Baumatic BWMI1206.1 Bedienungsanleitung

wan

BWMI1206.1

BWMI1407.1

Fully integrated

washing machine

USER MANUAL FOR YOUR BAUMATIC

BWMI1206.1

BWMI1407.1

Fully integrated

washing machine

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference.

GS 30/01/12

Contents

Environmental note 4

Important safety information 5 - 6

Specifications 7-8

Product and aperture dimensions 7

Product specifications 7 - 8

Control panel 9 - 14

Detergent drawer 13 - 14

Preparing the wash cycle 14 - 20

Preparing your garments for washing 14 - 15

A selection of wash care symbols 15

Detergents and conditioners 15 - 16

Program table 17 - 18

Program description 18 - 20

Wash program guidance 20

Selecting a wash program 21 - 25

Cancelling or pausing a wash program 21 - 22

Delaystartfeature 22

Saving energy when using your washing machine 22 - 23

Automatic consumption reduction 23

Removingstains 23

Stain removal rules 23 - 24

Stain removal guide 24 - 25

Maintenance and cleaning 25 - 28

Indailyuse 25

Control panel and washing machine cabinet 25

Detergent drawer 26

The washing machine drum 26

Door 26

90 degree maintenance wash 27

Cleaning the filter 27

Long periods of not in use 28

General troubleshooting 28 - 29

Poorwashresults 30

Installation 31 - 38

Unpacking and removing the transit bolts 31 - 32

Positioning and levelling the appliance 32 - 33

Fitting the décor door 33 - 35

Connecting to the mains water supply 35

Wateroutlet 36

Powersupply 37

Before first use maintenance wash 37 - 38

Baumatic consumables 39

Technicaldata 40 - 41

Contactdetails 42

Environmental note

Note

: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Advice Line.

General Safety

oRepairs to your appliance must only be carried out by a

Baumatic engineer or one of its authorised service agents. Any

attempt by an inexperienced person to repair the appliance,

could result in injury or damage to your washing machine.

oIf you notice that the mains cable is damaged. The appliance

must not be used. The same applies if you notice that the

worktop, control panel or base area is damaged. As this could

allow access to the internal components of the machine.

oThe appliance should be switched off and isolated from the

mains supply, before either cleaning or maintenance work is

attempted.

oThe mains cable must not be used to pull the plug out of the

electrical socket.

oThe machine should not be sprayed with water.

oThe glass of the porthole door may become hot during the higher

temperature wash programs.

oThe machine should be allowed to cool before carrying out an

emergency drain or cleaning the drain filter.

oIt is possible for small animals to chew either mains cables or

water hoses, which could cause an electric shock hazard.

Installation

oThe installation instructions contained within this user manual

should be followed.

oIt is obligatory for the completed installation to comply with all

relevant building regulations and local water authority

requirements.

oBefore the first use of the appliance, we advise that a

90°C cotton wash is completed. No garments should be

placed inside the machine; however a small amount of

detergent must be used.

During Use

oIt is recommended that the appliance is unplugged and the

water supply is switched off after the machine is used.

oThis appliance is only designed to wash normal domestic

washloads. If you use your washing machine in any other way or

it is incorrectly used, then Baumatic accepts no liability for any

damage that might be caused and any guarantee will be void.

oNo attempt should be made to alter or modify the specifications

of this appliance.

oThe detergents that you place in this appliance should be

suitable for automatic washing machines. With regards to dosage

levels, the detergent manufacturer’s recommendations should be

followed.

oYou should not wash garments that have been in contact with

flammable materials.

oYour washing machine should not be used for dry cleaning.

oIf you use either dyes or bleaching agents inside this machine,

then you should consult with the manufacturer of these products

to make sure they are suitable for use in your washing machine.

Baumatic cannot be held responsible for any damage that may

result.

Child Safety

oYour washing machine should only be used by adults. You should

not allow children in the area of the machine unsupervised. You

should not let them touch the controls or play with the appliance.

oIt could be possible for a child or pet to gain access to the

washing machine through the porthole door. Therefore please

check the drum before using the appliance.

oAny packaging that is removed from the machine should be kept

away from children.

oAll detergents should be kept out of children’s reach in a safe

place.

Specifications

Product dimensions:

Height: 820 mm

Width: 596 mm

Depth: 541 mm

Aperture dimensions:

825 mm

600 mm

570 mm

Product specifications

BWMI1206.1 BWMI1407.1

oLoad capacity: 6 kg 7 kg

oMaximum spin speed: 1200 rpm 1400 rpm

oDrum size: 46 litres 56 litres

o15 wash programs

o3 option buttons: Easy Iron, Extra Rinse and Cold Wash

oVariable spin speed with no spin option

oPorthole diameter: 30 mm

o180° door opening

oLED display

oDigital countdown indicator

oDelay start

oAutomatic consumption reduction

oSelf-adjusting water level to load

oImbalance control system

oOverflow protection

oFoam protection

oSafety lock

oFuzzy logic

oAdjustable feet

Energy efficiency:

Energyrating A+

Washperformance A

Water extraction performance class B (BWMI1206.1)

A (BWMI1407.1)

Control panel

A) Door open button

B) Door lock indicator light

C) Start/Pause button

D) Delay start button

E) Easy iron button

F) Extra rinse button

G) Cold wash button

H) Spin speed button

I) Spin speed indicator

J) Remaining time indicator

K) Program selection dial

L) Cycle option indicators

M) Detergent drawer

Door open button

Press this button to open the porthole door. A

safety device prevents the door from being

opened immediately after the end of the cycle.

You should wait for 2 minutes after the wash

cycle has finished and the door lock indicator

light has gone out before opening the door.

Door lock indicator light

The door lock indicator will light when the door is fully

closed and the machine is switched on. When the

Start/Pause button is pressed to start a wash cycle,

the indicator will flash for a few seconds and then light. If the door

is not closed the indicator will continue to flash. The door

cannot be opened until the door lock indicator has gone out.

Start/Pause button

This button should be used to start the chosen wash

program. When the button is pressed, the appliance

will begin the cycle within a few seconds. You can also

press this button to pause a wash cycle in progress

and continue after. When a program is selected,

wait for the STOP light to flash before pressing

the Start / Pause button.

Delay start button

This button can be used to program a delay start of 3, 6

or 9 hours. See the section “Delay start feature” on page

22 for instructions.

Easy iron button

Use this button to select the easy iron function. This will

minimise creases in mixed fabrics, delicate fabrics and

woollens and silk. It works in the following ways:

Fabric

(according to

program

selected)

Process

Mixed fabrics The water is gradually cooled throughout the final

2 rinses with no spinning and then a delicate spin

assures the maximum relaxation of the fabrics.

Delicate fabrics The final 2 rinses are carried out with no spinning

and then the fabrics are left in water until it is

time to unload. When you are ready to unload,

press the easy iron button to drain.

Woollens / silk After the final rinse the fabrics are left in water

until it is time to unload. When you are ready to

unload, press the easy iron button to drain and

spin.
