Trailled Oset Disc Harrow
Trailled Oset Disc Harrow
Light
CRSG 32-48
CRSG-L 18-32
Drag Type Oset Disc Harrow Remote Control
Drag Type Oset Disc Harrow Remote Control
Strong
CRI 32-44
CRI-R 12-26
We thank you for the preference and congratulate your excellent choice in acquiring an
implement of outstanding quality, manufactured in accordance with the advanced te-
chnology of BALDAN IMPLEMENTOS AGRÍCOLAS S/A.
This manual will assist you, in proceeds necessaries, since when you bought until the
operational proceeds application, security and maintenance.
The BALDAN guarantees that deliver this implement to the dealer, working properly, and in perfect
conditions.
The dealers it’s under the responsibility to keep the protection and conservation while keep the implement in your stock, and
than, to assembly, tighten, lubrication and overhaul.
On time of the technical deliver, the dealer must to have conducted the user customer about the manutentation, safety, and
your obligations in a possible technical assistance, the obligation to see the warranty terms and read the instruction manual.
Any solicitation of warranty, please contact our Baldan technical service, by your Baldan dealer that you bought our implement.
Rearm the necessity to read carefully of warranty certicate and note all of items from this manual, therefore you will increa-
se the working life of your equipment.
INTRODUCTION
Instruction Manual
BALDAN IMPLEMENTOS AGRÍCOLAS S/A.
CNPJ: 52.311.347/0009-06
Insc. Est.: 441.016.953.110
Escaneie o Código QR Code na
plaqueta de identificação do seu
equipamento e acesse online este
Manual de Instruções.
Trailled Oset Disc Harrow
Trailled Oset Disc Harrow Light
CRSG 32-48
CRSG-L 18-32
Drag Type Oset Disc Harrow Remote Control
Drag Type Oset Disc Harrow Remote Control Strong
CRI 32-44
CRI-R 12-26
INDEX
01. Safety rules.................................................................................................................................................................................................................................................................. 4 - 8
02. Components............................................................................................................................................................................................................................................................... 9
03. Technical specications ........................................................................................................................................................................................................................................... 10 - 11
04. Assembly ..................................................................................................................................................................................................................................................................... 13 - 15
Assembly of front and rear gang ....................................................................................................................................................................................................................................................................... 16 - 17
Mounting of the hydraulic system and articulating wheel assembly CRSGL 18 32 / CRIR 12 26 models with single wheels ................................................................................................................. 18
Mounting of the hydraulic system and the articulating wheel assembly CRSG 32 - 48 / CRI 32 44 models with dual wheels...................................................................................................................... 19
Mounting of the hitch system............................................................................................................................................................................................................................................................................ 20
05. Hitch.............................................................................................................................................................................................................................................................................. 21
Hitching to the tractor........................................................................................................................................................................................................................................................................................ 21
Hitching to the tractor (CRI 44 Discs) ................................................................................................................................................................................................................................................................. 22-24
06. Adjustments and operations.................................................................................................................................................................................................................................. 25
Transport ........................................................................................................................................................................................................................................................................................................... 25
Transport/work.................................................................................................................................................................................................................................................................................................. 25
Disc harrow gangs adjustments........................................................................................................................................................................................................................................................................ 26
Displacement adjustment ................................................................................................................................................................................................................................................................................. 26
Cross bar adjustment......................................................................................................................................................................................................................................................................................... 27
Adjusting the stabilizer bar and stabilizer bar support ..................................................................................................................................................................................................................................... 27
Operations ......................................................................................................................................................................................................................................................................................................... 28
07. Lubrication.................................................................................................................................................................................................................................................................. 29
08. Lubrication Points ..................................................................................................................................................................................................................................................... 30 - 31
09. Bearing adjustments ................................................................................................................................................................................................................................................ 32
10. Cleaning....................................................................................................................................................................................................................................................................... 32
11. Hourly production of the CRSG/CRI/CRIR......................................................................................................................................................................................................... 33 - 35
12. Identication .............................................................................................................................................................................................................................................................. 36 - 37
Notes................................................................................................................................................................................................................................................................................................................... 38 - 39
Certicate........................................................................................................................................................................................................................................................................... 40
Certicate of warranty........................................................................................................................................................................................................................................................................................ 40 - 46
CRSG / CRI / CRI-R - 4 5 - CRSG / CRI / CRI-R
Instruction Manual
01. SAFETY RULES
THIS ALERT SYMBOL INDICATES IMPORTANT SAFETY NOTES. WHENEVER YOU FIND IT IN THIS MANUAL, READ THE MESSAGE WITH ATTENTION TO AVOID
ANY ACCIDENT.
WARNING WARNING WARNING WARNING
• Read this instruction ma-
nual carefully to know the re-
commended safety rules.
• Only start the tractor opera-
tions, when are you properly
accommodated and with the
seat belt fasted.
• Never carry people over the
tractor or equipment.
• Há riscos de lesões graves
por tombamento ao traba-
lhar em terrenos inclinados.
• Não utilize velocidade ex-
cessiva.
Instruction Manual
5 - CRSG / CRI / CRI-R
01. SAFETY RULES
WARNING WARNING WARNING WARNING
• Before any equipment
maintenance, make sure that
is properly stopped.
• Avoid getting hit.
•Do not work with the tractor if
the front bee without enough
weight to the rear equipment.
•There is tendency to lift , add
weights at front or front wheels.
• Never weld the wheel mounted with
tire, the heat may cause air pressure
increase and provoke the explosion of
the tire
• When lling the tire, position yourself
besides the tire, never in front of it.
• Before beginning the work or
transportation of CRSG/CRI/CRI-R,
check if there are people or blocka-
ges close to it.
FALLOW ALL RECOMMENDATIONS, WARNINGS AND SAFE PRACTICES RECOMMENDED IN THIS MANUAL, UNDERSTAND THE IMPORTANCE OF YOUR SAFETY.
ACCIDENTS MAY LEAD TO DISABILITY OR INCLUDING DEATH. REMENBER, ACCIDENTS CAN BE AVOIDED!
CRSG / CRI / CRI-R - 6 7 - CRSG / CRI / CRI-R
Instruction Manual
01. SAFETY RULES
ALCOHOLIC BEVERAGE OR SOME MEDICATIONS MAY CAUSE LOSS OF REFLEXES AND CHANGE THE OPERATOR’S PHYSICAL CONDITIONS. FOR THIS REASON,
NEVER OPERATE THIS EQUIPAMENT UNDER ANY OF THESE SUBSTANCES.
WARNING WARNING WARNING
• Hydraulic oil works under pressure and may cause serious injuries if
there are any leakages. Periodically check the conservation status of
the hoses. If there are any sign of leakage, replace them immediately.
• Before connecting or disconnecting the hydraulic hoses, relief the
system pressure by activating the control with the tractor power swit-
ched o.
• Always keep yourself distant from the
active elements of the CRSG/CRI/CRi-R
(discs), they are sharp and may cause ac-
cidents.
• When performing any service in the dis-
cs, use safety gloves on the hands.
• Remove the ignition key before per-
formin any type of maintenance
in CRSG/CRI/CRI-R. Protect yoursef
against possible injuries or death by
CRSG/CRI/CRI-R unexpected start-up.
• Do not start the tractor up if CRSG/
CRI/CRi-R unexpected start-up.
Instruction Manual
7 - CRSG / CRI / CRI-R
The incorrect handling of the tractor engine can result in serious or fatal accidents. Before using the read carefully the instructions in this ma-
nual. Be sure that the person responsible for the operation is instructed about the correct handling and safety and has read and understood the
instruction manual concerning this machine.
WARNING
01- When operating the implement do not allow people to stand close or on the implement.
02- During assembly or disassembly of the discs section use protective gloves.
03- When coupling or uncoupling the hydraulic hose relieve the hydraulic circuit pressure.
04- Check out periodically the hoses condition. Where there is oil emptying change it immediately because the oil works under high pressure and
may cause serious damage.
05- Do not use large or daggy clothes because they can get caught on the implement.
06- When you start the tractor engine, be correctly placed at the operator seat and be aware of the correct and safety handling of both tractor and
implement. Always place the gearshift crank at the neutral position, turn o the gear of the power command and place the hydraulic commands at
the neutral position.
07- Do not turn on the tractor in a closed place without appropriate ventilation because the fumes from the fuel are is bad for health.
08- While maneuvering the tractor to clamp the implement be sure that there is enough space and nobody is too close, maneuver always in slow
gear and be ready to brake in case of emergency.
CRSG / CRI / CRI-R - 8 9 - CRSG / CRI / CRI-R
Instruction Manual
09- Do not carry out adjustments with the implement working.
10- When working over hilly areas try to keep the necessary stability. In case of instability reduce the acceleration, turn the wheels to the inclined
side of the land and never lift the implement.
11- Always use the tractor at safe speeds, especially when working in irregular or inclined areas, make sure the tractor is always in gear.
12- When using the tractor on the road, keep the brake pedal connected.
13- Do not work with the front tractor light. If there is a tendency to lift up add more weight in the front of the tractor at the front wheels.
14- When leaving the tractor, place the gearshift at the neutral position and apply the park brake. Never let clamped implements be hitched to the
tractor with the hydraulic system at the lifted position.
15- Drugs and alcohol will aect an operator’s alertness and coordination. Do not operate any engine under these conditions.
16- Explain the operation, inspection and maintenance instructions to those users or operators who can not read.
