Avision AV620CS PLUS Bedienungsanleitung

User’s Manual

AV620CS PLUS

Color Image Scanner

Doc. No.250-0221-E Rev. 1.0

Avision Inc.

Trademarks

Microsoft is a U.S. registered trademark of Microsoft Corporation.

Windows and MS-DOS are trademarks of Microsoft Corporation.

IBM, PC, AT, XT are registered trademarks of International Business

Machines Corp.

Other brands and product names herein are trademarks or registered

trademarks of their respective holders.

transmitted, transcribed, stored in a retrieval system, or translated

into any language or computer language, in any form or by any

means, electronic, mechanical, magnetic, optical, chemical, manual,

or otherwise, without the prior written permission of Avision Inc.

Material scanned by this product may be protected by governmental

laws and other regulations, such as copyright laws, the customer is

solely responsible for complying with all such laws and regulations.

Warranty

The information contained in this document is subject to change

without notice.

Avision makes no warranty of any kind with regard to this material,

including, but not limited to, the implied warranties of fitness for a

particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

iii

FCC Radio Frequency Interference

Statement

This equipment has been tested and found to comply with the limits

for a class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may

cause harmful interference to radio communication. However, there

is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

− Reorient or relocate the receiving antenna.

− Increase the separation between the equipment and receiver.

− Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

− Consult the dealer or an experienced radio/TV technician for help.

FCC CAUTION: To assure continued compliance, (example - use

only shield interface cables when connecting to computer or

peripheral devices). Any changes or modifications not expressly

approved by the manufacture of this device could void the user's

authority to operate the equipment. This device complies with Part

15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including

interference that may cause undesired operation.

Responsible Party: AVISION LABS INC.

6815 Mowry Ave. Newark CA 94560,

Telephone No.: USA

+1 (510) 739-2369

EC Declaration of Conformity

Manufacturer's Name: Avision Inc.

Manufacturer's Address: No. 20 Creation Rd. 1,

Science- Based Industrial Park,

Hsinchu 300, Taiwan, R.O.C.

declare that the product

Model Number : AV620CS Plus

conforms to the following Product Specifications:

Emission: EN 50081-1 (1992)

EN 55022 (Class B) (1994)

(Conducted/Radiated)

EN 61000-3-2 (Hormonics)(1995)

EN 61000-3-3(Flicker) (1995)

Immunity: EN50082-1 (1997)

IEC 1000-4-2 (ESD) (1995)

IEC 1000-4-3 (RS) (1995)

IEC 1000-4-4 (EFT/Burst) (1995)

IEC 1000-4-5 (SURGE) (1995)

Date: December 1997

TABLE OF CONTENTS

1.INTRODUCTION...................................................... 1-1

2.SCANNER INSTALLATION..................................... 2-1

2.1 PRECAUTIONS................................................................2-1

2.2 UNLOCKING YOUR SCANNER........................................2-2

2.3 SETTING SCSI ID.............................................................2-3

2.4 SETTING SCSI TERMINATOR.........................................2-3

2.5CONNECTING THE CABLES............................................2-5

2.6 INSTALLING THE SCSI CARD.........................................2-7

2.6.1 PC USERS................................................................2-7

2.6.2 MAC USER...............................................................2-8

2.7 PLACING YOUR ORIGINAL .............................................2-9

3.SCANNER DRIVER INSTALLATION...................... 3-1

3.1 MAC USERS.....................................................................3-1

3.2 PC USERS........................................................................3-4

3.2.1 BEFORE INSTALLING THE SCANNER DRIVER......3-4

3.2.2 WINDOWS 3.1 OR WINDOWS 3.1X........................3-5

3.2.3 WINDOWS 95...........................................................3-5

3.2.4 WINDOWS 98/ 95 OSR2 ..........................................3-6

3.2.5 WINDOWS NT4.0.....................................................3-7

3.2.6 UNINSTALL THE SCANNER DRIVER......................3-8

4.SCANNER OPERATION.......................................... 4-1

4.1 STARTING YOUR FIRST SCAN FROM WITHIN A TWAIN

OR A PLUG-IN APPLICATION ...............................................4-1

4.2 USING AVISION SCANNER DRIVER USER INTERFACE4-5

4.2.1 CHOOSING YOUR SCANNING SOURCE................4-5

4.2.2 DETERMINING YOUR RESOLUTION......................4-6

4.2.3 SELECTING A PROPER IMAGE TYPE....................4-8

4.2.4 ENHANCING YOUR IMAGE...................................4-13

4.2.4.................................................................................4-13

4.2.5 VIEWING THE IMAGE TOOL.................................4-24

4.2.6 OTHER TOOLS ......................................................4-25

4.2.7 STARTING FINAL SCAN........................................4-26

4.3 USING BUNDLED APPLICATION SOFTWARE..............4-27

4.3.1 INSTALLING THE APPLICATION SOFTWARE......4-27

4.3.2 VIEWING THE ONLINE MANUAL...........................4-28

5.CARE AND MAINTENANCE ................................... 5-1

5.1 CLEANING THE GLASS...................................................5-1

6.TROUBLESHOOTING............................................. 6-1

6.1 FREQUENTLY ASKED QUESTIONS ...............................6-1

6.2TECHNICAL SERVICE ......................................................6-4

7.SPECIFICATIONS ................................................... 7-1

7.1 MODEL: AV620CS PLUS.................................................7-1

INDEX .............................................................................a

AV620CS Plus 1-1

1. INTRODUCTION

Congratulations on your purchase of the Avision color image scanner.

Avision is one of the leading companies to make high quality color

image scanners.

To ensure the optimal performance of the scanner, please take a

few minutes to read through this manual before you install and

operate the new scanner. The manual contains valuable

information on how to unpack, install, operate, and maintain the

scanner properly.

1-2 AV620CS Plus

Figure 1-1 in below shows how the scanner is packed. Please

check if all items are included. If there is any item missing or

damaged, please contact your nearest dealer immediately for

replacement.

Figure 1-1 Package contents

Note: When you unpack the scanner, retain the packing

material and shipping box in case you may transport the

scanner in the future.

1.Scanner

2.CD, Manual,

Registration card

3.Power adapter

4.Scanner cable

AV620CS Plus 2-1

2. SCANNER INSTALLATION

2.1 PRECAUTIONS

v Keep the scanner out of direct sunlight. Direct exposure to

the sun or excessive heat may cause damage to the unit.

v Do not install the scanner in a humid or dusty place.

v Be sure to use the proper AC power source.

v Place the scanner securely on an even, flat surface. Tilted or

uneven surfaces may cause mechanical problems.

v Keep the shipping box and the material in case you may need

to ship the scanner again.

2-2 AV620CS Plus

2.2 UNLOCKING YOUR SCANNER

To protect the scanning unit from damage during

transportation, a lock switch is designed under the scanner

to keep the scanning unit from moving.To unlock the

scanner, please first place the scanner as Fig. 2-1 and

locate the lock switch at the corner and then move the lock

switch to the “Unlock” position as shown in below.

Figure 2-1 Unlocking the Scanner

Note: Likewise, if next time you need to transport the scanner, be

sure to move the lock switch to the “Lock” position. Otherwise,

there may be some damage to the scanning unit during

transportation and the manufacturer is therefore not responsible

for this.

lock

unlock
