OPERATOR’S MANUAL
Issue Date: September 2021
S14 And S18 Stump Grinder
TABLE OF CONTENTS
1 INTRODUCTION................................................................................................................................... 1
1.1 Overview...................................................................................................................................... 1
1.2 Intended Use And Foreseeable Misuse .................................................................................... 2
2 SAFETY ................................................................................................................................................ 3
2.1 Safety Alert Symbol And Safety Words.................................................................................... 3
2.2 Operational Hazards................................................................................................................... 3
Prepare For Emergencies .......................................................................................................... 4
Replace Safety Signs ................................................................................................................. 5
Do Not Allow Riders ................................................................................................................... 5
Lower Operating Speed ............................................................................................................. 5
Avoid Rollover ............................................................................................................................ 5
Avoid Powerlines & Underground Utilities .............................................................................. 6
Detach Stump Grinder Safely.................................................................................................... 6
Hazards From Modifying Equipment ........................................................................................ 7
2.3 Maintenance Hazards................................................................................................................. 9
3 SAFETY SIGNS .................................................................................................................................. 10
3.1 Safety Signs - S14 ................................................................................................................... 10
3.2 Safety Signs - S18 .................................................................................................................... 12
4 OPERATION ....................................................................................................................................... 14
4.1 Preparation for Use .................................................................................................................. 14
4.2 Machine Components .............................................................................................................. 15
4.3 Attach To Skidsteer .................................................................................................................. 15
4.4 Detach From Skidsteer ............................................................................................................ 16
4.5 Transporting.............................................................................................................................. 16
4.6 Carbide Teeth Break-In............................................................................................................. 17
4.7 First Time User Tips ................................................................................................................. 17
4.8 Field Operation ......................................................................................................................... 18
5 SERVICE AND MAINTENANCE......................................................................................................... 20
5.1 Replace Cutting Teeth - S18 .................................................................................................... 20
5.2 Rotate Cutting Teeth - S14 ....................................................................................................... 21
5.3 Replace Cutting Teeth - S14 .................................................................................................... 21
5.4 Replace Tooth Holder - S14 ..................................................................................................... 22
5.5 Replace Coupler - S14.............................................................................................................. 22
5.6 Replace Coupler - S18.............................................................................................................. 23
5.7 Maintenance.............................................................................................................................. 23
6 TROUBLESHOOTING........................................................................................................................ 24
7 WARRANTY........................................................................................................................................ 25
ii
1 INTRODUCTION
Congratulations on your choice of a Baumalight
Skidsteer Stump Grinder to complement your
stump grinding operation. This equipment has
been designed and manufactured to meet the
needs of a discriminating buyer for efcient
grinding of stumps.
This new and unique design allows us to build it
very economically and makes it a very compact
unit for storage and transport. The self feeding
design of the frame and enhanced visibility
make the stump grinder easy and efcient to
operate. Hydraulic controls are easy to adjust
and operate from most skidsteer loaders.
The debris shield is standard equipment on
all stump grinders. It is recommended that the
stump grinder never be operated with out one.
Safe, efcient and trouble free operation of your
Stump Grinder requires that you and anyone
else who will be operating or maintaining the
Stump Grinder, read and understand the Safety,
Operation, Maintenance and Troubleshooting
information contained within the Operator’s
Manual.
This manual covers the S14 and S18
Baumalight Skidsteer Stump Grinders. Use the
Table of Contents as a guide to locate required
information.
Keep this manual handy for frequent reference
and to pass on to new operators or owners.
Call your Baumalight dealer, distributor or the
factory if you need assistance, information or
additional copies of the manuals.
OPERATOR ORIENTATION - The directions
left, right, front and rear, as mentioned
throughout this manual, are as seen from
the skidsteer driver’s seat and facing in the
direction of travel.
1.1 Overview
1
The stump grinder is designed to be used by
experienced operators, trained in the safe
operation of a tractor and trained in the hazards
related to using the stump grinder and the safe use
of the grinder for the intended purpose. Operators
will require personal protective equipment to
reduce the risk from some hazards that cannot be
completely eliminated or controlled by the design
of the tool.
Care is required to ensure that the stump grinder
tool will not come across metallic objects, stones
or other materials.
Stump grinder tools are not designed for use in
hazardous atmospheres where there is a risk
of re or explosion due to ammable gases or
vapors. Use in hazardous, explosive atmospheres
is prohibited.
Serious injury or death of the operator or bystanders
may be caused if the tool is misused. Misuse may
also cause damage to the machine carrying the
implement.
1.2 Intended Use And Foreseeable
Misuse
2
2 SAFETY
You must read, understand and follow the
instructions given by the operating unit
manufacturers, as well as the instructions in this
manual.
The safety information in this manual is denoted
by the safety alert symbol:
^
This symbol means ATTENTION! BECOME
ALERT! YOUR SAFETY IS INVOLVED!
The level of risk is indicated by the following signal
words:
^^ DANGER
DANGER - Indicates a hazardous
situation, which, if not avoided, WILL
result in death or serious injury.
^ WARNING
WARNING - Indicates a hazardous
situation, which, if not avoided, could
result in death or serious injury.
^ CAUTION
CAUTION - Indicates a hazardous
situation, which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE - Indicates a situation that could
result in damage to the equipment or
other property.
2.2 Operational Hazards
^ WARNING
Prevent serious injury or death.
Read and understand this manual before
operating stump grinder.
Always stop engine and remove key
before leaving operators seat.
Never allow anyone near the stump
grinder during operation.
Travel at a safe speed.
^ WARNING
Prevent serious injury or death from
moving parts.
Moving parts can crush and dismember.
Do not operate without guards and
shields in place.
Disconnect and lockout power source
before adjusting or servicing.
^ WARNING
Use stump grinder only for the designed
applications.
Any other use may result in personal
injury, damage to equipment and may
void the warranty.
2.1 Safety Alert Symbol And Safety
Words
3
^ WARNING
Prevent serious injury or death.
Verify stump grinder is locked to
quick attach hitch before operation or
transport.
^ WARNING
Protect from ying debris.
Wear proper safety glasses, goggles,
or a face shield to protect from ying
debris.
Carefully read all safety messages in this manual
and on equipment safety signs. Keep safety signs
in good condition and replace missing or damaged
safety signs.
New equipment components and repair parts must
include the current safety decal.
Learn how to properly operate equipment.
NEVER operate or work around this equipment
without proper instruction, while fatigued or under
the inuence of alcohol, prescription or non-
prescription medication or if feeling ill.
Keep your equipment in proper working condition.
Know the regulations and laws that apply to you
and your industry. This manual is not to replace
any regulations or laws. Additional information
may be found at: www.asae.org or www.osha.gov.
If you do not understand any part of this manual,
contact Baumalight at 866-820-7603.
Prepare For Emergencies
• Be prepared in case of emergencies.
• Keep a re extinguisher and rst aid kit close
to the machine.
• Keep emergency phone numbers close to your
phone.
• Know your address so emergency services
can locate you if an emergency arises.
4
Replace Safety Signs
• Replace missing or damaged safety signs.
• Safety signs are identied in Section 3 of this
manual.
• Replacement safety signs are available from
your Baumalight dealer.
Do Not Allow Riders
• NEVER lift or carry anyone with stump grinder.
• NEVER use stump grinder as a work platform.
• NEVER allow passengers on stump grinder.
Lower Operating Speed
• Lower operating speed while loading, unloading
or performing heavy operations.
• Keep load low and move at slow speeds on
rough or uneven terrain.
Avoid Rollover
The equipment may rollover, resulting in death or
serious injury. To help prevent rollover:
• Travel at a slow speed.
• Avoid sharp turns & sudden movement on
slopes.
• Carry loads close to the ground.
• Avoid holes, ditches and other obstructions
which may cause equipment to rollover.
• Balance load so weight is evenly distributed
and load is stable.
• Use caution when operating on slopes and do
not operate on excessively steep slopes.
• Do not exceed load capacity of equipment.
5
Avoid Powerlines & Underground
Utilities
• Check clearance before raising equipment.
• Have local utilities locate and mark under
ground wires, cables, pipelines and other
hazards before grinding.
^ DANGER
Prevent electrocution.
Death or serious injury can result if
equipment comes near or contacts
power lines.
Electrocution can occur without direct
contact.
DO NOT leave the operator’s seat if any part of the
equipment contacts electric lines or cables.
Detach Stump Grinder Safely
Detach stump grinder on a rm and level surface.
Stump grinder may fall over if detached on unlevel
or soft surface. Be sure people, livestock and pets
are clear of machinery.
Relieve hydraulic pressure before disconnecting
hydraulic hoses.
6
Raised Attachment
^ WARNING
Crushing hazard.
Raised, unsupported stump grinder can
fall, resulting in death or serious injury.
Never enter the area under a raised
stump grinder.
A raised stump grinder can lower unexpectedly,
resulting in death or serious injury.
NEVER enter area under a raised stump grinder
unless stump grinder is properly and safely
supported.
Lower stump grinder to ground, engage parking
brake, shut off engine and remove key before
servicing.
Hazards From Modifying Equipment
Do not make any alterations to your stump grinder.
Altering may cause your equipment to be unsafe
and may void the manufacturers’ warranty.
Avoid High Pressure Fluids
^ WARNING
Pressurized uids can penetrate the
skin.
Hydraulic hoses can fail from age,
damage and exposure.
Use body and face protection while
searching for leaks. A tiny, almost
invisible leak can penetrate the skin,
thereby requiring immediate medical
attention.
Use wood or cardboard to detect
hydraulic leaks, never use your hands.
Escaping uid under pressure can penetrate the
skin causing serious injury.
Prevent the hazard by relieving pressure before
connecting or disconnecting hydraulic lines. Verify
all connections are tight before applying pressure.
Search for leaks with a piece of cardboard or wood.
Protect hands and body from high pressure uids.
If an accident occurs, get immediate medical
attention.
7
Avoid Wood Dust Inhalation
^WARNING
Drilling, sawing, sanding or machining
wood products can expose you to wood
dust, a substance known to the State of
California to cause cancer.
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection. For more information go to
www.P65Warnings.ca.gov/wood.
^WARNING
Wear an approved dust mask or
respirator.
Follow local, state and federal
regulations.
Avoid Loud Noise
^ WARNING
Prolonged exposure to loud noise can
cause impairment or loss of hearing.
Wear a suitable hearing protective device
such as earmuffs or earplugs to protect
against objectionable or uncomfortable
loud noises.
8
Andere Handbücher für S14
1
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Baumalight Schleifer Handbücher
Baumalight
Baumalight S40 Bedienungsanleitung
Baumalight
Baumalight STUMP BLASTER 3P34 Bedienungsanleitung
Baumalight
Baumalight WLWB44 Bedienungsanleitung
Baumalight
Baumalight STUMP BLASTER 3P24 Bedienungsanleitung
Baumalight
Baumalight STUMP BLASTER S24 Bedienungsanleitung
Baumalight
Baumalight HGW30 Bedienungsanleitung
Baumalight
Baumalight GXM350 Bedienungsanleitung
Baumalight
Baumalight S16 Bedienungsanleitung
Baumalight
Baumalight WB44 Bedienungsanleitung
Baumalight
Baumalight STUMP BLASTER S24 Bedienungsanleitung
