Table of Contents

Introduction ......................................................................................................... 4

Product Features.................................................................................................. 5

System Requirements........................................................................................... 6

Package Contents ................................................................................................ 7

US B Adapter S pecifications .................................................................................. 8

Software Setup .................................................................................................... 9

Hardware Setup ................................................................................................. 16

Initial C onfiguration Wizard................................................................................. 19

Uninstalling the S oftware.................................................................................... 22

How to use the B elkin B luetooth® Technology software ...................................... 26

UK - 3

Introduction

Thank you for purchasing the Bluetooth® Technology USB Adapter (the USB

Adapter) from Belkin. The USB Adapter features breakthrough Bluetooth® wireless

technology that lets you create efficient communications between your USB desktop

PC or notebook and devices using Bluetooth® wireless technology—without physical

connectors or cables.

Before you install and start using your new Bluetooth® Technology USB Adapter,

please take a few minutes to review some of the terms that you will be seeing

throughout the document.

UK-4

Product Features

• Bluetooth®Technology allows you to create an adhoc network

• Higher speed access up to 3Mbps (effective throughput of 2.2 Mbps)

• Adds Bluetooth® 2.0 + EDR wireless technology to

your USB desktop computer, or notebook

• Fast paring time between 3.5 to 5 sec.

• Lower power consumption

• Bit Error Rate (BER) improved performance

• Manufacturer’s Lifetime Warranty

• Offers backwards compatibility with any Bluetooth®

Technology v1.1 and v1.2-compliant device

• Installs easily with Plug-and-Play convenience

• Allows you to work at distances of up to 100 metres (Class 1) and 10 metres (Class 2)**

• Supports Microsoft®Windows®98 SE, Me, 2000, XP, and Mac OS®X v10.3 and higher*

** Range is dependent upon environment, number of users and other wireless devices within immediate proximity.

UK-5

PC System Requirements

• PC-compatible computer, CPU speed of 200MHz or above

• Memory: 64MB or above, 128MB recommended

• One available USB port, USB 1.1 or 2.0

• Windows 98 SE, Me, 2000, and XP

Mac®System Requirements

• One available USB port, USB 1.1 or 2.0

• Mac OS X v10.3 and higher*

*Mac OS X driver and software provided by Apple.

System Requirements

UK-6

Package Contents

• Bluetooth® Technology USB Adapter

• CD-ROM for installation software and documentation

• User + CAMagic Mobile™ Manual on CD

• Quick Installation Guide

• CAMagic Mobile™ Software

• Registration Card

UK-7

USB Adapter Specifications

Bluetooth® Technology Compliance:Version 2.0

Physical Interface: USB UHCI/OHCI 2.0-compliant

Operating Frequency: 2.4 to 2.4835GHz

Output Power: (F8T012) 4~20 dBm, Class I

(F8T013) -6~4 dBm, Class II

Sensitivity: <0.1% BER @ -80 dBm

Data Rate: 3Mbps (effective throughput of 2.2 Mbps)

Typical Power

Consumption: (F8T012) Tx: 150mA, Rx 80mA

(F8T013) Tx: 65mA, Rx 45mA

Operating Range: (F8T012) 100-meter radius indoors

(F8T013) 10-meter radius indoors

Network Topology: Point-to-Multipoint

Packet Support: 1/3/5 Slots Packet

Operation: Master/Slave

Frequency Stability: +/- 10PPM

LED Indicator: Power On/Data Traffic

Antenna Type: Integrated, 0 +/- 1 dBi

Dimensions: 58mm (L) x 18mm (W) x 8mm (H)

Weight: 0.2oz. (7g)

Operating Temp: 0 to 70 degrees Celsius

Storage Temp: -30 to 80 degrees Celsius

Humidity: 5-90% (non-condensing)

Supply Voltage: 5.0V DC

Nominal Current: 100mA

Spread Spectrum: FHSS (Frequency Hopping

Spread Spectrum)

Modulation: GFSK (Gussian Frequency

Shift Keying)

Certifications: FCC, CE, ICES, C-Tick,

BQB, WHQL for XP

Specifications are subject to change without notice.

UK-8

Software Setup

1. Insert the CD and wait for the software to run automatically.

2. Press on “Install Bluetooth® Technology Software”.

UK-9

Software Setup

Software Setup for Windows 98 SE, Me, 2000, and XP

To install the software for the USB Adapter, follow the instructions below:

Note: The installation process for Windows XP may look slightly different from

Windows 98 SE, Me, and 2000.

Note: Do not insert the USB Adapter into the USB port prior to software installation.

1. Insert the software installation CD-ROM into the PC’s CD-ROM drive.

2. The “Software InstallShield Wizard” window appears. Click on “Next” to begin the

installation process.

UK-10
