 Bedienungsanleitung

Auto Page

Auto Page RF-503 Bedienungsanleitung

Auto Page

Auto Page RS-655 Bedienungsanleitung

Auto Page

Auto Page C3-RS-900LCD Bedienungsanleitung

Auto Page

Auto Page RF-320 Bedienungsanleitung

Auto Page

Auto Page RF-1055KE Betriebsanleitung

Auto Page

Auto Page A.P.I. EXP-52 Bedienungsanleitung

Auto Page

Auto Page Car-Pro CPX-2500 Bedienungsanleitung

Auto Page

Auto Page RF-520LCD Bedienungsanleitung

Auto Page

Auto Page RF-305 Bedienungsanleitung

Auto Page

Auto Page Professional Vehicle Security System RF-315 Bedienungsanleitung

Auto Page

Auto Page CAR-PRO CPX-2350 Bedienungsanleitung

Auto Page

Auto Page MA-200 Bedienungsanleitung

Auto Page

Auto Page Telematics and Tracking Module Bedienungsanleitung

Auto Page

Auto Page AP4000EX Technisches Datenblatt

Auto Page

Auto Page C3-RS-727A LCD Bedienungsanleitung

Auto Page

Auto Page RF-505 Bedienungsanleitung

Auto Page

Auto Page RF405A Bedienungsanleitung

Auto Page

Auto Page Car-Pro CPX-3600 Bedienungsanleitung

Auto Page

Auto Page RF-315 Bedienungsanleitung

Auto Page

Auto Page Car-Pro CPX-2200 Bedienungsanleitung

Beliebte Autoalarmanlage Handbücher anderer Marken

Clifford

Clifford 3606X Bedienungsanleitung

Ultra Start

Ultra Start 2500M SERIES Bedienungsanleitung

Ultra Start

Ultra Start 650 Series Bedienungsanleitung

Audiovox

Audiovox Prestige Platinum+ APS-511C Bedienungsanleitung

Sparkrite

Sparkrite SRA8 Bedienungsanleitung

Viper

Viper 4708V Bedienungsanleitung

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Handbuch

Falcon

Falcon Predator XL3 Benutzerhandbuch

Audiovox

Audiovox Auto Security XR91 Betriebsanleitung

Clifford

Clifford Sabre II Bedienungsanleitung

CrimeStopper

CrimeStopper CS-8717 Kurzanleitung

Ultra Start

Ultra Start 450 SERIES Bedienungsanleitung

Scytek electronic

Scytek electronic Vectra X3 Bedienungsanleitung

Excalibur

Excalibur AL-1860-EDPB Bedienungsanleitung

Clifford

Clifford CYBER 2 Bedienungsanleitung

Gemini

Gemini 7057 Bedienungsanleitung

FlashLogic

FlashLogic FLRSBA PRESTIGE Bedienungsanleitung

Magicar

Magicar FAI-440 Bedienungsanleitung
