BGS technic 3213 Bedienungsanleitung

Art. 3213

8-piece Air Hammer Kit

Technical Data

Chisel shank: Ø 10 mm

Chisel shank length: 133 mm

Blow per minute: 4500

Working pressure: 90PSI

Air consumption: 4CFM (90PSI)

Air Inlet: 1/4“ PT

Stroke: 41 mm

Noise: LpA: 84 dB (A)

LwA: 95 dB (A)

Vibration: ahd = 9,4 m/s²

K = 1,5 m/s²

Weight: 1,1 kg

Please read these instructions carefully before use or maintain the air tool described. Keep

instructions for future reference.

Description

This air hammer is designed for cutting through rusted metal or bolts and removing mortar from

cement blocks or bricks.

General Safety

1. This air hammer is a part of a high pressure system. Do not exceed maximum operating pressure

of the air tool (90 PSI – 6,2 BAR). The hammer could explore and result in death or serious injury.

2. Disconnect the air drill from air compressor before changing tools or accessories, servicing and

during non operation.

3. Always ear safety glasses and using hearing protection during operation.

4. Do not wear loose fitting clothing and jewelry which may become caught in moving parts and

result in serious injury.

5. Do not depress trigger when connecting the air hose.

6. Never trigger the tool when not applied to a work object. Accessories must be securely attached.

7. Make sure spring retainer, all connections are secure and check air hoses for weak or worn

condition before each use.

8. WARNING !!! Disconnect air supply before installing or any maintenance notes.

Maintenance Tips

This air hammer requires lubrication BEFORE initial use and BEFORE and AFTER each additional

use throughout its life.

1. WARNING !!! Disconnect the air hammer from the air supply and hold the tool upside down.

2. Pull the trigger, put a half teaspoon of air tool oil into the air inlet.

3. Reconnect the air hammer to the air supply and run the hammer for 20 seconds.

Cover the exhaust port with a towel and run for 20 seconds. Oil will discharge from the rear exhaust

port when air pressure is applied. Any excess oil in the motor is immediately expelled from the

exhaust port.

WARNING !!! Always direct exhaust port away from people or objects.

Operations

Before use, drain water out of air compressor tank and condensation from air lines. After clearing air

compressor moisture and lubricating the air

hammer, connect it to an air hose of a recommended compressor.

1. Remove the spring retainer to load a chisel. Always tighten the spring retainer well before use.

WARNING !!! Use attachments designed for use with air tools. Do not use damaged attachments.

2. Depress the trigger to operate. Always hold the hammer well during operation to avoid injury.

Air Supply

Air supply MUST be greater than air requirement of the tool, Recommended air compressor is 3/4HP.

Air Hose: Using 3 m or 7,5 m long with 5 mm inside diameter and 1/4PT threads is recommended.

However, hoses longer than 7,5 m should use 10 mm even 12 mm inside diameter. For proper

performance and more convenience. Using fittings or air hoses which are too small can create a

pressure drop and reduce the power of the air hammer.

WARNING !!! Keep hoses away from heat, oil and sharp edges. Replace any hose that is damaged,

weak or worn. Never carry a tool by the hose or pull the hose to move the tool or a compressor.

The use of air filters and air line lubricators is recommended.

Storage

The air hammer must be lubricated before storage. Follow the lubrication instructions. Only run for 3

seconds instead of 20 seconds because more oil needs to remain in the tool when storing.

SW-Stahl und Werkzeugvertriebs GmbH Tel. +49 (0) 2191 / 46438-0

F56essartSresukreveL ax +49 (0) 2191 / 46438-40

ed.lhatsws@ofni:liaM-EdiehcsmeR79824-D

CE-Erklärung

BGS technic KG

Bandwirkerstr. 3

D-42929 Wermelskirchen

Tel.: 02196 720480

Fax.: 02196 7204820

[email protected]

www.bgstechnic.com

Wir erklären in alleiniger Verantwortung, dass die Bauart des Produktes:

We declare that the following designated product:

Nous déclarons sous propre responsabilité que ce produit:

Declaramos bajo nuestra sola responsabilidad que este producto:

folgenden einschlägigen Bestimmungen entspricht:

complies with the requirements of the:

est en conformité avec les réglementations ci-dessous:

esta conforme a las normas:

Angewandte Normen:



Norme appliquée:

Normas aplicadas:

ppa.

Frank Schottke, Prokurist

BGS technic KG, Bandwirkerstrasse 3, D-42929 Wermelskirchen

Wermelskirchen, den

EU-KONFORMITÄTSERKLÄRUNG

EC DECLARATION OF CONFORMITY

DÉCLARATION„CE“ DECONFORMITE

DECLARATION DE CONFORMIDAD UE

Druckluft-Meisselhammer-Satz (Art. 3213)

Air Hammer

Marteau à piquer pneumatique

Neumática martillo cincelador

Machinery Directive 2006/42/EC

EN ISO 11148-4:2012

Verification No.: 16081635C-S / WFH-1040

Test Report No.: 2011-16-70-16-PB001

16.06.2017
