Baumatic BWM1216W Bedienungsanleitung

BWM1216W 60 cm 6

kg Freestanding

washin

Machine

USER MANUAL FOR YOUR BAUMATIC

BWM1216W

60 cm 6 kg

Freestanding

washing machine

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 03/09/10

Contents

Environmental note 4

Important safety information 5 – 6

Specifications 7

Description of the appliance 8

Controlpanel 9

LCDdisplay 10

Detergentdrawer 11

Preparing the wash cycle 11-14

Preparing your garments for washing 11-12

A selection of wash care symbols 13

Detergents and conditioners 13-14

Wash program table 14-15

Wash program guidance 15

Selecting a wash program 15-19

Descriptions of the wash programs 15 – 22

Childlock 19

Maintenance and cleaning 19-26

Indailyuse 19

Control panel and washing machine cabinet 20

Detergentdrawer 20

The washing machine drum 20-21

Door 21

Cleaning the drain pump filter 21

Cleaning the water inlet filter 22

Winterstorage 22

Removingstains 23

Stainremovalrules 23

Stain removal guide 23-24

Poor wash results 25-26

Installation 26-31

Removing the transit bolts 26

Locating your washing machine 27

Connecting to the mains water supply 28-29

Connecting to the water outlet 29

Levelling the appliance 30

Powersupply 30-31

Before first use maintenance wash 31

Error code failure system 31–32

General troubleshooting 32-34

Contact details 35

Environmental note

Important safety information

Your safety is of the utmost importance to

Baumatic. Please make sure that you read this

instruction booklet before attempting to install or

use the appliance. If you are unsure of any of the

information contained in this booklet, please

contact the Baumatic Advice Line.

General Safety

oRepairs to your appliance must only be carried out by a

Baumatic engineer or one of its authorised service agents. Any

attempt by an inexperienced person to repair the appliance,

could result in injury or damage to your washing machine.

oIf you notice that the mains cable is damaged. The appliance

must not be used. The same applies if you notice that the

worktop, control panel or base area is damaged. As this could

allow access to the internal components of the machine.

oThe appliance should be turned off and isolated from the mains

supply, before either cleaning or maintenance work is attempted.

oThe mains cable must not be used to pull the plug out of the

electrical socket.

oThe machine should not be sprayed with water.

oThe glass of the porthole door may become hot during the higher

temperature wash programs.

oThe machine should be allowed to cool before carrying out an

emergency drain or cleaning the drain filter.

oIt is possible for small animals to chew either the mains cable or

water hoses, which could cause an electric shock hazard.

Installation

oThe installation instructions contained within this user manual

should be followed.

oIt is obligatory for the completed installation to comply with all

relevant building regulations and local water authority

requirements.

oBefore the first use of the appliance, we advise that a 95

degree cotton wash is completed. No garments should be

placed inside the machine; however a small amount of

detergent must be used.

During Use

oIt is recommended that the appliance is unplugged and the

water supply is turned off after the machine is used.

oThis appliance is only designed to wash normal domestic wash

loads. If you use your washing machine in any other way or it is

incorrectly used, then Baumatic accepts no liability for any

damage that might be caused and any guarantee will be void.

oNo attempt should be made to alter or modify the specifications

of this appliance.

oThe detergents that you place in this appliance should be

suitable for automatic washing machines. With regards to dosage

levels, the detergent manufacturer’s recommendations should be

followed.

oYou should not wash garments that have been in contact with

flammable materials.

oYour washing machine should not be used for dry cleaning.

oIf you use either dyes or bleaching agents inside this machine,

then you should consult with the manufacturer of these products

to make sure they are suitable for use in your washing machine.

Baumatic cannot be held responsible for any damage that may

result.

Child Safety

oYour washing machine should only be used by adults. You should

not allow children in the area of the machine unsupervised. You

should not let them touch the controls or play with the appliance.

oIt could be possible for a child or pet to gain access to the

washing machine through the porthole door. Therefore please

check the drum before using the appliance.

oAny packaging that is removed from the machine should be kept

away from children.

oAll detergents should be kept out of a child’s reach and in a safe

place.

Specifications

o14 wash programs

o6 kg wash load

o1200 rpm maximum spin speed

oLED display

oElectronic control operation

oDelay start

oDigital countdown indicator

oDoor locked indicator

o300 mm porthole

o45 litre drum size

oFailure detection system

oImbalance control system

oOverflow protection

oFoam protection

oAnti-crease function

oAdjustable feet

oSafety door lock

Appliance dimensions

Height: 850 mm

Width: 595 mm

Depth: 495 mm

Ratings

Energyefficiencyclass A

Wash performance class A

Water extraction performance class B

For future reference please record the following information which can

be found on the rating plate and the date of purchase which can be

found on your sales invoice. The rating plate for your washing machine

will either be located on the right hand side of the cabinet or behind

the porthole door.

Model Number ……………………………….

Serial Number ……………………………….

Date of Purchase ……………………………….

Description of the appliance

Detergent

compartment Control panel

Door handle

Basket

Service panel

Filter door

Accessories

Control panel

1) Washing program selection dial. Use this dial to select the

required washing program.

2) Start / pause button. Press this button to start or pause a

washing cycle.

3) Water level selection button. Press this button to select the

required water level according to the amount of laundry from

the following options:

High

Mid

Low

Tiny

4) Temperature selection button. Press this button to set the

temperature of the water for a washing program from the

following options:

95°C

60°C

40°C

30°C

5) Spin speed selection button. Press this button to select the

spin speed for the chosen washing program from the following

options:

1200

900

600

No Spin

6) Delay start button. Press this button to delay the start of the

washing cycle. Repeatedly press the button to choose a time

between 0-24 hours.

7) Function button. Press this button to choose from two

additional functions for your washing cycle. You can add an

extra rinse or a pre-wash to get a better washing result.

8) Add garment button. Press this button to add more clothes

during a washing cycle. The cycle will pause and the door will

unlock. Press the start / pause button after adding the extra

clothes and closing the door to continue the cycle.

LCD display

Wash cycle progress indicator. The current wash cycle phase will

light on the display to indicate the progress of the program from “Pre-

Wash”, “Wash”, “Rinse” and “Spin”.

Delay start. The “Delay” icon will flash to indicate the delay time

which has been set. The program will begin after the set delay time.

Remain indicator. After the washing cycle has begun, “Remain” will

light and the remaining time will be displayed until the wash program

ends.

Child locked. When the child-lock function is activated this icon will

light. The light will go off when the lock is deactivated.

Door locked. When the door is in the lock state, this icon will light.

The door can be opened only after the light turns off.
