Barco R812302K Bedienungsanleitung
BARCO PROJECTION SYSTEMS
Date :
170699
INSTALLATION MANUAL
KIT POLARISER BEAM SPLITTER FOR 6300
PROJECTORS
R812302K
Art. No. :
R5976048
Rev :
00
PBS
6300 Kit
Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, June 1999.
All rights reserved.
Trademarks are the rights of their respective owners.
BARCO n.v./Projection Systems
Noordlaan 5
B-8520 Kuurne
Belgium
Tel : +32/56/368211
Fax : +32/56/351651
Visite Barco at the web : http://www.barco.com
Printed in Belgium
BARCO 3 Projection Systems
Safety
Who This procedure is intended for use only by qualified ser ice technicians who ha e been
trained and authorized by BARCO !
Hot Surface Switch the projector to stand by and let it cool down for at least 15 minutes before
starting with the Analyser replacement.
Risk of Electrical
Shock
Power down the projector and unplug the power cord from the wall outlet.
Once the projector is cooled down and the power is off, continue with the replacement
procedure.
Antistatic
Protection Steps
Wear a wrist band which is connected to the ground while handling the static sensiti e
parts.
BARCO 4 Projection Systems
Contents of the Kit
Type The kit contains a PBS (Polarizing Beam Splitter). This PBS can only be mounted in
BARCOGRAPHICS 6300 projector.
Part Listing The kit contains one PBS :
R812302
R5976048
1
1
PBS
Manual inst PBS 6300
Part Number Description Indication
Antistatic
Protection Steps
Wear a wrist band which is connected to the ground while handling the static sensiti e
parts.
Illustration of the
Kit
BARCO 5 Projection Systems
Access to the Modules
What has to be
done
The lens has to be remo ed and the top co er has to be opened.
ecessary Tools Screwdri er 8 mm.
Removing the
Lens
To remo e the lens, follow the next procedure:
1
2
3
4
1
2
2
Open the lens co er by pi oting it backwards and hook it
of.
Loosen the fixation screws of the motor part and pi ote it
upwards.
Open both lens locks by pulling them backwards.
Take the lens out of the lens house.
Step Action Image
Illustrations on
Removing the
Lens
Image 2
Image 1
Lens lockings
Motor part
To be continued on next page.
ecessary Parts None
Fixation screws
BARCO 6 Projection Systems
Access to the Modules (Continued)
Removing the
Top Cover
1
2
3
1
2
Pull the 3 rubber sealing pieces.
Turn out the 3 fixing screws.
Take off the top co er.
Step Action Image
To remo e the top co er, follow the next procedure:
Illustrations on
Top Cover
Removal
Image 1
Image 2
BARCO 7 Projection Systems
Removing the Pixel Map Processor Module.
What has to be
done
The pixel map processor (PMP) has to be remo ed.
ecessary Tools Philips screwdri er
ecessary Parts None
To be continued on next page.
Electrical
Disconnection of
the PMP
Before remo ing the PMP, it must be electrically disconnected. Follow the next proce-
dure :
1
2
3
4
1
1
1
1 & 2
Pull out the 5 coax cables (A)
Pull out the white power cable connector (B).
Pull out the black connector (C) for the uniformity module.
Remo e both flat cables (D) by pressing ery carefully on
both sides of the indicated points to unlock.
Pull out the cable.
Step Action Image
Illustrations
Image 2Image 1
Press to lock
Press to unlock
Connector connector
cable
BARCO 8 Projection Systems
Removing the Pixel Map Processor Module (Continued)
Removing the
PMP
1
2
1
Turn out the indicated screws.
Take off the PMP.
If an SDI module is installed, unplug both coax cables
before taking off the PMP.
Step Action Image
To remo e the PMP, follow the next procedure:
Illustrations
Image 1
BARCO 9 Projection Systems
Mounting the extra feet.
What has to be
done
Three extra feet has to be mounted on upper side of the projector to turn the projector
upside down.
ecessary Tools 3 feet (a ailable in the toolkit 6300)
ecessary Parts None
Illustrations
Image 2
Image 1
Mounting the
Feet
To mount the feet, follow the next procedure :
1 1
Turn in the feet on the indicated positions.
The projector is ready to be turn upside down.
Step Action Image
BARCO 10 Projection Systems
Removing the Fan.
What has to be
done
The fan on the lightblock has to be remo ed before gaining access to the lightbock
co er.
ecessary Tools Nut dri er 5.5
Nut dri er 7
Screwdri er 4 mm
ecessary Parts None
Removing the
CSB module
To remo e the CSB module, follow the next procedure :
1
2
1
2
Turn out both indicated screws.
Pi ote the module backwards.
Step Action Image
Illustrations
Image 2
Image 1
Removing Fan To remo e the fan, follow the next procedure :
1
2
1
2
Turn out both indicated screws.
Slide out the fan
Step Action Image
Illustrations
Image 2
Image 1
