Please note- this Instruction Manual contains important safety information. Please

make sure that you read it before using your Washing Machine for the first time. It also

contains valuable Troubleshooting tips so that you can solve faults without having to call

for a service engineer.

Instruction Manual for your Baumatic

BWD12

FULLY INTEGRATED FULL HEIGHT

WASHING MACHINE

28/07/05

Please note: for fast access to using your

Washing Machine, please look at the bold-font

items listed on the Contents page (page 2).

CONTENTS

Specifications ……….…………….……………………..………………. 3

Important Safety Information……….…..………..…..…………………..4

Your Washing Machine’s Control Panel…...……..….....……………5-6

Cautions and Advice ………….…………..……....…………………….…7

Using your BWD12.…………...…………………….….……..…………….8

Before Loading your Washing Machine ………….…………..….……..9

Tips for Loading Laundry / Guide to Washing Labels ..………..…..10

Filling your Washing Machine’s Dispenser

Drawer with Detergent …………………………………..……………11-12

Tips on Washing your Clothes / Running your Washing Machine

……………………………………………………….…………………....13-18

The Program Knob ….………………………………14

Selecting a Washing Program ………………..…...15

Washing Temperature Knob ………………………16

Starting a Washing Program ………………..…..…16

Interrupting a Program ……………………..……....17

Additional Functions Buttons ………………….17-18

WASHING PROGRAMME CHART …………………………..…….19-20

At the End of a Wash Programme …………….…..….………………21

YOUR DRYER / USING YOUR DRYER…………………………….21-23

Maintenance and Cleaning …………………....……………………24-26

Notes on Stains and How to Remove them

from your Clothes ........................................................................27-28

TROUBLESHOOTING ……………………………..……………….….29-31

INSTALLATION INSTRUCTIONS …………………..………………..32-38

ADJUSTING THE FEET ………..………….......................……………..39

ELECTRICAL CONNECTION ………………..…………………………..39

WATER CONNECTION ……………..………………………………...39-40

Directive Conformity Confirmation ..…………………………………..41

Conditions of Guarantee……………………..….………………............42

Contact Details…………………………..….…………………………...…43

2 washing programmes

Wash load: 4.5 kg

Maximum spin speed: 1200 rpm

(

)

:1) On / Off

2) No Spin 3) ½ Spin 4) Spin

Speed select (500 or 1200 rpm)

IMPORTANT SAFETY INFORMATION:

WARNING: THIS IS IMPORTANT SAFETY INFORMATION. PLEASE

READ THIS BEFORE USING YOUR WASHING MACHINE.

:DO NOT USE AN EXTENSION CORD OR PLUG INTO A MULTIPLE

SOCKET.

:DO NOT INSERT A PLUG WITH A DAMAGED CORD OR THAT IS

BROKEN INTO THE SOCKET.

:IF THE CORD IS DAMAGED IT SHOULD BE REPLACED BY THE

MANUFACTURER OR APPOINTED SERVICE AGENT.

:NEVER REMOVE THE PLUG FROM THE SOCKET BY PULLING FROM

THE CORD SECTION. HOLD THE PLUG AS YOU PULL IT OUT.

:DO NOT PLUG INTO THE POWER SUPPLY IF YOUR HANDS ARE WET.

:DO NOT TOUCH THE MACHINE WITH WET HANDS OR FEET.

:DO NOT OPEN THE DETERGENT DRAWER WHILE THE DEVICE IS

RUNNING.

:DO NOT FORCE OPEN THE DOOR OF THE MACHINE WHILE THE

MACHINE IS RUNNING.

:DO NOT TOUCH THE DRAIN HOSE AND WATER DURING DRAINING –

THE WASHING MACHINE CAN REACH HIGH TEMPERATURES DURING

DRAINING.

:DO NOT ATTEMPT TO REPAIR. PLEASE APPLY TO THE NEAREST

AUTHORISED SERVICER.

:DO NOT FORGET THAT THE PACKING MATERIAL OF YOUR MACHINE

MAY BE HAZARDOUS FOR CHILDREN.

:NEVER LET YOUR CHILDREN PLAY WITH YOUR WASHING MACHINE.

:KEEP PETS AWAY FROM YOUR WASHING MACHINE.

:ONLY USE YOUR WASHING MACHINE IN THE HOME. THE WARRANTY

WILL BE INVALID SHOULD YOU USE IT FOR COMMERCIAL

PURPOSES.

:ALWAYS SWITCH OFF THE POWER AFTER USING YOUR APPLIANCE.

:ENSURE THAT YOU REMOVE AND CLEAN THE FILTER.

:THE OUTLET HOSE MUST BE FREE OF RESTRICTIONS.

:THE WATER PRESSURE MUST NOT BE ANY MORE THAN 1 MPa

AND NOT LESS THAN 0.05 MPa.

:DO NOT OVERLOAD THE DRUM.

Your BWD12’s Control Panel

Key to above figure:

1 – Programme Selector (see page 14 for details on use).

Turn this knob to select a Washing programme AND / OR to select

a Drying programme, depending on the dirtiness of your laundry.

To set the programme, first ensure that machine is OFF (i.e., the

position of the ON/OFF button is out) and turn the knob clockwise

until the needle points to the mark matching the programme you

want to use. A CONTINUOUS wash/dry programme can be set

using this knob (see pages 22-23).

2- Drying Timer (see page 23 for details on use).

This knob adjusts the time of your drying programme for up to

140 minutes. NOTE : The Dryer can only be used when the

half load - - button is pressed and the heat setting is

selected.

3 – Temperature Selector to be used in conjunction with the

Washing programme selector (see page 16 for details on use).

This knob adjusts the temperature of your wash or drying

cycles. Always check the labels of your clothes before grouping

them for a wash load.

4 – Additional option buttons ON/OFF button, and pilot lamp

(see pages 17-18 for details on use).

This selection of buttons allows you to choose options for your

washing cycle, and to turn your appliance ON and OFF. The

pilot lamp will show you when your machine is operating.

5 – Soap Dispenser Drawer (see pages 11-12 for details on

use).

Pull this out to load the soap into your machine, ready for a

washing cycle.

Cautions and advice

In order to get maximum satisfaction and performance from your washing machine,

please ensure you follow the instructions given below:

9Select the clothes load correctly and choose the appropriate

programme.

9Before opening the door, check that there is no water in the

machine and the pilot light is off.

9Put the washing products in the right proportion and in the right

compartment.

9Small garments, such as socks, belts, etc. are best put inside a

bag to avoid their being lost.

9Before putting clothes into the washing machine, make sure that

there is nothing in the pockets (coins, buttons, clips, etc.) and that

the zips are undone.

9If you machine has a filter, you should check regularly that

it is clean & not blocked. Be especially wary of coins,

brassiere wire & fluff/hair.

9The interior of the washing machine should be handled by

specialists only. NEVER attempt to repair or modify it

yourself.

9After each wash, leave the door ajar to prevent the rubber seal

from becoming misshapen or mouldy.

9When the clothes to be washed are heavily soiled or splattered

with mud, it is advisable to run a programme with pre-wash.

9Always put the machine on fully loaded. This will conserve energy.

9Do NOT use the dryer function if the clothes have been treated

with any non-aqueous solution.

9Do NOT use the dryer function for items containing any kind of

spongy rubber or similar elastomer materials.

9The dryer must be installed in a well-ventilated place, away from

the influence of gases from other appliances and from defective

installations.

9The lower ventilation, between the floor and the base of the

machine must not be obstructed (by carpet, cloths, etc.).

9When the machine has just been installed, or after a long time

without it being used, it is advisable to run a washing programme

with the machine empty, to eliminate any rusty water in the tubes.

Using your BWD12

NOTE: (*VERY IMPORTANT*) – You must

ensure that the transportation bolts

have been removed before you attempt

to use your Washing Machine,

OTHERWISE you will damage or

destroy your appliance. See page 32

for instructions.

Only once you are sure this has been done can you do

the following:

1) Plug in your machine

2) Turn on the water supply

Note on using your

Washing Machine

for the first time:

There may be water

left inside your

machine after factory

tests and trials.

•The first time you run a

wash cycle, you should not

put laundry in your machine

as it may need to drain water.

•Pour half a measuring cup of

normal or all purpose detergent

into compartment 2 ( ) in your

detergent dispenser and select

wash programme 2 (without

prewash) for 90

•Start the programme.

•Wait until the programme finishes.

*FOR NORMAL USE, SEE NEXT PAGE

Before Loading your

Washing Machine

NOTE: Before putting the clothes into the machine:

oSeparate the clothes into 3 lots (cotton,

synthetics and wool).

9Within each group, separate the coloureds from

the whites. *NOTE – see next page for tips.

9Once the clothes have been separated, you can

put them into the drum of the washing machine,

separately and according to colour and group,

loose, piece by piece. Do not exceed the

maximum weight of clothes as given below:

Cotton Maximum: 4.5 kg

HOW TO

OPEN THE

DOOR

Pressing the hidden

lever (1) with the

index and middle

fingers, pull

outwards.

oLoad your clothes inside the drum one item at a

time and spread them about well.

oShut the door of your machine, being careful

that no pieces of clothing are jammed between

the door and the gasket seal. Make sure the door

is closed tightly otherwise it won’t work.
