Avision AV100CS Bedienungsanleitung
Document Scanner
Getting Started Guide
Trademarks
Microsoft is a U.S. registered trademark of Microsoft
Corporation.
Windows, Windows Vista, Windows 7 and Windows 8 are either
registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries.
Other brands and product names herein are trademarks or
registered trademarks of their respective holders.
Copyright ©2015 Avision Inc.
English
ii
Table of Contents
1. Introduction .............................................................1-1
2. Scanner Installation.............................................. 2-1
2.1 Unlocking Your Scanner ................................ 2-1
2.2 Installing the Scanner Driver and Connecting
the Cables................................................... 2-2
2.2.1 Connecting to Power ..................................2-2
2.2.2 Turning on the Power.................................2-3
2.2.3 Installing the Scanner Driver ...................2-3
2.2.4 Connecting to Computer ...........................2-4
3. Completing Your First Scan................................ 3-1
3.1 Loading Your Paper ...................................... 3-1
3.2 Verifying Your Scanner Installation ................. 3-5
4. ISIS Interface Operation ....................................4-1
5. Using the Buttons .................................................. 5-1
5.1 Installing Button Manager V2 ......................... 5-1
5.2 Checking the Button Configurations Before
Scanning .................................................... 5-1
5.3 Scanning From One Touch of the Buttons........ 5-3
6. Maintenance .............................................................6-1
6.1 Cleaning the Flatbed Glass ............................ 6-1
6.2 Cleaning the ADF ......................................... 6-2
6.3 Cleaning the Calibration Area......................... 6-3
7. Troubleshooting......................................................7-1
7.1 Clearing a Paper Jam .................................... 7-1
Getting Started
1-1
1. Introduction
Congratulations on your purchase of the color sheet-fed
image scanner. With this scanner, you can you scan your
multi-page documents from the auto document feeder at a
rated speed or scan irregular single-page document from the
flatbed.
The following figure indicates the package contents. Please
check all the items against your checklist. If you do not
receive all the items, please contact your authorized local
dealer immediately.
1. Scanner Main Unit
2. Software CD
3. USB Cable
4. Power Adapter & Power Cord
2 3 4
1
Getting Started
2-1
2. Scanner Installation
2.1 Unlocking Your Scanner
The scan unit is locked during transport to protect the scanning
mechanism from being damaged. Be sure to unlock the scan
unit before using the machine.
Turn over the machine to
locate the lock switch.
Move the lock switch to the
"unlocked position".
If you need to transport the
machine, please move the
lock switch to the “Locked”
position. Before doing this,
make sure the scan unit at
the left end of the glass as
indicated. (If not, please
turn on the machine. When
the scan unit moves to the
left end, turn off the
machine.)
T
he scan unit
must be at
this position
before being
locked.
“Locked Position”
“Unlocked Position”
2-2
2.2 Installing the Scanner Driver and Connecting the
Cables
NOTE:
1). The Windows system CD may be required when installing
on some PC’s.
2). To ensure your computer can identify the USB scanner,
please install scanner driver first before connecting the
scanner to your computer.
3). The scanner driver contains TWAIN, ISIS and WIA driver.
This scanner allows you to scan via a TWAIN, ISIS, or a
WIA (Windows Image Acquisition) interface. Start your
TWAIN-compliant image editing software application to
select a TWAIN or WIA user interface or your ISIS software
to select a ISIS user interface. You may also launch
Microsoft’s Scanner and Camera Wizard to scan via a WIA
user interface.
2.2.1 Connecting to Power
Before connecting, make sure the power switch is off.
Plug the small end of the power adaptor into the power jack of
your scanner. Insert the other end to an appropriate power
outlet.
Getting Started
2-3
2.2.2 Turning on the Power
Press the Power Switch button on the front panel, the Power
LED will flash. When it is finished and ready to scan, the
LED indicator will stop flashing and become steadily on. To
turn off the scanner, press the Power Switch button for
about 3 seconds, the Power LED will be off.
2.2.3 Installing the Scanner Driver
1. Place the supplied CD-ROM onto your CD-ROM drive.
2. The software installation graphic appears. If not, run
“setup.exe”.
2-4
3. Click Install Button Manager V2 to install the Button
Manager V2 software and then click Install Scanner
Driver to install the scanner driver on your computer.
2.2.4 Connecting to Computer
1. Connect the square end of the USB cable to the USB port of
your scanner. Connect the rectangle end to the USB port of
your computer.
2. The computer should detect a new USB device and prompt
a “New Hardware Found” message.
3. Click the Next button to continue. When the certification
screen appears, click Continue Anyway to complete the
installation.
4. When the Finish dialog is prompted, click the Finish
button.
Getting Started
3-1
3. Completing Your First
Scan
3.1 Loading Your Paper
3.1.1 Placing Your Document on the Flatbed
Open document cover. Place your document FACE DOWN on
the document glass and align the document to the reference
mark as indicated. Close document cover.
3-2
3.1.2 Loading Your Document in the ADF Paper Tray
3.1.3 Notice on Using the ADF
Before using the ADF, please make sure that your paper meets
the following specifications:
Document(s) should be square or rectangular and in good
condition (not fragile or worn).
Document(s) should be free of curl, wrinkle, tears, wet
ink, or punch holes.
Document(s) should be free of staples, paper clips, paper
sticky notes.
Getting Started
3-3
Fanning Your Document
Standard paper size should feed easily through the scanner.
To avoid occasional paper jam when automatically feeding
multiple documents, loosen the paper before loading.
Document Feeding
1. Load the stack of document face down with the top of
the pages pointing into the feeder.
2. Verify that the paper guides are aligned with the edges
of the stack.
Your
Document
(Face
Down)
Paper
Guide
