Technical Specifications

Version 1.0 February 2003

POWERPLAY PRO-8 HA8000

ENGLISH

VERSION 1.2February 2003

HA8000

POWERPLAY PRO-8 HA8000

POWERPLAY PRO-8

8-CHANNEL HIGH-POWER HEADPHONES DISTRIBUTION AMPLIFIER

Professional multi-purpose headphones ampliﬁer system for stage and studio applications=

Eight totally independent stereo high-power ampliﬁer sections in one rack space=

Two stereo Main inputs for two independent mixes, accessible from all eight channels=

Eight independent Direct inputs provide up to eight individual stereo mixes=

Highest sonic quality with virtually all types of headphones even at maximum volume=

Output level control and accurate 8-digit LED output meter per channel=

Mono/stereo switch per channel for more ﬂexibility=

One front and one rear 1/4” TRS phones connector for each channel=

Direct input connector on each channel for easy connection of any sound source=

Paralleled outputs allow cascading of several headphones ampliﬁers=

Toroidal transformer for noiseless operation and low magnetic interference=

High-quality components and exceptionally rugged construction ensure long life=

Conceived and designed by BEHRINGER Germany=

POWERPLAY PRO-8 HA8000

SPECIFICATIONS

AUDIO INPUTS

MAIN IN HF-filtered, servo-balanced

1/4" TRS connectors

Inp t impedance 40 kΩ balanced,

20 kΩ nbalanced

Max. inp t level +16 dB balanced and

nbalanced

CMRR typically 40 dB, >55 dB @ 1 kHz

DIRECT IN 1/4" TRS connector (stereo)

Inp t impedance 15 kΩ

AUDIO OUTPUTS

PHONES OUTPUTS 1/4" TRS connector (stereo)

POWER AMPLIFIER

Max. o tp t power +24 dBm (load impedance 100 Ω)

Min. o tp t load impedance 100 Ω

SYSTEM SPECIFICATIONS

Freq ency response 10 Hz to 150 kHz, +/-3 dB

Noise 22 Hz to 22 kHz >90 dB @ 0 dB

Dynamic range 22 Hz to 22 kHz: 110 dB

Distortion (THD) 0.006 % typ. @ +4 dB , 1 kHz,

Gain 1

FUNCTION CONTROLS

Inp t Level variable

O tp t Level per channel variable

FUNCTION SWITCHES

Main In 1/Main In 2 switches between Main Inp t 1

and Main Inp t 2

Mono switches this section to mono

DISPLAYS

Inp t level 4-digit LED-display:

-30/-12/0 dB/CLIP

O tp t level 8-digit LED-display:

-30/-24/-18/-12/-6/-3/0 dB/CLIP

POWER SUPPLY

Mains voltage

USA/Canada 120 V~, 60 Hz

E rope/U.K./A stralia 230 V~, 50 Hz

Japan 100 V~, 50 - 60 Hz

General export model 120/230 V~, 50 - 60 Hz

Power cons mption 30 W

F ses 100 - 120 V ~: T 630 mA H

200 - 240 V ~: T 315 mA H

Mains connection standard IEC receptacle

DIMENSIONS AND WEIGHT

Dimensions (H x W x D) approx. 1 ¾" (44.5 mm) * 19"

(482.6 mm) * 8 ½" (217 mm)

Weight approx. 5.19 lbs. (2.35 kg)

BEHRINGER is constantly striving to maintain the highest

professional standards. As a res lt of these efforts, modifications

may be made from time to time to existing prod cts witho t prior

notice. Specifications and appearance may differ from those

listed or ill strated.

POWERPLAY PRO-8 HA8000

The information contained in this p blication is s bject to change witho t notice. No part of this p blication may be reprod ced or

transmitted in any form or by any means, electronic or mechanical, incl ding photocopying and recording of any kind, for any

p rpose, witho t the express written permission of BEHRINGER Spezielle St diotechnik GmbH.

BEHRINGER Spezielle St diotechnik GmbH, Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany

Tel. +49 (0) 21 54 / 92 06-0, Fax +49 (0) 21 54 / 92 06-30
