Belkin F8T008 Bedienungsanleitung

Bluetooth™ USB Adapter

F8T008 - F8T009

Connect your peripherals and computing devices, without cables

Connectez vos périphériques et appareils informatiques sans utiliser de câble

Verbindet Ihre Peripherie- und Computergeräte – ganz ohne Kabel

Verbind uw randapparatuur en computers met elkaar, zonder kabels

Conecte sus periféricos y dispositivos informáticos sin necesidad de cables

Per collegare tra loro i vostri computer e le vostre periferiche senza l’utilizzo di cavi.

User Manual

Manuel de l'utilisateur

Benutzerhandbuch

Handleiding

Manual del usuario

Manuale utente

Conecte sus periféricos y dispositivos informáticos sin necesidad de cables

Per collegare tra loro i vostri computer e le vostre periferiche senza l’utilizzo di cavi.

Bluetooth™ USB Adapter

F8T008 - F8T009

Connect your peripherals

and computing devices, without cables

User Manual

Table of Contents

Introduction ............................................................................................................ 2

Product Features ..................................................................................................... 3

System Requirements ............................................................................................... 4

Package Contents ................................................................................................... 5

USB Adapter Specifications ..................................................................................... 6

Supported Profiles ................................................................................................... 7

Software Setup ........................................................................................................ 9

Hardware Setup ..................................................................................................... 14

Initial Configuration Wizard ..................................................................................... 17

Uninstalling the Software ........................................................................................ 20

Glossary ................................................................................................................ 21

Information ............................................................................................................ 23

Introduction

Thank you for purchasing the Bluetooth USB Adapter (the USB Adapter) from Belkin.

The USB Adapter features the breakthrough Bluetooth wireless technology that lets

you create efficient communications between your USB desktop PC or notebook and

devices using Bluetooth wireless technology—without physical connectors or cables.

Before you install and start using your new USB Adapter, please take a few minutes to

review some of the terms that you will be seeing throughout the document. You will find

a brief Glossary on page 21 of this manual.

Product Features

The USB Adapter is compliant with

Bluetooth

standard version 1.2 and provides:

• Compliancy with Bluetooth specification v1.2 devices

• USB bus powering: no external power supply necessary

• Support for Microsoft® Windows® 98 SE, Me, 2000, and XP

• Compatible with Mac OS® X v10.3 and higher*

• Operating distance of up to 10 meters (F8T009) or 100 meters (F8T008)**

• Point-to-multipoint connections

• Support for data rates up to 723/57.6Kbps

• Built-in security: up to 128-bit encryption and authentication

• Compatibility with USB desktop and notebook computers

*Mac OS X driver and software provided by Apple®.

** 10m/100m range is dependent upon environment, number of users, and other wireless devices within proximity.

PC System Requirements

• PC-compatible computer, CPU speed of 200MHz or above

• Memory: 64MB or above, 128MB recommended

• One available USB port, USB 1.1 standard

• Windows 98 SE, Me, 2000, and XP

Mac® System Requirements

• One available USB port, USB 1.1 standard

• Mac OS X v10.3 and higher*

*Mac OS X driver and software provided by Apple.

System Requirements

Package Contents

• Bluetooth USB Adapter

• CD-ROM for installation software and documentation

• User Manual

• Quick Installation Guide

• Registration Card

For a complete explanation of the Belkin Bluetooth software, refer to the software manual contained in the

included CD-ROM.

USB Adapter Specifications

Bluetooth Compliance: Version 1.2

Physical Interface: USB UHCI/OHCI 1.2-compliant

Operating Frequency: 2.4 to 2.4835GHz

Output Power: (F8T008) 4~20 dBm, Class I

(F8T009) -6~4 dBm, Class II

Sensitivity: <0.1% BER @ -80 dBm

Data Rate: 723/57.6Kbps

Typical Power

Consumption: (F8T008) Tx: 150mA, Rx 80mA

(F8T009) Tx: 65mA, Rx 45mA

Operating Range: (F8T008) 100-meter radius

indoors

(F8T009) 10-meter radius

indoors

Network Topology: Point-to-Multipoint

Packet Support: 1/3/5 Slots Packet

Operation: Master/Slave

Frequency Stability: +/- 10PPM

LED Indicator: Power On/Data Traffic

Antenna Type: Integrated, 0 +/- 1 dBi

Dimensions: 58mm (L) x 18mm (W) x 8mm (H)

Weight: 0.2oz. (7g)

Operating Temp: 0 to 70 degrees Celsius

Storage Temp: -30 to 80 degrees Celsius

Humidity: 5-90% (non-condensing)

Supply Voltage: 5.0V DC

Nominal Current: 100mA

Spread Spectrum: FHSS (Frequency Hopping

Spread Spectrum)

Modulation: GFSK (Gussian Frequency

Shift Keying)

Certifications: FCC, CE, ICES, C-Tick, BQB,

WHQL for XP

Warranty: 2 years

Supported Languages: English, German, Japanese,

Spanish, French

Specifications are subject to change without notice.

Supported Profiles

The services supported by your USB Adapter are defined as “Profiles”.

Available profiles include:

• Generic Access

• Service Discovery

• Personal Area Network

• Hardcopy Cable Replacement

• Serial Port

• LAN Access

• Dial-Up Networking

• Generic Object Exchange

• Object Push

• File Transfer

• Synchronization

• Fax

• Human Interface Device

• Headset

• Audio Gateway
