OverViewOVL708

Fully redundant 70" XGA 4:3 LED video wall

Barco's OverView OVL series LEDlit video

walls are the first choice for 4:3

missioncritical control rooms that require a

guaranteeduptime.Themodules’highlevel

of redundancy, not only of the individual

LEDs, but also of the LEDs' power supplies

and even inputs, ensures nothing can go

wrong,givingusersthepeaceofmindthey

need. Featuring a structure that can be

tailoredtotherequirementsofthecustomer,

the OverView OVL series knows virtually no

limitsinsize.

Ultimatepeaceofmind

The OverView OVL708 video wall modules have been designed for an

entirelymaintenancefreeoperationoverseveralyears,withoutanyneedfor

consumables. Barco's unique liquid cooling system ensures lower LED

temperature, resulting in longer LED lifetime (>80,000 hours in eco mode).

Displaying the sharpest and most saturated colors in XGA resolution

(1024x768),theOverViewOVL708offersanergonomicallyexcellentviewing

experience. The availability of alternative screen types makes sure you can

adjust the video wall to your specific needs in terms of viewing angle and

brightness.

Alwaysthemostoptimalpicture

OverView OVL series video walls come with Sense6, Barco's unique sensor

technology that provides brightness and color stability over time and across

the entire display. Sense6 continuously measures brightness and color by

meansofahighqualityspectrometer,andadjuststhecolorspacetoprovide

an image that is most convenient for the human eye. This means that no

maintenanceormanualadjustmentsareneeded.

OverViewOVL708

Fully redundant 70" XGA 4:3 LED video wall

Thebrightnesschampion

TheOverViewOVLseriesisthebrightestLEDlitrearprojectionvideowallon

the market, and the first to cross the 1,000 lumens barrier. This further

expands the usability of video walls to control rooms where lighting

conditionsareparticularlychallenging.

Upgradeforexistingmodules

Thanks to the modular design of the projection engine, the OverView OVL

projectorcanalsobeusedtoupgradeexistingBarcorearprojectionmodules

oftheOverViewDseries.

Productspecifications OverViewOVL708

Resolution XGA(1024x768px)

Brightness onscreen:350cd/m²(FXS)

Onscreencontrast 1,200,000:1

Color Upto165%EBU

Displaytechnology rearprojectionDLP

Whitepoint 3,200K|6,500K|9,600K|arbitrary

Brightnessuniformity Typ95%ANSI13

Screen BB,FXS,HighGain

Screengap <0.2mm|0.008"stitched

<1.5mm|0.06"modular(@25°C)

<0.4mm|0.015"modular(@30°C)

Colorstability SelfcalibratingwithspectrometerbasedSense6

Dimensions •Diagonal:70"nominal

•Width:1,400mm/55.1"

•Heigth:1,050mm/41.3"

•Depth:899mm/35.4"

•Aspectratio:4:3

•Weight/module101.5kg/224lbs

Lightsource 3xsixfoldredundantLEDblock

Lightsourcelifetime >60,000h,>80,000h(eco)

Recommendedmaintenanceinterval >5yearsNoburnin,noimageretention

Conditionsforoperation 10°C40°C,50°F104°F,80%humidity(nc)

ACinputvoltage 90–240V,5060Hz

Power typical:230W,maximum:350W,ecomode:170W

Heatdissipation typical:785,maximum:1,195,ecomode:580BTU/h

Directethernetaccess Buildinwebserver

Graphicaluserinterface Allsettingsandoperationalparameters

Signalinput/output 2xDuallinkDVIin,2xDuallinkDVIout

SinglelinkDVIin,withHDCP(optional)

Pixelclock 320MHz

Inputfrequency 24–62Hz

Genlock 49–61Hz

Signalprocessing Loopthroughupto10cubes/Freecropping,freescaling

Integrationtothirdpartyequipment WebbasedAPI

Warranty 2years

Generatedon:17May2014

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
